KLARSTEIN Pausa Espresso Machine User Manual

1. Introduction

Thank you for choosing the KLARSTEIN Pausa Espresso Machine. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read this manual thoroughly before first use and keep it for future reference.

Image 1.1: The KLARSTEIN Pausa Espresso Machine in operation, brewing a cup of espresso.

2. Safety Instructions

To prevent injury or damage, always observe basic safety precautions when using electrical appliances. This machine operates with high pressure and hot water/steam.

• Read all instructions before use.
• Do not immerse the appliance, power cord, or plug in water or other liquids.
• Ensure the voltage indicated on the appliance matches your local mains voltage.
• Keep children and unauthorized persons away from the appliance during operation.
• Always unplug the machine before cleaning and when not in use.
• Do not operate the appliance with a damaged cord or plug.
• Use only original accessories and spare parts.
• Exercise caution when handling hot surfaces and steam.

3. Product Overview and Components

Familiarize yourself with the parts of your espresso machine for optimal use.

Image 3.1: The espresso machine features 1350 Watts of power and a 20-bar pressure pump for efficient coffee extraction.

Image 3.2: The top of the machine includes a preheated stainless steel tray for storing and warming cups, along with push buttons for selecting 1 or 2 cups of espresso.

Image 3.3: The machine is compatible with both ground coffee and coffee pods, offering versatility in brewing options. Shown are the portafilter, measuring spoon, various filter baskets, and coffee pods.

Image 3.4: The movable milk foam nozzle allows for easy frothing of milk, perfect for creating lattes and cappuccinos.

Image 3.5: The machine features an easily removable 1.4-liter water tank and a drip tray with a grid for quick cleaning.

4. Setup

4.1 Unpacking

Carefully remove all packaging materials. Check the machine for any damage. Keep packaging for future transport if needed.

4.2 Initial Cleaning

1. Wash the water tank, portafilter, filter baskets, and drip tray with warm soapy water. Rinse thoroughly and dry.
2. Wipe the exterior of the machine with a damp cloth.

4.3 Filling the Water Tank

1. Remove the water tank from the back of the machine.
2. Fill the tank with fresh, cold water up to the MAX level indicator. Do not use hot water or other liquids.
3. Place the water tank back into the machine, ensuring it is securely seated.

4.4 First Use / Priming

Before brewing coffee, prime the machine to fill the internal system with water.

1. Ensure the water tank is filled.
2. Place a cup under the portafilter outlet (without coffee).
3. Press the power button to turn on the machine. The indicator lights will flash as the machine heats up.
4. Once the lights are solid, press the single espresso button. Let water run through until the cup is full. Repeat this process 2-3 times.
5. Turn the steam knob to release steam for 10-15 seconds to prime the steam wand. Close the knob.

5. Operating Instructions

5.1 Making Espresso

1. Ensure the machine is on and preheated (indicator lights solid).
2. Insert the desired filter basket (single or double shot) into the portafilter.
3. Add ground coffee to the filter basket. For a single shot, use approximately 7g; for a double, use 14g. Tamp the coffee evenly.
4. Attach the portafilter to the brew head by aligning it and turning it firmly to the right.
5. Place one or two cups on the drip tray under the portafilter spouts.
6. Press the single or double espresso button. The machine will automatically dispense the programmed amount of espresso.
7. Once brewing is complete, remove the portafilter and discard the used coffee grounds.

Image 5.1: The KLARSTEIN Pausa Espresso Machine allows you to prepare a variety of coffee specialties, including Espresso, Cappuccino, and Latte Macchiato.

5.2 Using Coffee Pods

1. Use the specific filter basket designed for coffee pods.
2. Place one coffee pod into the filter basket.
3. Follow steps 4-7 from the 'Making Espresso' section.

5.3 Frothing Milk

1. Fill a pitcher with cold milk (dairy or non-dairy) to about one-third full.
2. Ensure the machine is preheated and the steam function is ready (steam indicator light solid).
3. Position the steam wand into the milk, just below the surface.
4. Turn the steam knob to release steam. Move the pitcher up and down to create foam.
5. Once desired foam and temperature are reached, turn off the steam knob.
6. Immediately wipe the steam wand with a damp cloth to prevent milk residue from drying.

6. Maintenance and Cleaning

Regular cleaning ensures optimal performance and extends the lifespan of your espresso machine.

6.1 Daily Cleaning

• Portafilter and Filter Baskets: After each use, remove coffee grounds and rinse with warm water.
• Drip Tray: Empty and clean the drip tray and grid daily.
• Steam Wand: Wipe immediately after frothing milk. Periodically remove the nozzle and clean any milk residue with a small brush.
• Water Tank: Rinse the water tank daily and refill with fresh water.

6.2 Descaling

Descale the machine every 2-3 months, or more frequently if you have hard water, to prevent mineral buildup.

1. Prepare a descaling solution according to the descaler manufacturer's instructions.
2. Fill the water tank with the descaling solution.
3. Place a large container under the brew head and steam wand.
4. Turn on the machine. Once heated, run half of the solution through the brew head by pressing the espresso button.
5. Then, open the steam knob and let the remaining solution run through the steam wand.
6. After the tank is empty, rinse the water tank thoroughly and fill it with fresh water.
7. Repeat steps 4-5 with fresh water to rinse the machine.

7. Troubleshooting

8. Specifications

9. Warranty and Support

KLARSTEIN products are manufactured with quality and care. For warranty information, please refer to the documentation provided with your purchase or visit the official KLARSTEIN website. For technical support or service inquiries, please contact KLARSTEIN customer service.

Please retain your proof of purchase for any warranty claims.
