Ematic PBS KIDS 150" HD Video Projector + HDMI Streaming Stick (EPBS520P) User Manual

1. Important Safety Instructions

Please read all instructions carefully before using this product and retain them for future reference. Failure to follow these instructions may result in electric shock, fire, or other hazards.

• Do not expose the projector to rain or moisture to prevent fire or electric shock.
• Do not block any ventilation openings. Ensure adequate space around the projector for proper airflow.
• Use only attachments/accessories specified by the manufacturer.
• Unplug the projector during lightning storms or when unused for long periods.
• Refer all servicing to qualified service personnel. Do not attempt to open or repair the device yourself.
• Keep the projector away from direct sunlight, heat sources, and extreme temperatures.
• Avoid looking directly into the projector lens when the lamp is on, as it can cause eye damage.

2. Package Contents

Carefully unpack your projector and check that all the items listed below are included and in good condition. If any items are missing or damaged, please contact customer support.

• PBS KIDS 150" Multimedia Projector
• Projector Remote Control
• PBS KIDS Plug & Play HDMI Streaming Stick
• Streaming Stick Remote Control
• Lens Cover
• AC Power Adapter
• User Manual
• Quick Start Guide
• Warranty Card
• CYA Warranty Card

This image displays the main components included in the package: the projector, its remote, the PBS KIDS HDMI Streaming Stick (designed as a green race car), and the streaming stick's remote. It also highlights key specifications for both devices.

3. Product Overview

The Ematic PBS KIDS 150" HD Video Projector is designed for easy media playback and streaming. Familiarize yourself with the projector's various ports and controls.

Projector Components

• Projection Lens: Projects the image onto the screen.
• Focus Ring: Adjusts image clarity.
• Keystone Correction: Adjusts image distortion.
• Control Panel: Buttons for basic navigation and settings.
• HDMI Port: Connects to HDMI-enabled devices, including the PBS KIDS Streaming Stick.
• VGA Port: Connects to computers or other VGA-enabled devices.
• USB Port: For playing media from USB drives (up to 1000GB).
• Micro SD Card Slot: For playing media from Micro SD cards.
• 3.5mm Headphone Jack: For connecting external audio devices.
• AC Power Input: Connects to the power adapter.

This image provides a clear front view of the PBS KIDS HD Video Projector, highlighting its main projection lens and the distinctive teal color of its casing.

4. Setup

4.1 Power Connection

1. Connect the AC power adapter to the projector's AC power input port.
2. Plug the other end of the power adapter into a standard electrical outlet.
3. Press the power button on the projector or remote control to turn on the device.

4.2 Connecting the PBS KIDS HDMI Streaming Stick

1. Insert the PBS KIDS HDMI Streaming Stick into an available HDMI port on the projector.
2. Ensure the streaming stick is securely connected.
3. Use the projector's input source selection to switch to the corresponding HDMI input.

4.3 Connecting Other Devices

• HDMI Devices: Connect other HDMI devices (e.g., game consoles, Blu-ray players) to an available HDMI port. Select the correct HDMI input source.
• VGA Devices: Connect a computer or laptop using a VGA cable to the VGA port. Select the VGA input source.
• USB Drives: Insert a USB flash drive into the USB port. The projector's media player will typically detect it automatically.
• Micro SD Cards: Insert a Micro SD card into the Micro SD card slot. The projector's media player will typically detect it automatically.

4.4 Focus and Keystone Adjustment

• Focus: Rotate the focus ring around the lens until the projected image appears clear and sharp.
• Keystone: If the projected image appears distorted (wider at the top or bottom), use the keystone correction dial or setting to adjust it until the image is rectangular.

5. Operating the Projector

5.1 Using the Projector Remote Control

The included remote control allows you to navigate menus, select input sources, adjust volume, and control media playback from a distance.

• Power Button: Turns the projector on/off.
• Source Button: Cycles through input sources (HDMI1, HDMI2, VGA, USB, Micro SD).
• Navigation Buttons (Up/Down/Left/Right): Move through menu options.
• OK/Enter Button: Confirms selections.
• Menu Button: Accesses projector settings.
• Volume Buttons: Adjusts the audio output level.

5.2 Navigating the Projector Interface

Once powered on, the projector will display its main menu. Use the remote or control panel buttons to select your desired function:

• Media Player: For playing videos, photos, and music directly from USB drives or Micro SD cards.
• Input Source Selection: Choose between HDMI, VGA, USB, or Micro SD inputs.
• Settings: Adjust image, sound, time, and other system preferences.

5.3 Using the PBS KIDS HDMI Streaming Stick

The PBS KIDS HDMI Streaming Stick provides access to a wealth of kid-friendly content. Ensure it is connected to an HDMI port and the projector is set to the correct HDMI input.

1. Power On: The streaming stick powers on automatically when the projector is on and the HDMI input is selected.
2. Connect to Wi-Fi: Using the streaming stick's remote, navigate to the network settings and connect to your home Wi-Fi network.
3. Access Content: Once connected, you can access the built-in 24/7 live TV channel, video clips, episodes, songs, and games provided by PBS KIDS.
4. Navigation: Use the streaming stick's remote control to browse and select content.

6. Maintenance

Proper maintenance ensures the longevity and optimal performance of your projector.

• Lens Cleaning: Use a soft, lint-free cloth specifically designed for optical lenses to gently wipe the projector lens. Do not use abrasive cleaners or cloths.
• Dust Removal: Periodically clean the projector's exterior with a soft, dry cloth. Ensure ventilation openings are free from dust and debris.
• Bulb Life: The LED bulb has an estimated life of 20,000 hours. No user replacement is typically required for the life of the product.
• Storage: When not in use, store the projector in a cool, dry place, away from direct sunlight and extreme temperatures. Use the lens cover to protect the lens.

7. Troubleshooting

If you encounter issues with your projector, refer to the following common problems and solutions:

• No Power:
  Solution: Ensure the power adapter is securely connected to both the projector and a working electrical outlet. Try a different outlet.
• No Image:
  Solution: Check if the projector is powered on. Verify that the correct input source is selected (e.g., HDMI1, VGA). Ensure the connected device is also powered on and outputting a signal.
• Blurry Image:
  Solution: Adjust the focus ring on the projector lens until the image is clear. If the image is distorted, adjust the keystone correction.
• No Sound:
  Solution: Check the volume settings on both the projector and the connected source device. Ensure no headphones are connected if you expect sound from the internal speakers.
• Streaming Stick Not Connecting to Wi-Fi:
  Solution: Ensure your Wi-Fi network is active and within range. Double-check the Wi-Fi password. Restart the streaming stick and your router.
• Remote Control Not Working:
  Solution: Replace the batteries in the remote control. Ensure there are no obstructions between the remote and the projector's IR receiver.

8. Specifications

Detailed technical specifications for the Ematic PBS KIDS 150" HD Video Projector (EPBS520P).

9. Warranty and Support

This product is covered by a limited warranty. Please refer to the included Warranty Card for specific terms and conditions regarding coverage, duration, and claims procedures. Retain your proof of purchase for warranty service.

For technical support, troubleshooting assistance, or warranty inquiries, please contact Ematic customer service. Contact information can typically be found on the manufacturer's official website or on the included warranty documentation.
