1. Introduction
Thank you for choosing the Sofucor 52 Inch Ceiling Fan with Light and Remote. This modern ceiling fan is designed to provide optimal airflow and lighting for various indoor spaces. It features a quiet and energy-efficient DC motor, adjustable speeds, dimmable 3-color LED lighting, and convenient remote control operation. This manual provides detailed instructions for installation, operation, maintenance, and troubleshooting to ensure safe and efficient use of your new ceiling fan.
Image: Sofucor 52 Inch Ceiling Fan with Light and Remote, including the fan unit, various downrod lengths, and the remote control.
2. What's in the Box
Please check the contents of your package to ensure all parts are included:
- 1 x DC Motor
- 3 x Fan Blades
- 1 x Remote Control
- 1 x LED Light Panel
- 1 x Lampshade
- 1 x User Manual
- 3 x Downrods (5", 10", 24")
3. Specifications
| Feature | Description |
|---|---|
| Brand | Sofucor |
| Model Name | 52 inch ceiling fan with light remote, dark wood |
| Item Model Number | KBS-52K012-BK |
| Color | Dark Wood |
| Product Dimensions | 52"D x 52"W x 11.5"H |
| Number of Blades | 3 |
| Blade Material | Wood |
| Air Flow Capacity | 5500 Cubic Feet Per Minute |
| Number of Power Levels | 6 |
| Motor Type | DC Motor (Quiet & Energy Efficient) |
| Light Type | LED (18W, 2100 lumens) |
| Color Temperatures | 3000K/4000K/6000K (Dimmable 10%-100%) |
| Control Method | Remote Control |
| Noise Level | <30 dB |
| Special Features | Remote Controlled, Quiet Operation, Adjustable Height (with downrods), Timer (1/4/8 hours), Safety Certified (ETL) |
| Indoor/Outdoor Usage | Indoor |
Image: Detailed dimensions of the Sofucor ceiling fan, illustrating the fan's width, height with different downrod lengths (5", 10", 24"), and recommended room sizes for optimal performance.
4. Setup and Installation
Most components of the Sofucor ceiling fan are pre-assembled for ease of installation. Please follow the detailed instructions provided in the included User Manual for a smooth setup process. Ensure power is disconnected at the circuit breaker before beginning installation.
Key Installation Notes:
- The fan supports both flat and sloped ceiling mounting (up to 15° slope).
- Choose the appropriate downrod (5", 10", or 24") based on your ceiling height and desired fan clearance.
- All necessary hardware is included.
For a visual guide, please refer to the official installation video:
Video: Official Sofucor installation guide for the 52 Inch Wood Ceiling Fan with Lights and Remote, demonstrating the step-by-step assembly and mounting process.
5. Operating Instructions
Your Sofucor ceiling fan comes with a multi-functional remote control for convenient operation of all features.
Fan Control:
- Speed Adjustment: Select from 6 adjustable speeds, ranging from a gentle breeze to powerful airflow (up to 5500 CFM).
- Reverse Airflow: The reversible DC motor allows for year-round use. In summer, the fan rotates counter-clockwise to create a cooling downdraft. In winter, it rotates clockwise to circulate warm air trapped near the ceiling, helping to save energy.
- Timer Function: Set the fan to automatically turn off after 1, 4, or 8 hours to conserve energy.
Image: Illustration highlighting the 6-speed adjustable DC motor and its 75% energy saving efficiency compared to ordinary motors.
Image: Diagram showing the reversible airflow function for summer (downward airflow for cooling) and winter (upward airflow for air circulation).
Light Control:
- 3-Color LED: Switch between 3 color temperatures (3000K Warm White, 4000K Natural White, 6000K Cold White) to suit your preference and mood.
- Dimmable: Adjust the brightness from 10% to 100% to create the perfect ambiance.
- Memory Function: The light features a memory function that recalls your last brightness and color temperature setting when turned back on.
Image: Visual representation of the customizable LED light, showing options for Warm White (3000K), Natural White (4000K), and Cold White (6000K), along with a dimmable brightness scale from 10% to 100%.
6. Maintenance
Regular maintenance will ensure the longevity and optimal performance of your Sofucor ceiling fan.
- Cleaning: Periodically wipe down the fan blades and motor housing with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners that could damage the finish.
- Blade Balance: If the fan wobbles, check that all blade screws are tightened and that the blades are balanced. Balancing kits are typically available if needed.
- LED Light Panel: The LED light panel is designed for long-term use. If replacement is ever needed, contact Sofucor customer support.
Image: Information regarding Sofucor's after-sales service, including lifetime free replacement for the motor and notes on obtaining free replacement accessories for the LED light board and remote control if damaged or lost.
7. Troubleshooting
If you encounter any issues with your ceiling fan, please refer to the following common troubleshooting steps:
- Fan Not Operating:
- Check if the circuit breaker is ON.
- Ensure all wiring connections are secure.
- Verify remote control batteries are fresh and correctly inserted.
- Light Not Working:
- Check light switch on remote.
- Ensure LED light panel is properly connected.
- Excessive Noise:
- Confirm all screws on the motor housing and blades are tight.
- Check for any loose parts or obstructions.
- Ensure the fan is properly balanced.
- Remote Control Issues:
- Replace remote batteries.
- Ensure there are no obstructions between the remote and the fan receiver.
If problems persist, please contact Sofucor customer support for assistance.
8. Warranty and Support
Sofucor stands behind the quality of its products. Your ceiling fan is covered by the following:
- Lifetime Motor Maintenance: Enjoy peace of mind with lifetime maintenance for the fan motor.
- 3-Year Protection Plan for Accessories: Accessories are covered by a 3-year protection plan.
Our technical team is available to assist you within 24 hours. For any inquiries or support, please refer to the contact information provided in your original purchase documentation or visit the official Sofucor website.
