Introduction
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Koda 32-inch 50W Slim Oval LED Ceiling Light Fixture. Please read these instructions thoroughly before beginning installation or use, and retain this manual for future reference.
Image: The Koda 32-inch Slim Oval LED Ceiling Light illuminates a modern dining room, showcasing its sleek design and bright output.
Safety Information
- Electrical Safety: Always turn off power at the circuit breaker before installation, removal, or servicing. Consult a qualified electrician if you are unsure about wiring procedures.
- Installation: Ensure the mounting surface can support the weight of the fixture. Follow all local electrical codes and ordinances.
- Handling: Handle the fixture with care to prevent damage. Do not attempt to modify the fixture.
- Usage: This fixture is designed for indoor use only. Do not expose to moisture or extreme temperatures.
Package Contents
Verify that all components are present before beginning installation:
- 1 x Koda 32-inch Slim Oval LED Ceiling Light Fixture
- 1 x Installation Kit (includes mounting screws, wire nuts, etc.)
Image: The Koda LED Ceiling Light and its accompanying installation hardware, including screws and wire nuts, are displayed.
Product Features
- Bright LED Light: Provides 3500 lumens of clear and bright light.
- Adjustable Color Temperature: Easily switch between 2700K (warm white) and 4000K (natural white) light.
- Slim Modern Flush Mount Design: Only 1.5 inches thick for a sleek, low-profile appearance.
- Energy Efficient: ENERGY STAR certified, using 90% less energy and lasting up to 15 times longer than traditional bulbs.
- Dimmable: Compatible with standard dimmer switches for adjustable brightness levels.
Image: An infographic highlighting the key features of the Koda LED Ceiling Light, such as adjustable color temperature (4000K Natural White, 2700K Warm White), 3500 lumens, and LED technology.
Specifications
| Attribute | Detail |
|---|---|
| Brand | Koda |
| Model Name | LM Ceiling light |
| Size | 32 inches |
| Wattage | 50 watts |
| Brightness | 3500 Lumens |
| Color Temperature | 2700K (Warm White), 4000K (Natural White) |
| Material | Plastic, Glass |
| Installation Type | Flush Mount |
| Power Source | Corded Electric |
| Voltage | 120 Volts |
| Indoor/Outdoor Usage | Indoor |
| Special Feature | Energy Efficient |
Installation Guide
Before starting, ensure the power is turned off at the circuit breaker.
Tools Required (Not Included):
- Screwdriver
- Wire strippers
- Drill (if needed for mounting screws)
- Safety glasses
Installation Steps:
- Install Mounting Plate: Secure the mounting plate to the ceiling junction box using the provided screws. Ensure it is firmly attached.
- Connect Wire Hooks: Attach the wire hooks from the ceiling light fixture to the mounting plate. This will temporarily hold the fixture while you make electrical connections.
- Make Electrical Connections: Using wire nuts, connect the wires from the ceiling light to the corresponding wires from the junction box. Connect green (ground) to ground, white (neutral) to neutral, and black (hot) to hot. Ensure all connections are secure.
- Secure Fixture: Gently push the connected wires into the junction box. Align the ceiling light with the mounting plate and slide it into place, ensuring the arrow label on the fixture matches the direction of the label on the mounting plate. Secure the fixture to the mounting plate.
Image: A visual guide illustrating the five steps for installing the Koda LED Ceiling Light, from mounting the plate to connecting wires and securing the fixture.
Video: Official Koda installation guide for the 32-inch Slim Oval LED Ceiling Light (LM030061), demonstrating the step-by-step process for secure mounting and wiring.
Operating Instructions
Adjusting Color Temperature:
The Koda LED Ceiling Light allows you to switch between two color temperatures: 2700K (warm white) and 4000K (natural white). To change the color temperature, simply flip your standard wall light switch OFF for 1 second, then back ON. The light will cycle to the next available color temperature.
Image: A hand operates a wall switch, demonstrating how to toggle between warm and cool white light settings on the Koda LED Ceiling Light.
Dimming:
This fixture is compatible with most standard dimmer switches. To adjust the brightness, use your existing dimmer switch. Ensure your dimmer switch is compatible with LED lighting for optimal performance.
Video: A demonstration of the Koda 32-inch Slim Oval LED Ceiling Light (LM030061) in operation, showcasing its bright output and adjustable color temperature feature.
Maintenance
To maintain the appearance and performance of your Koda LED Ceiling Light, follow these simple guidelines:
- Cleaning: Ensure the power is off before cleaning. Wipe the fixture with a soft, dry, or slightly damp cloth. Do not use abrasive cleaners, solvents, or polishes as they may damage the finish.
- Bulb Replacement: The LED components are integrated and not user-replaceable. The fixture is designed for long-term use.
Troubleshooting
If you encounter issues with your Koda LED Ceiling Light, refer to the table below for common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on | No power, loose wiring, faulty switch | Check circuit breaker. Verify all wire connections are secure. Test the wall switch. |
| Light flickers | Incompatible dimmer, loose wiring | Ensure dimmer is LED compatible. Check wire connections. |
| Color temperature does not change | Incorrect switch operation | Flip the light switch OFF for 1 second, then ON again. Repeat if necessary. |
Warranty and Support
For warranty information or technical support, please refer to the documentation included with your product or visit the official Koda website. You can also visit the Koda Store on Amazon for additional resources and contact options.
