1. Introduction
The Skip Hop Eon 4-in-1 High Chair is designed to grow with your child, offering four distinct modes of use: High Chair, Dining Booster, Tableside Booster, and Big Kid Chair. This manual provides essential information for safe assembly, operation, and maintenance of your product.
Image: A baby seated in the Skip Hop Eon 4-in-1 High Chair, configured as a traditional high chair, with a tray attached.
2. Safety Information
WARNING: Failure to follow these warnings and instructions could result in serious injury or death.
- Always secure the child in the restraint system.
- Never leave child unattended.
- Always use the restraint system and ensure it is correctly fitted.
- Ensure the high chair is fully assembled and all locking mechanisms are engaged before use.
- Do not use the high chair if any components are broken or missing.
- Keep children away from the product during assembly and disassembly.
- Do not place the high chair near open flames or other heat sources.
- Do not use the high chair on an elevated surface.
- Age and Weight Limits:
- High Chair: 6 months to 3 years (up to 33 lbs / 15 kg)
- Booster Seat (with harness): 6 months and up
- Booster Seat (without harness): 3 years and up
- Big Kid Chair: Up to 5 years (supports up to 80 lbs / 36 kg)
3. Product Features
The Skip Hop Eon 4-in-1 High Chair offers several features designed for convenience and adaptability:
- 4-in-1 Versatility: Converts between High Chair, Dining Booster, Tableside Booster, and Big Kid Chair modes.
- Easy Cleaning: Features smooth, wipe-clean surfaces and a detachable, adjustable tray with a dishwasher-safe insert.
- Secure Harness: Includes a removable 5-point harness for child safety.
- Adjustable Footrest: Equipped with a 2-position footrest for comfort.
- Modern Design: Incorporates beechwood accents for a contemporary aesthetic.
Image: Detailed views of the high chair's key features, including the harness, tray, footrest, and wooden leg accents.
4. Assembly Instructions
Assembly of the Skip Hop Eon 4-in-1 High Chair is required before first use. Please refer to the detailed assembly guide included in your product packaging for step-by-step instructions and diagrams. Ensure all parts are present and undamaged before beginning assembly. Use only original manufacturer parts.
General Assembly Steps (Refer to detailed guide for specifics):
- Unpack all components and verify against the parts list.
- Attach the legs to the seat unit, ensuring they click securely into place.
- Install the footrest onto the legs at the desired position.
- Attach the tray to the seat unit.
- Ensure the 5-point harness is correctly threaded and secured.
- Test the stability of the assembled unit before placing a child in it.
5. Usage Modes
The Eon 4-in-1 High Chair transitions through four stages to accommodate your child's growth:
Image: Visual representation of the high chair transforming into its four different modes.
5.1. Stage 1: High Chair
This mode is suitable for infants aged 6 months to 3 years, up to 33 lbs (15 kg). It provides a secure and elevated seating position for feeding with the included tray.
Image: A baby seated in the high chair mode, ready for mealtime.
5.2. Stage 2: Dining Booster
For children 6 months and up, this mode allows the seat to be securely attached to an adult dining chair, bringing your child closer to the family table. The 5-point harness must be used in this mode.
Image: A baby in the dining booster seat, secured to a standard dining chair.
5.3. Stage 3: Tableside Booster
Designed for children 3 years and up, this booster mode can be used without the harness, allowing older toddlers to sit comfortably at the table. Ensure the booster is securely fastened to the adult chair.
Image: A toddler using the tableside booster seat at a dining table.
5.4. Stage 4: Big Kid Chair
This final stage converts the high chair into a standalone chair suitable for children up to 5 years old, supporting up to 80 lbs (36 kg). It provides a comfortable seating option for various activities.
Image: A child seated in the big kid chair mode, suitable for older children.
6. Operating Instructions
6.1. Attaching and Removing the Tray
- To attach the tray, align the tray guides with the slots on the seat unit and push until it clicks into place.
- To adjust the tray position, locate the release button (usually on the front or underside) and slide the tray forward or backward.
- To remove the tray, press the release button and pull the tray away from the seat.
6.2. Using the 5-Point Harness
- Place your child in the seat.
- Bring the shoulder straps over your child's shoulders and the waist straps around their waist.
- Connect the shoulder straps to the waist straps, then insert the buckles into the central buckle until they click.
- Adjust the straps to ensure a snug but comfortable fit. There should be no more than one finger's width of slack.
- To release, press the button on the central buckle.
6.3. Adjusting the Footrest
The footrest has two positions. To adjust, locate the adjustment mechanism on the sides of the footrest and slide it to the desired height. Ensure both sides are adjusted evenly and securely locked.
7. Cleaning and Maintenance
Regular cleaning and maintenance will prolong the life of your high chair.
- Seat and Frame: Wipe clean with a damp cloth and mild soap. Do not use abrasive cleaners or solvents.
- Tray Insert: The tray insert is dishwasher-safe. Remove it from the main tray and place it on the top rack of your dishwasher.
- Harness Straps: The harness straps are not machine washable. Spot clean with a damp cloth and mild soap. Allow to air dry completely before reassembly or use.
- Wood Components: Wipe clean with a damp cloth. Avoid prolonged exposure to moisture.
- Storage: Store the high chair in a clean, dry place away from direct sunlight and extreme temperatures.
8. Troubleshooting
If you encounter issues with your high chair, please refer to the following common solutions:
| Problem | Possible Solution |
|---|---|
| High chair feels unstable. | Ensure all legs are fully inserted and locked. Check that the floor surface is even. |
| Tray is difficult to attach or remove. | Ensure the release button is fully pressed. Check for any food debris or obstructions in the tracks. |
| Harness straps are too tight or too loose. | Adjust the strap length using the adjusters on each strap. Refer to section 6.2 for proper harness use. |
| Child is sliding or slumping in the seat (especially younger/smaller babies). | Ensure the child meets the minimum age and weight requirements for the high chair mode. For smaller babies, additional padding (not included) may be used for support, but always ensure the harness remains snug and secure. |
If you continue to experience issues, please contact Skip Hop customer support.
9. Specifications
| Attribute | Detail |
|---|---|
| Model Number | 9M494410 |
| Product Dimensions (High Chair) | 67.1D x 69.6W x 91.4H cm (26.4L x 27.4D x 36H inches) |
| Product Dimensions (Booster Seat) | 42.6L x 35D x 40.6H cm (16.8L x 13.8D x 16H inches) |
| Product Dimensions (Big Kid Chair) | 48L x 44.4D x 61H cm (18.9L x 17.5D x 24H inches) |
| Item Weight | 5.4 kg |
| Maximum Weight Recommendation | 14.97 kg (High Chair), 36 kg (Big Kid Chair) |
| Materials | Polypropylene, Polyoxymethylene, Acrylonitrile Butadiene Styrene, Nylon, Polyethylene, Glass Fiber, Thermoplastic Elastomers, Steel, Polyester, Beech Wood, Paper |
| Country of Origin | China |
| UPC | 194135799806 |
10. Warranty and Support
For warranty information, please refer to the warranty card included with your product or visit the official Skip Hop website. If you have any questions, require assistance, or need to report a missing or damaged part, please contact Skip Hop customer support directly.
Contact Information:
- Visit the Skip Hop Store on Amazon for product information.
- Refer to your product packaging for specific customer service contact details.
