1. Introduction
The ABUS HomeTec Pro CFF3100 Bluetooth Remote Control is designed to provide convenient, keyless access to your home when used in conjunction with the ABUS HomeTec Pro Bluetooth CFA3100 electronic door lock actuator. This remote control allows you to lock, unlock, and open your door with a simple press of a button, enhancing ease of entry and exit.
2. Product Features
- Compatibility: Exclusively designed for use with the ABUS HomeTec Pro Bluetooth CFA3100 electronic door lock actuator.
- Keyless Operation: Lock, unlock, and open your door remotely with dedicated buttons.
- Status Indication: Query the current status of your door lock (locked or unlocked) via an integrated LED indicator. A green light indicates locked, while a red light indicates unlocked.
- Multi-Device Control: Capable of controlling up to two separate HomeTec Pro Bluetooth CFA3100 door lock actuators simultaneously.
- Battery Powered: Operates on one CR2032 3V button cell battery. Battery status can be monitored via the associated ABUS application.
- Enhanced Security: Features AES 128-bit encryption for secure communication between the remote control and the door lock actuator.
3. Setup and Pairing
3.1 Battery Installation
The remote control comes with one CR2032 3V button cell battery. To install or replace the battery:
- Locate the battery compartment cover on the back of the remote control.
- Carefully open the cover using a small tool or coin.
- Insert the CR2032 battery with the positive (+) side facing upwards.
- Close the battery compartment cover securely.
3.2 Pairing with HomeTec Pro CFA3100
Before using the remote control, it must be paired with your ABUS HomeTec Pro Bluetooth CFA3100 electronic door lock actuator. Ensure the CFA3100 is already installed and operational.
Image 1: ABUS HomeTec Pro CFF3100 Bluetooth Remote Control. This image shows the black remote control with two distinct buttons, one for locking and one for unlocking, and a keyring attachment at the bottom.
The remote control includes an ABUS card for the pairing process. Follow the specific pairing instructions provided with your HomeTec Pro Bluetooth CFA3100 actuator and the remote control. Generally, this involves activating a pairing mode on the CFA3100 and then initiating pairing from the remote control using the ABUS card.
4. Operation
4.1 Locking and Unlocking the Door
- To lock the door: Press the top button (lock symbol) once.
- To unlock the door: Press the bottom button (unlock symbol) once.
- To open the door (fully retract the latch): Press the bottom button (unlock symbol) twice in quick succession.
Image 2: A person holding the ABUS remote control, pointing it towards a modern glass door, indicating remote operation from outside the building.
4.2 Checking Door Status
To determine if the door is currently locked or unlocked:
- Press both the lock and unlock buttons simultaneously.
- Observe the LED indicator on the remote control:
- A green light indicates the door is locked.
- A red light indicates the door is unlocked.
Image 3: A person holding the ABUS remote control, standing inside what appears to be a garage or entryway, operating a door remotely.
4.3 Controlling Multiple Actuators
If configured, your remote control can manage up to two different HomeTec Pro Bluetooth CFA3100 actuators. The method for switching between or assigning control to different actuators will be detailed in the specific pairing instructions for your setup.
5. Maintenance
5.1 Battery Replacement
When the battery level is low, the remote control's performance may degrade, or the LED indicator might behave erratically. Replace the CR2032 battery as described in Section 3.1.
5.2 Cleaning
Clean the remote control with a soft, dry cloth. Do not use abrasive cleaners or solvents, as these can damage the surface or internal components.
6. Troubleshooting
- Remote not responding: Check the battery. Ensure you are within Bluetooth range of the CFA3100 actuator. Re-pair the remote if necessary.
- Incorrect door status indication: Ensure the CFA3100 actuator is properly calibrated and functioning correctly. Re-query the status by pressing both buttons simultaneously.
- Pairing issues: Refer to the detailed pairing instructions provided with your ABUS HomeTec Pro system. Ensure both devices are in pairing mode.
7. Specifications
| Specification | Detail |
|---|---|
| Model Number | CFF3100 |
| Dimensions (L x W x H) | 6.3 x 3 x 1.1 cm |
| Weight | 61 grams |
| Color | Black |
| Material | Plastic |
| Connectivity | Bluetooth |
| Battery Type | 1 x CR2032 3V Button Cell |
| Encryption | AES 128-bit |
| Compatibility | ABUS HomeTec Pro Bluetooth CFA3100 |
8. Warranty and Support
For warranty information, technical support, or further assistance, please refer to the documentation included with your ABUS HomeTec Pro system or visit the official ABUS website. Contact details for customer service can typically be found there.
