Edifier W600BT Bluetooth Over-Ear Headphones User Manual

Introduction

Thank you for purchasing the Edifier W600BT Bluetooth Over-Ear Headphones. This manual provides instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your device. Please read this manual thoroughly before use.

Image: Edifier W600BT Bluetooth Over-Ear Headphones. These over-ear headphones feature a sleek grey design with comfortable earcups and an adjustable headband.

Package Contents

The Edifier W600BT package includes the following items:

• Edifier W600BT Bluetooth Over-Ear Headphones
• 3.5mm Audio Cable
• USB Charging Cable
• User Manual (this document)

Setup

Charging the Headphones

1. Connect the USB charging cable to the charging port on the headphones.
2. Connect the other end of the USB cable to a USB power adapter (not included) or a computer's USB port.
3. The indicator light will illuminate during charging and turn off when fully charged. A full charge takes approximately 3 hours.

Bluetooth Pairing

1. Ensure the headphones are charged.
2. Press and hold the power button until the indicator light flashes blue and red, indicating pairing mode.
3. On your device (smartphone, tablet, laptop), enable Bluetooth and search for available devices.
4. Select "EDIFIER W600BT" from the list of devices.
5. Once connected, the indicator light will flash blue slowly.

Image: Diagram illustrating Bluetooth 5.1 connectivity for the Edifier W600BT headphones, showing connections to a laptop, headphones, and smartphone. Bluetooth 5.1 offers faster transmission, better sound quality, and a more stable connection.

Operating Instructions

Power On/Off

• Power On: Press and hold the power button for approximately 3 seconds.
• Power Off: Press and hold the power button for approximately 5 seconds.

Music Playback

• Play/Pause: Press the multi-function button once.
• Next Track: Press and hold the "+" button.
• Previous Track: Press and hold the "-" button.
• Volume Up: Short press the "+" button.
• Volume Down: Short press the "-" button.

Call Management

• Answer/End Call: Press the multi-function button once.
• Reject Call: Press and hold the multi-function button for 2 seconds.

Image: A close-up of the Edifier W600BT headphones, highlighting the control buttons on the earcup for media playback and call management.

Wired Connection

The headphones can also be used with a wired connection, which is useful when the battery is depleted or for devices without Bluetooth functionality.

1. Connect one end of the included 3.5mm audio cable to the audio jack on the headphones.
2. Connect the other end of the 3.5mm audio cable to your audio source (e.g., computer, tablet, laptop).
3. In wired mode, the headphones will function passively and do not require battery power.

Image: A person wearing Edifier W600BT headphones, with an inset showing a 3.5mm audio jack. This illustrates the option for wired connection, ensuring continuous audio even if the battery is low.

Maintenance

• Clean the headphones regularly with a soft, dry cloth.
• Avoid exposing the headphones to extreme temperatures, humidity, or direct sunlight.
• Do not use abrasive cleaners or solvents.
• Store the headphones in a cool, dry place when not in use.
• Avoid dropping or subjecting the headphones to strong impacts.

Troubleshooting

Specifications

• Model: W600BT
• Bluetooth Version: 5.1
• Driver Unit: 40mm NdFeB
• Battery Life: Up to 30 hours (playback)
• Charging Time: Approximately 3 hours
• Connectivity: Bluetooth, 3.5mm Audio Jack
• Dimensions: 7.56 x 3.44 x 9.21 inches
• Weight: 13 ounces (0.81 lbs)
• Material: Faux Leather (ear pads)
• Included Components: Cable (3.5mm audio cable)

Official Product Video

Warranty and Support

For warranty information and technical support, please refer to the official Edifier website or contact their customer service directly. Keep your purchase receipt for warranty claims.

Edifier Official Website: www.edifier.com
