Hangsun CN950 Pro Nebuliser Machine

1. Product Overview

The Hangsun CN950 Pro Nebuliser Machine is a compressor-based system designed for efficient and effective respiratory therapy for both adults and children. It converts liquid medication into a fine mist for inhalation, targeting various respiratory conditions.

Image: The Hangsun CN950 Pro Nebuliser Machine, showcasing its compact design and various included accessories such as masks and tubing.

This device is engineered for ease of use with one-button operation and features a built-in storage compartment for accessories, ensuring convenience and portability.

Image: Diagram illustrating how the nebuliser can assist with various breathing issues, including cough, asthma, fever, sore throat, rhinitis, and nasal mucus.

2. Important Safety Information

Please read all instructions carefully before using the nebuliser. Failure to follow these instructions could result in injury or damage to the device.

• Always use the nebuliser under the supervision of an adult, especially when used by children or individuals with limited physical capabilities.
• Do not immerse the main unit in water or any other liquid.
• Ensure the power cord is not damaged and is properly connected to a suitable power outlet.
• Use only medications prescribed by a healthcare professional with this device.
• Keep the device and accessories out of reach of small children.
• Do not block the air vents during operation.
• Unplug the device from the power outlet before cleaning or when not in use.

3. Package Contents

The Hangsun CN950 Pro Nebuliser Machine comes with a comprehensive set of accessories to ensure versatile use for different age groups and needs. Please verify all items are present upon unboxing.

Image: A visual representation of all components included in the package, such as the compressor main unit, air tube, masks, mouthpiece, nosepieces, spare air filters, nozzle attachments, and instruction manual.

• 1 x Main Unit (Compressor)
• 1 x Mouthpiece
• 1 x Infant Mask
• 1 x Children's Mask
• 1 x Adult Mask
• 1 x Children's Nose Adapter
• 1 x Adults Nose Adapter
• 8 x Replacement Filters
• 3 x Attachments for different particle sizes (Blue, Red, Yellow)
• 1 x Air Tube
• 1 x Instruction Manual

Image: Close-up views of the nebuliser's accessory storage case, portable handle, and power cable storage compartment, highlighting its integrated design for organization and transport.

4. Setup Guide

Follow these steps to set up your Hangsun CN950 Pro Nebuliser Machine for first use:

1. Unpack the Device: Carefully remove all components from the packaging.
2. Place the Unit: Position the main unit on a stable, flat surface.
3. Connect the Air Tube: Open the flip-top lid. Connect one end of the air tube to the air outlet on the main unit.
4. Assemble the Nebuliser Cup: Attach the other end of the air tube to the bottom of the nebuliser cup.
5. Add Medication: Open the nebuliser cup and pour the prescribed liquid medication into it. Do not overfill.
6. Attach Desired Accessory: Securely attach the mouthpiece, adult mask, children's mask, or nose adapter to the top of the nebuliser cup, depending on the user and treatment.
7. Connect to Power: Plug the power cord into a suitable electrical outlet.

Image: A detailed diagram labeling the key components of the nebuliser, including the power switch, flip-top lid, adult mask, cup, holder, accessory case, air filter, air plug, air vent, tube, and rubber feet, illustrating their positions and functions.

Setup Video Guide

5. Operating Instructions

Once the nebuliser is set up, follow these steps for effective treatment:

1. Turn On: Press the power switch located on the main unit to turn on the device. The compressor will begin to generate air flow, creating a fine mist from the medication.
2. Inhale:
   • With Mouthpiece: Place the mouthpiece between your teeth and seal your lips around it. Breathe in slowly and deeply through your mouth until all medication is nebulised.
   • With Mask: Place the mask over your nose and mouth, ensuring a snug fit. Breathe normally and deeply until all medication is nebulised.
   • With Nose Adapter: Insert the nose adapter into your nostrils. Breathe normally through your nose.
3. Treatment Duration: Continue inhalation until the nebuliser cup is empty or the mist production stops. This typically takes 5-10 minutes, depending on the medication volume and flow rate.
4. Turn Off: Once the treatment is complete, press the power switch again to turn off the device.

Image: An infographic highlighting the nebuliser's efficient and powerful features, including short treatment time, ultra-quiet operation (<55dB), 1.5m extra long hose, suitability for children and adults, and one-button operation.

Operation Video Guide

6. Maintenance and Cleaning

Proper cleaning and maintenance are essential for the longevity and hygienic operation of your nebuliser.

Daily Cleaning (After Each Use):

1. Disconnect: Unplug the device from the power outlet.
2. Disassemble: Separate the nebuliser cup, mouthpiece/mask, and air tube from the main unit.
3. Rinse: Rinse the nebuliser cup, mouthpiece/mask, and nose adapters thoroughly with warm tap water.
4. Dry: Air dry all components completely on a clean paper towel or allow them to dry naturally. Ensure no moisture remains before reassembly or storage.

Weekly Disinfection:

1. Prepare Solution: Prepare a solution of one part white vinegar to three parts distilled water, or use a medical disinfectant solution recommended by your healthcare provider.
2. Soak: Soak the disassembled nebuliser cup, mouthpiece/mask, and nose adapters in the solution for 30 minutes.
3. Rinse: Remove components from the solution and rinse them thoroughly under warm running water for several minutes to remove any residue.
4. Dry: Air dry all components completely before storing.

Filter Replacement:

The air filter should be checked regularly and replaced every 30 days or sooner if it appears discolored or clogged. Using a dirty filter can impair the performance of the device.

1. Locate the air filter compartment on the main unit.
2. Remove the old filter.
3. Insert a new, clean filter. Ensure it fits snugly.

Note: Do not wash or reuse the air filter. Replace it with a new one from the provided spare filters.

7. Troubleshooting

If you encounter any issues with your nebuliser, please refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact customer support.

8. Product Specifications

Image: A visual representation of the nebuliser's compact size and weight (1.90kg), with approximate dimensions of 13 inches (height), 7.8 inches (length), and 5.0 inches (width).

9. Warranty and Customer Support

Hangsun is committed to providing high-quality products. The Hangsun CN950 Pro Nebuliser Machine typically comes with a manufacturer's warranty.

Image: A badge indicating a 36-month (3-year) warranty for the product, signifying manufacturer confidence in durability.

For specific warranty details, claims, or technical assistance, please refer to the warranty card included in your package or contact Hangsun customer support directly. You can often find contact information on the manufacturer's official website or through your point of purchase.

For further assistance, please visit the HANGSUN Store on Amazon.
