1. Introduction
The Perixx PERIBOARD-732B is a compact and versatile wireless keyboard designed for efficiency and comfort. Featuring 2.4 GHz wireless connectivity, a slim profile, and bold, easy-to-read backlit keys, it is suitable for various computing environments.
Its low-profile scissor keys provide a stable, responsive, and quiet typing experience, making it ideal for a neat and minimalistic desk setup. The keyboard is equipped with a rechargeable battery for convenience.
Image: The Perixx PERIBOARD-732B keyboard positioned on a desk, highlighting its compact design for use in limited workspaces.
2. Package Contents
- Perixx PERIBOARD-732B Wireless Backlit Mini Keyboard
- USB 2.4 GHz Receiver (stored in the keyboard's battery compartment)
- USB-A to USB-C Charging Cable (2.6 ft / 800 mm)
- Instruction Manual
Image: The Perixx PERIBOARD-732B keyboard, its retail box, USB-C charging cable, and instruction manual, laid out on a surface.
3. Setup
3.1 Charging the Keyboard
Before initial use, fully charge the keyboard using the provided USB-A to USB-C charging cable. Connect the USB-C end to the keyboard's charging port and the USB-A end to a powered USB port on your computer or a USB wall adapter.
Image: The Perixx PERIBOARD-732B keyboard being charged via its USB-C port, highlighting its rechargeable battery feature.
3.2 Connecting via 2.4 GHz Wireless
- Locate the USB 2.4 GHz receiver in the keyboard's battery compartment.
- Plug the USB receiver into an available USB port on your computer.
- Turn on the keyboard using the power switch, usually located on the side or back of the keyboard.
- Your computer should automatically detect and connect to the keyboard. No additional drivers are typically required.
4. Operating Instructions
4.1 Power On/Off
Use the physical ON/OFF switch on the keyboard to power it on or off. The keyboard also features an automatic sleep mode to conserve battery life when not in use.
4.2 Backlighting
The PERIBOARD-732B features white backlighting with laser-etched keys for durability and readability. To control the backlighting:
- Press Fn + F10 to cycle through different brightness levels or turn the backlight off.
Image: A user's hands typing on the Perixx PERIBOARD-732B keyboard, demonstrating the clear and bright white backlighting of the keys.
4.3 Multimedia Shortcut Keys
The keyboard includes multimedia shortcut keys for quick access to functions like volume control, media playback, and more. These keys are primarily designed for Windows operating systems. Functionality may vary on other operating systems (macOS, Chrome OS) and will follow your system's settings.
4.4 Typing Experience
The PERIBOARD-732B utilizes high-quality scissor key mechanisms, offering a stable and responsive typing experience. The sculpted shape of the keys contributes to comfortable and accurate typing.
Image: A detailed view of the keys on the Perixx PERIBOARD-732B, emphasizing their sculpted design and the underlying X-type scissor mechanism for precise and comfortable input.
4.5 Official Product Video
Video: An official product overview of the PERIBOARD-732B Wireless Backlit Mini Keyboard by Perixx USA, showcasing its features and design.
5. Maintenance
5.1 Cleaning
To clean your keyboard, gently wipe the keys and surface with a soft, damp, lint-free cloth. Avoid using harsh chemicals, abrasive cleaners, or excessive moisture, as these can damage the keyboard.
5.2 Battery Care
To prolong the life of the rechargeable battery, avoid fully discharging it frequently. Charge the keyboard when the battery indicator light suggests low power. If storing the keyboard for an extended period, ensure it is partially charged (around 50%) and power it off.
6. Troubleshooting
6.1 Keyboard Not Connecting
- Ensure the USB 2.4 GHz receiver is securely plugged into a working USB port on your computer.
- Verify that the keyboard's power switch is in the ON position.
- Check the keyboard's battery level. Recharge if necessary.
- Try plugging the USB receiver into a different USB port on your computer.
- Restart your computer.
6.2 Backlight Not Working
- Press Fn + F10 to ensure the backlight is turned on and to cycle through brightness levels.
- Check the keyboard's battery level. The backlight may not function or may dim significantly if the battery is low.
6.3 Keys Not Responding
- Ensure the keyboard is powered on and connected (refer to section 6.1).
- Check for any physical obstructions under the keys.
- Test the keyboard on another device if possible to rule out a computer-specific issue.
7. Specifications
| Feature | Detail |
|---|---|
| Model Number | 11950 |
| Product Dimensions | 11.22"L x 4.56"W x 0.83"H (285 x 116 x 21 mm) |
| Item Weight | 0.79 lb. (361 g) / 12.3 ounces |
| Connectivity Technology | Wireless (2.4 GHz) |
| Keyboard Description | Wireless Mini Backlit scissor-switch US keyboard |
| Special Feature | Backlit |
| Color | Black |
| Keyboard Backlighting Color | Single Color (White) |
| Batteries | 1 Lithium Polymer battery (included) |
| Compatible Devices | PC (Windows 7, 8, 10), macOS, Chrome OS |
| Manufacturer | Perixx Computer GmbH |
8. Warranty and Support
The Perixx PERIBOARD-732B comes with a 12-month warranty. If you encounter any issues with the product or require technical assistance, please do not hesitate to contact Perixx customer support. Refer to the contact information provided in the packaging or on the official Perixx website for assistance.
