1. Introduction
This manual provides detailed instructions for the installation, operation, and maintenance of your TheiaMo 36"x24" Oval LED Bathroom Mirror. This mirror features integrated LED lighting, anti-fog functionality, and adjustable color temperatures to enhance your daily routine.
Key features of your TheiaMo LED Bathroom Mirror include:
- Anti-Fog Function: Ensures a clear reflection even after a steamy shower.
- 3 Color Temperatures: Offers warm (3000K), natural (4000K), and cold (6000K) light options.
- Shatter-Proof Design: Constructed with automotive-grade frosted glass for enhanced safety.
- Exquisite Framed Design: Modern aluminum frame available in black.
- HD & Waterproof: 1:1 HD reflection with IP65 waterproof rating and anti-oxidation protective layer.
- Memory Function: Retains your last light setting.
- UL Certified: Ensures electrical safety standards are met.
2. Safety Information
Please read all safety instructions carefully before installation and use. Failure to follow these instructions may result in electric shock, fire, or personal injury.
- Electrical Safety: Ensure power is disconnected at the circuit breaker before any installation or maintenance. All wiring should be performed by a qualified electrician in accordance with local electrical codes.
- Handling: Although this mirror is designed to be durable and safe with shatter-proof glass, handle with care during installation and use to avoid potential injury.
- Water Exposure: The mirror has an IP65 waterproof rating, making it suitable for bathroom environments. However, avoid direct water spray onto electrical components.
- Cleaning: Use only mild, non-abrasive cleaners. Do not spray cleaner directly onto the mirror's edges or electrical components.
- Ventilation: Ensure adequate ventilation in the bathroom to prevent excessive humidity buildup, which can affect electronic components over time.
3. Setup and Installation
Before beginning installation, ensure you have all necessary tools and components. It is recommended to have two people for installation due to the mirror's size and weight.
3.1 Package Contents
- TheiaMo Oval LED Bathroom Mirror
- Mounting Hardware (screws, wall anchors)
- Installation Template (if included)
- Instruction Manual
3.2 Choosing Installation Location
Consider the mirror's dimensions (36"L x 24"W) and ensure adequate space. The mirror can be mounted horizontally or vertically.
3.3 Mounting the Mirror
- Mark the desired position on the wall using the provided template or by measuring.
- Drill pilot holes at the marked locations.
- Insert wall anchors into the drilled holes.
- Secure the mounting brackets or screws, ensuring they are level and firmly attached.
- Carefully lift the mirror and hang it onto the secured mounting hardware.
3.4 Electrical Connection
The mirror supports both plug-in and hardwired installations. Ensure power is off before connecting.
- Plug-in: Simply plug the mirror's power cord into a standard electrical outlet.
- Hardwired: For a seamless look, the mirror can be hardwired directly into your electrical system. This requires professional installation. Connect the mirror's wires to the corresponding household wires (Live, Neutral, Ground) according to local electrical codes.
The mirror also supports control via a wall switch when hardwired.
4. Operating Instructions
Your TheiaMo LED Bathroom Mirror is equipped with intuitive touch controls for easy operation.
4.1 Power On/Off
Locate the touch sensor button on the mirror surface. A short press will turn the LED lights on or off.
4.2 Adjusting Color Temperature
The mirror offers three color temperature settings: Warm (3000K), Natural (4000K), and Cold (6000K).
- With the lights on, long press the touch sensor button to cycle through the color temperatures. Release the button when your desired color is displayed.
- The mirror features a memory function that will recall your last selected color temperature when turned on again.
4.3 Anti-Fog Function
The anti-fog function activates automatically when the mirror is powered on, ensuring a clear viewing area in humid conditions. This feature is designed to keep the central portion of the mirror clear.
5. Maintenance
Proper care and maintenance will ensure the longevity and optimal performance of your TheiaMo LED Bathroom Mirror.
5.1 Cleaning the Mirror Surface
- Turn off the mirror's power before cleaning.
- Use a soft, lint-free cloth dampened with water or a mild, non-abrasive glass cleaner.
- Spray cleaner onto the cloth, not directly onto the mirror surface, especially near the edges or electrical components.
- Wipe the mirror surface gently to remove smudges and dirt.
- Dry the mirror with a clean, dry cloth to prevent streaks.
5.2 Frame Care
The aluminum frame is designed to be anti-rust and anti-oxidation. Wipe the frame with a soft, damp cloth as needed. Avoid harsh chemicals that could damage the finish.
5.3 Electrical Components
The mirror's electrical components are enclosed and rated IP65 waterproof. Do not attempt to open the mirror housing or service internal components. Refer to qualified personnel for any electrical issues.
6. Troubleshooting
If you encounter any issues with your TheiaMo LED Bathroom Mirror, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Mirror lights do not turn on. | No power supply; loose connection; faulty touch sensor. | Check if the power cord is securely plugged in or if the hardwired connection is correct. Verify the circuit breaker is on. Try pressing the touch sensor firmly. |
| Lights are dim or flickering. | Incorrect color temperature setting; power fluctuation; LED issue. | Long press the touch sensor to cycle through color temperatures and ensure it's set to the brightest option (6000K). Check power supply stability. If issues persist, contact customer support. |
| Anti-fog function not working. | Mirror not powered on; excessive humidity. | Ensure the mirror is powered on. The anti-fog function activates with the lights. While effective, extreme humidity might still cause some condensation outside the heated area. |
| Touch sensor unresponsive. | Wet hands; temporary glitch. | Ensure your hands are dry when operating the touch sensor. Try turning off power at the source for a few minutes and then restoring it to reset the mirror. |
If the problem persists after attempting these solutions, please contact TheiaMo customer support for further assistance.
7. Specifications
Detailed technical specifications for the TheiaMo 36"x24" Oval LED Bathroom Mirror:
| Feature | Description |
|---|---|
| Brand | TheiaMo |
| Model | B09NN1YKFS |
| Product Dimensions | 36"L x 24"W |
| Shape | Oval |
| Frame Material | Aluminum |
| Mirror Material | 5mm Copper-free Silver Mirror, Tempered Glass |
| Light Source | LED (120 LED beads/meter) |
| Color Temperatures | 3000K (Warm), 4000K (Natural), 6000K (Cold) |
| Special Features | Anti-Fog, Shatterproof, Memory Function, Dimmable |
| Waterproof Rating | IP65 |
| Certifications | UL Recognized (for LED components) |
| Mounting Type | Wall Mount (Horizontal/Vertical) |
| Item Weight | 18.9 Pounds |
8. Warranty and Support
TheiaMo is committed to providing high-quality products and excellent customer service.
8.1 Warranty Information
Your TheiaMo LED Bathroom Mirror is covered by a 2-Year Warranty from the date of purchase. This warranty covers manufacturing defects and issues arising from normal use. Please retain your proof of purchase for warranty claims.
8.2 Customer Support
For any questions, concerns, or technical assistance, please contact TheiaMo customer support. Our team is available for 7x24 Hours Rapid Response to assist you.
You can find more information and contact details on the official TheiaMo store page: TheiaMo Store
