1. Introduction
Thank you for choosing the Beghelli 86152 Floodlight FL Outdoor Projector. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new LED floodlight. Please read these instructions carefully before installation and retain them for future reference.
Image 1: Beghelli 86152 Floodlight FL Outdoor Projector. This image shows the front view of the white LED floodlight with its integrated mounting bracket.
2. Safety Information
Always observe the following safety precautions to prevent injury or damage to the product:
- Electrical Installation: Installation must be performed by a qualified electrician in accordance with all local and national electrical codes.
- Power Disconnection: Ensure the main power supply is disconnected before any installation, maintenance, or cleaning.
- Voltage: This product operates on 220-240 VAC, 50/60 Hz. Verify your power supply matches these requirements.
- Grounding: The floodlight must be properly grounded to prevent electric shock.
- Outdoor Use: The product is rated IP66 for outdoor use, providing protection against dust and powerful water jets. However, do not submerge the unit.
- Temperature: Do not operate the floodlight outside the specified ambient temperature range of -20°C to +40°C.
- Light Source: Do not stare directly into the LED light source when illuminated, as it may cause eye damage.
- Modifications: Do not attempt to modify or repair the floodlight. Refer all servicing to qualified personnel.
3. Package Contents
Please check the package for the following items:
- Beghelli 86152 Floodlight FL Outdoor Projector (1 unit)
- Mounting Bracket (pre-attached)
- Instruction Manual (this document)
- Note: Mounting hardware (screws, anchors) may not be included and should be selected based on the installation surface.
4. Setup and Installation
Follow these steps for proper installation of your Beghelli Floodlight FL:
- Choose Location: Select a suitable outdoor location for mounting. The floodlight can be installed on a wall or ground. Ensure the surface is sturdy enough to support the weight of the fixture (approximately 1 kg).
- Power Disconnection: Before starting any electrical work, ensure the main power supply to the installation area is turned off at the circuit breaker.
- Mounting:
- Use the pre-attached mounting bracket as a template to mark drilling points on the desired surface.
- Drill appropriate holes and insert suitable anchors (if required for your surface type).
- Secure the mounting bracket firmly to the surface using appropriate screws.
- Adjust the angle of the floodlight as needed using the bracket's pivot points, then tighten securely.
- Electrical Connection:
- Route the electrical cable to the floodlight's connection point. Ensure the cable is suitable for outdoor use and protected from damage.
- Connect the live (brown/black), neutral (blue), and earth (green/yellow) wires from your power supply to the corresponding terminals on the floodlight. Ensure all connections are secure and properly insulated.
- Verify all wiring is correct and secure before proceeding.
- Final Check: Double-check all connections and mounting security. Ensure no wires are exposed or pinched.
Image 2: Beghelli 86152 Floodlight FL Side View. This image provides a side perspective of the floodlight, highlighting its slim profile and the adjustable mounting bracket.
5. Operating Instructions
Once installed correctly, operating the Beghelli Floodlight FL is straightforward:
- Restore Power: After ensuring all installation steps are complete and safe, restore power to the circuit at the main breaker.
- Switch On: Use the external wall switch or control system connected to the floodlight to turn it on. The LED light will illuminate instantly.
- Switch Off: Turn off the floodlight using the same external switch or control system.
This floodlight is designed for direct connection to a power source and does not feature integrated user controls like dimmers or color temperature adjustments.
6. Maintenance
The Beghelli Floodlight FL is designed for minimal maintenance. Follow these guidelines to ensure longevity and optimal performance:
- Cleaning: Periodically clean the floodlight's surface and glass cover with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the finish or seals. Ensure power is disconnected before cleaning.
- Inspection: Regularly inspect the floodlight for any signs of damage, loose connections, or wear on the cable. Address any issues promptly.
- No User Serviceable Parts: The LED light source is integrated and not user-replaceable. Do not attempt to open the fixture, as this will void the warranty and may compromise its IP66 rating.
7. Troubleshooting
If you encounter issues with your floodlight, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Floodlight does not turn on. | No power supply. Loose wiring connection. Faulty external switch. | Check if the circuit breaker is on. Verify all electrical connections are secure (ensure power is off first). Test the external switch. |
| Light is dim or flickers. | Unstable power supply. Loose connection. Product fault. | Ensure stable power. Check wiring connections (power off). If problem persists, contact customer support. |
| Water ingress inside the fixture. | Improper installation. Damaged seal. | Ensure all seals are properly seated and the fixture is correctly assembled. If damaged, contact customer support; do not attempt to repair. |
If the problem persists after attempting these solutions, please contact Beghelli customer support or a qualified electrician.
8. Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | 60047 (also known as 86152 Floodlight FL) |
| Power | 50 W |
| Input Voltage | 220-240 VAC, 50/60 Hz |
| Light Color Temperature | 4000K (Cool White) |
| Luminous Flux | 3000 lumens |
| Luminous Efficacy | 60 lumen/watt |
| Protection Rating | IP66 (Dust tight and protected against powerful water jets) |
| Ambient Temperature | -20°C to +40°C |
| Body Material | Plastic |
| Lampshade Material | Glass |
| Color | White |
| Mounting Type | Wall mount, Surface mount |
| Product Weight | 1 kg |
| Compliance | EN60598-1; EN60598-2-1; EN 62471 |
| Country of Origin | Italy |
9. Warranty and Support
Beghelli products are manufactured to high-quality standards and are covered by a standard manufacturer's warranty. Please refer to the warranty card included with your purchase or visit the official Beghelli website for detailed warranty terms and conditions.
For technical support, troubleshooting assistance, or warranty claims, please contact your retailer or Beghelli customer service directly. Ensure you have your product model number (86152 Floodlight FL or 60047) and proof of purchase available when contacting support.
Beghelli Official Website: www.beghelli.it
