Product Overview
The Pyle PDWRBT36RD speakers are a pair of 200-watt dual waterproof 3.5-inch 2-way full-range speakers designed for both indoor and outdoor use. Featuring a 1/2-inch high-compliance polymer tweeter and Bluetooth wireless music streaming, these speakers are suitable for various environments including home, boat, marine, deck, patio, and poolside. Their heavy-duty ABS construction ensures durability and a completely waterproof design.
What's in the Box
- (2) Speakers
- Mounting Brackets
- Mounting Hardware
- Speaker Cable
- Power Adapter
Image: The speaker set, mounting brackets, hardware, speaker cable, and power adapter are included in the box.
Setup & Installation
Mounting the Speakers
The Pyle PDWRBT36RD speakers are designed for universal mounting, allowing them to be installed either horizontally or vertically. The heavy-duty ABS construction and marine-grade waterproof design make them suitable for various outdoor and indoor locations. Use the provided mounting brackets and hardware to secure the speakers to your desired surface.
Image: A Pyle speaker is shown mounted on a wall, demonstrating its wall-mount capability.
Wiring Connections
These speakers feature quick-connect speaker terminals for easy wiring. The system includes a capacitor crossover network that separates two channels for distinct sound reproduction. Connect the speaker cable from the powered speaker to the passive speaker using these terminals.
Image: The rear panel of a Pyle speaker, highlighting the quick-connect speaker terminals, AUX in, and DC 12V power input.
Bluetooth Pairing
The speakers have a built-in Bluetooth wireless streaming receiver. To connect your device:
- Plug in the power adapter to the speaker and a power outlet.
- Turn on the speakers. You will hear an audible tone indicating they are searching for a Bluetooth device.
- On your smartphone, tablet, or other Bluetooth-enabled device, go to the Bluetooth settings.
- Ensure Bluetooth is enabled and search for available devices.
- Select 'Pyle' from the list of available devices. The default Bluetooth network password is '0000' (four zeroes).
- Once paired, you will hear a confirmation tone, and the speakers will be ready for audio streaming.
Video: Demonstrates how to connect a device via Bluetooth to Pyle speakers (Note: This video is for model PDWR42WBT, but the Bluetooth pairing process is generally similar).
Video: Shows the unboxing and setup process for similar 3.5-inch outdoor Bluetooth speakers, including wiring and Bluetooth connection.
Operating Instructions
Bluetooth Wireless Streaming
After successful pairing, you can stream audio wirelessly from your connected device. Adjust the volume directly from your device. The speakers are compatible with all modern devices, including smartphones, tablets, laptops, and computers.
Image: A person is shown streaming music wirelessly to a Pyle speaker from a smartphone.
Auxiliary Input (AUX IN)
For non-Bluetooth devices, you can use the 3.5mm AUX IN port located on the back of the powered speaker. Connect your audio source directly using a compatible 3.5mm audio cable (not included).
Features
- Full Range Audio: 200-watt peak power / 100W RMS with 3.5" aluminum injection cones subwoofer, 1.75" midrange, and 1/2" high compliance polymer tweeter for comprehensive stereo sound.
- Bluetooth Compatible: Wireless audio streaming from all modern devices (Smartphone, Tablet, Laptop, Computer, etc.) with Bluetooth Version 4.0 and a wireless range of 30+ ft.
- Quick-Connect Terminals: Easy and secure speaker wire connections.
- Waterproof Construction: Heavy-duty ABS construction and marine-grade waterproof design for safe use in environments with water splashes.
- Universal Mounting: Can be mounted horizontally or vertically using included brackets.
Image: Pyle speakers are shown with water droplets, illustrating their marine-grade waterproof design.
Image: An exploded view of the speaker highlights its 3.5-inch aluminum injection cone subwoofer and 1/2-inch high compliance polymer tweeter.
Image: A Pyle speaker is shown mounted on a wall, demonstrating its wall-mount capability and suitability for various indoor and outdoor uses.
Specifications
| Max Power: | 200 Watts |
| RMS Power: | 100 Watts |
| Subwoofers: | 3.5” Aluminum Injection Cones |
| Tweeters: | 1/2” High Compliance Polymer Tweeter |
| Impedance: | 8 Ohm |
| Sensitivity: | 90dB |
| Frequency Response: | 70-21KHz |
| Bluetooth Version: | 4.0 |
| Wireless Range: | 30+ ft. |
| Construction Material: | ABS |
| Product Dimensions (D x W x H): | 3.74’’ x 3.78’’ x 5.91’’ -inches |
| Item Weight: | 3.33 lbs. |
Maintenance
To ensure the longevity and optimal performance of your Pyle PDWRBT36RD speakers, follow these maintenance guidelines:
- Cleaning: Wipe the speaker surfaces with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners.
- Connection Check: Periodically inspect all wiring connections to ensure they are secure and free from corrosion, especially in outdoor environments.
- Environmental Care: While waterproof, avoid submerging the speakers. Ensure proper drainage if installed in areas prone to heavy water exposure.
- Storage: If storing the speakers for an extended period, especially during extreme weather, disconnect them and store them in a cool, dry place.
Troubleshooting
If you encounter issues with your Pyle PDWRBT36RD speakers, try the following steps:
- No Power: Ensure the power adapter is securely connected to both the speaker and a working power outlet. Check if the power outlet is functional.
- No Sound: Verify that the speaker wires are correctly connected to both the powered and passive speakers. Ensure your audio source device is playing music and its volume is turned up.
- Bluetooth Pairing Issues: Make sure the speakers are in pairing mode (indicated by an audible tone). Ensure Bluetooth is enabled on your device and it is within the 30+ ft wireless range. Try forgetting the 'Pyle' device from your device's Bluetooth list and re-pairing.
- Distorted Sound: Lower the volume on both your audio source and the speakers. Check for any loose connections or damaged cables.
Warranty & Support
The Pyle PDWRBT36RD speakers come with a Limited Warranty. For specific warranty details or technical support, please refer to the documentation included with your product or visit the official Pyle website. Ensure you retain your proof of purchase for warranty claims.
