Product Overview
The TAISHAN UV Sanitizer Toothbrush Case provides deep sanitization for your toothbrush, promoting oral hygiene. This rechargeable, portable device is designed to fit various toothbrush types, including electric and manual models. It features a drying function to inhibit bacterial growth and a safety mechanism to prevent cross-contamination when used as a single-person holder. The compact design makes it suitable for both home and travel use.
The TAISHAN UV Sanitizer Toothbrush Case is designed for daily use to maintain oral hygiene for the entire family.
Setup Instructions
1. Initial Charging
Before first use, fully charge the device. Connect the provided USB cable to the charging port on the side of the unit and to a suitable USB power source. A full charge typically takes approximately 2 hours and provides power for up to 12 days of use.
Locate the USB charging port on the side of the device for initial charging.
2. Wall Mounting (Optional)
The toothbrush case can be mounted on a bathroom wall using the strong adhesive sticker provided. Ensure the wall surface is clean and dry before application. Apply the adhesive to the wall, then attach the toothbrush holder. The design allows for easy removal and reattachment of the unit from the wall-mounted sticker.
Illustration of wall mounting using the adhesive sticker. Only one magnet needs to be stuck to the wall.
3. UV Test Card
A UV test card is included to verify the authenticity and function of the UV light. Follow the instructions on the test card to confirm the UV sanitization is active.
Operating Instructions
1. Inserting Your Toothbrush
Open the case and insert your toothbrush head into the designated slot. The case is compatible with various toothbrush heads, including those from electric and manual toothbrushes.
The case accommodates both electric and manual toothbrush heads.
2. Starting the Sanitization Cycle
Close the case. The UV sanitization cycle will automatically begin and run for 3 minutes. The device will then automatically shut off. This process provides deep sanitization and includes a drying function to prevent bacterial growth.
The device performs automatic disinfection for 3 minutes upon closing.
The 360-degree sterilization effectively cleans your toothbrush.
Maintenance
1. Cleaning the Device
The silicone area where the toothbrush sits can be removed for cleaning. Wash this component regularly with mild soap and water, then allow it to dry completely before reinserting. Wipe the exterior of the case with a soft, damp cloth as needed.
2. Recharging
Recharge the device when the battery indicator shows low power or after approximately 12 days of use. Consistent charging helps maintain battery longevity.
Troubleshooting
Device Not Charging
- Ensure the USB cable is securely connected to both the device and the power source.
- Try using a different USB cable or power adapter to rule out a faulty accessory.
- Inspect the USB charging port on the device for any visible damage or debris.
Molding or Odor Inside the Case
- Regularly remove and clean the silicone insert with soap and water.
- Ensure the toothbrush head is not excessively wet when placed in the case. While the device has a drying function, excessive moisture can still contribute to issues.
- Ensure the case is not stored in an overly humid environment.
Sanitization Light Not Activating
- Ensure the device is fully charged.
- Confirm the case is closed properly. The sanitization cycle only begins when the case is securely shut.
- Use the provided UV test card to verify UV light functionality.
Specifications
| Feature | Detail |
|---|---|
| Brand | TAISHAN |
| Model Number | BX-100 |
| Material | Plastic |
| Color | Black |
| Product Dimensions (L x W x H) | 6" x 2.9" x 2.5" |
| Item Weight | 3.17 ounces |
| Mounting Type | Wall Mount |
| Unit Count | 1 Count |
| Charging Time | Approx. 2 hours |
| Battery Life | Up to 12 days per charge |
| Sanitization Cycle Duration | 3 minutes (automatic shut-off) |
Warranty Information
Warranty information for the TAISHAN UV Sanitizer Toothbrush Case BX-100 is not provided within this manual. Please refer to the product packaging or contact the manufacturer directly for details regarding warranty coverage.
Customer Support
Customer support contact information for the TAISHAN UV Sanitizer Toothbrush Case BX-100 is not provided within this manual. For assistance, please refer to the product packaging or the retailer's website where the product was purchased.
