XP Metal Detectors BH-01 Bone Conduction Wired Headphones User Manual

1. Product Overview

The XP BH-01 Bone Conduction Wired Headphones are specifically designed for use with the XP Deus II metal detector. These headphones utilize bone conduction technology to transmit sound directly to the inner ear through vibrations on the cheekbone, bypassing the eardrums. This design makes them suitable for underwater metal detection and allows users to maintain awareness of their surroundings when used on land.

Certified IP68, the BH-01 headphones are waterproof for submersion up to 20 meters (66 feet), ensuring reliable performance in various aquatic environments. They are manufactured in France and come with a 2-year warranty.

Figure 1: XP BH-01 Bone Conduction Wired Headphones. These headphones are designed to sit comfortably on the cheekbones, transmitting sound through bone vibrations.

2. Key Features

• Bone Conduction Technology: Transmits audio directly through vibrations to the cheekbone, allowing for clear sound without covering the ears.
• Waterproof IP68 Certified: Fully submersible up to 20 meters (66 feet), ideal for underwater metal detection with the XP Deus II.
• Multi-Terrain Use: Enables users to hear ambient sounds on land, enhancing safety and situational awareness. Can also be used with earplugs in noisy conditions for focused detection.
• Optimized for Noisy Environments: Provides clear audio even in disturbed or windy water conditions, protecting the ears while maintaining sound perception.
• Durable Construction: Designed for longevity and supplied with a dedicated storage bracket to maintain shape.
• Made in France: Ensures high-quality manufacturing standards.

Figure 2: Overview of key features, highlighting the waterproof capability, rich audio, and bone conduction design.

3. Setup

The BH-01 headphones are designed for exclusive compatibility with the XP Deus II metal detector. Connection is straightforward via a proprietary 6-pin connector.

1. Locate the dedicated headphone port on your XP Deus II metal detector.
2. Align the 6-pin connector of the BH-01 headphones with the port.
3. Gently push the connector into the port until it is securely seated. Ensure a firm connection to maintain waterproofing and optimal audio transmission.

Figure 3: Connection diagram for the BH-01 headphones to the Deus II control unit. The Deus II's integrated amplifier ensures exceptional audio quality underwater.

4. Operating Instructions

4.1. On Land Use

When using the BH-01 headphones on land, their bone conduction design allows you to hear the metal detector's signals clearly while remaining aware of your surrounding environment. This is particularly beneficial for safety in busy or natural settings.

• Position the transducers firmly on your cheekbones, just in front of your ears.
• Adjust the fit for comfort and secure placement.
• In noisy or windy conditions, you may opt to use earplugs (not included) to further isolate the metal detector's audio and enhance focus.

Figure 4: The BH-01 headphones allow users to hear their surroundings while metal detecting on land, promoting safety and awareness.

4.2. Underwater Use

The IP68 certification ensures the BH-01 headphones are fully functional and waterproof for deep submersion. They work effectively whether you are wearing a diving hood or not.

• Ensure the connection to the XP Deus II is secure before entering the water.
• The bone conduction technology provides clear audio even in disturbed or noisy underwater environments, allowing you to pinpoint targets accurately.
• The headphones are designed to withstand pressure up to 20 meters (66 feet) depth.

Figure 5: The BH-01 headphones are designed for underwater use, functioning perfectly with or without a diving hood, allowing for clear detection through bone conduction.

5. Maintenance

Proper maintenance will extend the lifespan of your XP BH-01 headphones.

• Cleaning: After each use, especially in saltwater, rinse the headphones thoroughly with fresh water to prevent corrosion. Wipe them dry with a soft cloth.
• Storage: Always store the BH-01 headphones on their supplied storage bracket. This helps them maintain their original shape and ensures a snug fit on your cheekbones during future use. Store in a cool, dry place away from direct sunlight.
• Cable Care: Avoid sharp bends or excessive pulling on the cable to prevent internal damage.

Figure 6: The included storage bracket helps maintain the shape and fit of your BH-01 headphones for optimal comfort and performance.

6. Troubleshooting

If you encounter issues with your XP BH-01 headphones, please refer to the following common solutions:

If the issue persists after attempting these solutions, please contact XP Metal Detectors customer support for further assistance.

7. Specifications

8. Warranty and Support

The XP BH-01 Bone Conduction Wired Headphones are covered by a 2-Year Warranty from the date of purchase. This warranty covers manufacturing defects and ensures the product is designed to last.

For warranty claims, technical support, or any inquiries regarding your BH-01 headphones, please contact XP Metal Detectors customer service through their official website or authorized distributors. Please have your proof of purchase and product model number (BH-01) ready when contacting support.
