i-box MiniGlow Alarm Clock Radio with LED Night Light

1. Introduction

Thank you for choosing the i-box MiniGlow Alarm Clock Radio. This device combines a large LED display with dimmable brightness, dual alarms, a night light function, a USB charging port, FM radio, and a modern textile finish. Its compact design makes it ideal for bedside tables. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your device.

Please read this manual carefully before use and retain it for future reference.

2. Package Contents

• i-box MiniGlow Alarm Clock Radio
• Power Adapter
• CR2025 Button Cell Battery (pre-installed for backup)
• User Manual

3. Device Overview

Familiarize yourself with the main components and controls of your i-box MiniGlow.

Image: Front view of the i-box MiniGlow Alarm Clock Radio, showing the large LED display and top controls. This image provides a general overview of the product's appearance.

Controls and Ports:

• LED Display: Shows time, alarm status, and radio frequency.
• Top Buttons: For setting time, alarms, radio, night light, and sound modes.
• Volume/Tuning Knob: Adjusts volume and tunes FM radio frequencies.
• USB Charging Port: Located on the side/back for charging external devices.
• Power Input: For connecting the power adapter.

4. Setup

4.1 Power Connection

1. Connect the provided power adapter to the DC input port on the back of the i-box MiniGlow.
2. Plug the adapter into a standard wall outlet. The display will light up.

4.2 Backup Battery

The device includes a pre-installed CR2025 button cell battery to maintain time and alarm settings during a power outage. No action is required for initial setup regarding this battery.

4.3 Setting the Time

1. Press and hold the Time Set button (usually marked with a clock icon) until the hour digits flash.
2. Use the +/- buttons or the tuning knob to adjust the hour.
3. Press the Time Set button again to confirm the hour, and the minute digits will flash.
4. Use the +/- buttons or the tuning knob to adjust the minutes.
5. Press the Time Set button one last time to save the time.

5. Operating Instructions

5.1 Setting Alarms (Dual Alarm Feature)

The i-box MiniGlow supports two independent alarms.

Image: The i-box MiniGlow on a bedside table, illustrating its dual alarm capability for different wake-up times. This image highlights the convenience of setting two separate alarms.

1. Press and hold the Alarm 1 or Alarm 2 button until the alarm time flashes.
2. Use the +/- buttons or the tuning knob to set the desired hour. Press the alarm button again to confirm.
3. Use the +/- buttons or the tuning knob to set the desired minutes. Press the alarm button again to confirm.
4. Select the alarm source (Buzzer, FM Radio, or White Noise/Nature Sound) using the +/- buttons. Press the alarm button again to confirm.
5. To activate/deactivate an alarm, short press the corresponding Alarm 1 or Alarm 2 button. An alarm icon will appear/disappear on the display.

5.2 FM Radio Operation

Enjoy your favorite FM radio stations with up to 10 presets.

Image: The i-box MiniGlow displaying an FM radio frequency, indicating its radio functionality. This image shows the device in a typical bedroom setting.

1. Press the FM button to turn on the radio.
2. Auto Scan: Press and hold the FM button to automatically scan and save available stations.
3. Manual Tuning: Use the tuning knob to manually adjust the frequency.
4. Saving Presets: While listening to a station, press and hold a Preset button (e.g., P1-P10) until the preset number flashes. Use the +/- buttons to select a preset number, then press the Preset button again to save.
5. Recalling Presets: Short press the Preset button to cycle through saved stations.
6. Sleep Timer: While the radio is playing, press the Sleep button repeatedly to set a sleep timer (e.g., 15, 30, 60, 90 minutes). The radio will turn off automatically after the set time.

5.3 Night Light and RGB Mood Lighting

The integrated night light offers adjustable brightness and multiple color options.

Image: Multiple i-box MiniGlow units displaying different RGB mood lighting colors. This image demonstrates the range of color options available for the night light.

1. Press the Light button to turn on the night light.
2. Press the Light button repeatedly to cycle through 6 different RGB colors or a continuous color cycle.
3. To select a static color during the color cycle, press the Light button when the desired color is displayed.
4. To adjust the brightness of the night light, use the Dimmer button (if available) or refer to the specific light control buttons.
5. To turn off the night light, continue pressing the Light button until it switches off.

5.4 White Noise and Natural Sounds

Choose from 6 relaxing white noise and natural sound tracks to aid sleep.

Image: The i-box MiniGlow on a bedside table with a purple night light, suggesting its white noise and natural sounds feature for peaceful sleep. This image shows the device in a nighttime setting.

1. Press the Sound button (often marked with a musical note or wave icon) to activate the white noise/natural sound mode.
2. Press the Sound button repeatedly to cycle through the 6 available sound tracks.
3. Adjust the volume using the Volume knob.
4. To turn off the sound, press the Sound button until it stops, or use the Power button.

5.5 USB Charging Port

Charge your smartphone or smartwatch conveniently.

Image: The i-box MiniGlow on a bedside table with a smartphone connected to its built-in USB charging port. This image demonstrates the convenience of charging devices directly from the alarm clock.

Connect your device's USB charging cable to the USB output port on the i-box MiniGlow. The device will begin charging automatically. Ensure your i-box MiniGlow is connected to a power source for this function to work.

5.6 Display Dimmer

Adjust the brightness of the LED time display for comfortable viewing in any lighting condition.

1. Press the Dimmer button (often marked with a sun icon) repeatedly to cycle through different brightness levels (e.g., High, Medium, Low, Off).
2. Select the desired brightness level.

6. Maintenance

6.1 Cleaning

• Always unplug the device from the power outlet before cleaning.
• Use a soft, dry cloth to wipe the exterior surfaces.
• Do not use liquid cleaners, abrasive cleaners, or sprays, as these may damage the finish or internal components.

6.2 Battery Replacement (Backup Battery)

The CR2025 backup battery typically lasts for several years. If you notice that time and alarm settings are lost after a power outage, the backup battery may need replacement.

1. Unplug the device from the main power supply.
2. Locate the battery compartment on the bottom of the unit.
3. Open the compartment and carefully remove the old CR2025 battery.
4. Insert a new CR2025 battery with the correct polarity (+ side up).
5. Close the battery compartment and reconnect the device to power.

7. Troubleshooting

8. Specifications

9. Warranty and Support

The i-box MiniGlow Alarm Clock Radio comes with a 12-month limited warranty. Please retain your proof of purchase for warranty claims.

For technical support, troubleshooting assistance, or warranty inquiries, please refer to the contact information provided in your product packaging or visit the official i-box website.

Online Resources: For additional support and FAQs, please visit the i-box Brand Store.
