EVERSECU 1080P 2MP Wireless PTZ Security Camera Instruction Manual

1. Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your EVERSECU 1080P 2MP Wireless PTZ Security Camera. Please read this manual thoroughly before using the product to ensure proper function and safety. Keep this manual for future reference.

2. Product Overview

The EVERSECU 1080P 2MP Wireless PTZ Security Camera is designed for home and commercial surveillance, offering high-definition video, pan-tilt-zoom capabilities, and smart features for enhanced security.

2.1 Key Features

• 1080P 2MP Ultra HD Video Resolution: Provides clear and fluent video streaming.
• Pan-Tilt-Zoom (PTZ): Offers 355° pan, 110° tilt, and 4x digital zoom for comprehensive area coverage.
• Humanoid Auto Tracking: Automatically tracks human motion and records activity.
• Two-Way Audio: Built-in microphone and speaker for real-time communication.
• Spotlight Color Night Vision: Features 2 IR LEDs and 6 white LEDs for up to 65.6ft full-color night vision.
• Motion Detection & Real-time Alerts: Sends notifications upon detecting motion.
• Easy Installation: Plugs directly into a standard power socket (110V~240V) without complex wiring.
• Storage Options: Supports local TF card storage (not included) and cloud storage (30-day free trial).
• Tuya Smart Life App Integration: Remote control and monitoring via the Tuya app.

2.2 Product Components

Familiarize yourself with the main parts of your security camera:

Figure 1: Front view of the EVERSECU 1080P 2MP Wireless PTZ Security Camera, showing the lens and plug.

Figure 2: Detailed diagram illustrating the camera's components, including the lens, microphone, speaker, IR sensor, array LEDs, white LEDs, Micro SD card slot, and reset button.

3. Setup Instructions

Follow these steps to set up your EVERSECU security camera.

3.1 Easy Installation

The camera is designed for simple plug-and-play installation:

1. Locate a standard power socket (110V~240V) where you wish to install the camera.
2. Plug the camera directly into the power socket. No drilling, wiring, or power cables are required beyond the socket itself.
3. Ensure the camera powers on and is ready for app pairing.

Figure 3: Image demonstrating the simple plug-in installation of the camera into a power outlet.

3.2 Tuya Smart App Download and Registration

The Tuya Smart app is essential for controlling and monitoring your camera.

1. Download the 'Tuya Smart' app from your device's app store (iOS App Store or Google Play Store).
2. Open the app and complete the account registration process by following the on-screen prompts.

3.3 Device Pairing

Pair your camera with the Tuya Smart app:

1. In the Tuya Smart app, tap 'Add Device' or the '+' icon.
2. Select 'Security & Video Surveillance' and then 'Smart Camera (Wi-Fi)'.
3. Follow the in-app instructions to reset the device if prompted.
4. Enter your 2.4 GHz Wi-Fi network details (SSID and password). Note: 5GHz Wi-Fi is not supported.
5. The app will generate a QR code. Position your phone so the camera lens can scan this QR code.
6. Once the camera successfully scans the code and emits a prompt tone, confirm in the app.
7. The device will connect and be added to your app.

4. Operating Instructions

Learn how to use the various functions of your EVERSECU security camera.

4.1 Live View and PTZ Control

1. Open the Tuya Smart app and select your camera from the device list.
2. You will see the live video feed. You can switch between HD and SD resolution.
3. Use the on-screen controls to pan (355°), tilt (110°), and digitally zoom the camera view.
4. Set preset positions for quick navigation to specific areas.

4.2 Two-Way Audio

Communicate through the camera:

• In the live view, tap the microphone icon to speak through the camera's speaker.
• Tap the speaker icon to hear audio from the camera's environment.
• This feature allows for real-time conversations with visitors or to deter intruders.

Figure 4: Illustration of the two-way audio function, enabling communication between the app user and the camera's location.

4.3 Motion Detection and Auto Tracking

Enable and configure motion-activated features:

1. Access the camera settings in the app.
2. Enable 'Motion Detection Alarm' and adjust the sensitivity level.
3. Define specific 'Activity Areas' to focus detection on critical zones.
4. When motion is detected, the camera will automatically track the movement and send real-time alerts to your phone.

Figure 5: Visual representation of the camera's mobile tracking capability, highlighting its ability to follow moving objects.

4.4 Night Vision Modes

The camera offers different night vision options:

• Infrared (IR) Mode: When light is insufficient, the camera automatically activates IR LEDs for black and white video.
• Automatic Mode: Similar to IR mode, but if motion is detected, the white spotlights will turn on for full-color night vision.
• Full-Color Night Vision: Utilizes 2 IR LEDs and 6 white LEDs to provide clear, full-color video even in low-light conditions.

Figure 6: Example of the camera's full-color night vision, showcasing its clarity in dark environments.

4.5 Video Storage and Playback

Manage your recordings and view past events:

1. SD Card Storage: Insert a Micro SD card (not included) into the designated slot on the camera. Configure local recording settings (event-based or non-stop) and schedule recording times via the app.
2. Cloud Storage: The Tuya app supports cloud storage services. You can purchase a subscription for secure, encrypted video storage.
3. Playback: In the app, select the 'Playback' option, choose the desired date, and drag the progress bar to view recorded footage.

Figure 7: Diagram showing the camera's support for both local TF card storage and cloud storage solutions.

4.6 Device Sharing and Privacy Mode

• Device Sharing: Share access to your camera with family and friends through the Tuya app. This allows multiple users to view the live feed simultaneously.
• Privacy Mode: Activate privacy mode in the app settings. This will put the camera into a sleep state, protecting your privacy when needed. The camera will resume monitoring once privacy mode is deactivated.

5. Maintenance

Regular maintenance ensures optimal performance and longevity of your camera.

• Cleaning: Gently wipe the camera lens and body with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials.
• Firmware Updates: Periodically check for firmware updates through the Tuya Smart app. Updates can improve performance, add new features, and enhance security. The app supports online detection and update.
• SD Card Management: If using an SD card, regularly check its status and format it as needed to maintain recording quality and prevent data corruption.
• Account Security: Bind your account with your mobile phone number or email address, and consider setting up fingerprint ID or a gesture password to protect your account information.

6. Troubleshooting

If you encounter issues with your camera, refer to the following common problems and solutions:

7. Specifications

Detailed technical specifications for the EVERSECU 1080P 2MP Wireless PTZ Security Camera:

• Model: B09PVBGZ3H
• Brand: EVERSECU
• Video Capture Resolution: 1080p, 720p
• Connectivity Technology: Wireless (Wi-Fi)
• Power Source: Corded Electric (110V~240V)
• Special Features: Motion Sensor, Night Vision, PTZ Technology
• Indoor/Outdoor Usage: Indoor
• Controller Type: Amazon Alexa (Compatible)
• Mounting Type: Wall Mount
• Color: White
• Item Weight: 11.4 ounces
• Package Dimensions: 6.3 x 5.71 x 3.35 inches
• International Protection Rating: IP65
• UPC: 778299333160

8. Warranty and Support

For warranty information and technical support, please refer to the official EVERSECU website or contact their customer service directly. Keep your purchase receipt as proof of purchase for warranty claims.
