Deerma 250ml Touchless Auto-Sensing Soap Dispenser User Manual
Model: XS100
Product Overview
The Deerma XS100 is a 250ml touchless auto-sensing soap dispenser designed for hygienic and convenient hand washing. It features an infrared sensor for automatic dispensing, eliminating the need for physical contact and reducing the risk of cross-contamination. This battery-operated unit is suitable for various environments, including kitchens and bathrooms, and can be used on a countertop or mounted on a wall.
Figure 1: The Deerma XS100 touchless dispenser (left) prevents secondary infection compared to traditional manual pump dispensers (right).
Key features include:
- Automatic Touchless Operation: Built-in infrared sensor for hands-free dispensing.
- Versatile Placement: Can be used as a desktop unit or wall-mounted to save space.
- Energy Efficient: Powered by 2 AA batteries (not included).
- Optimal Capacity: 250ml reservoir, providing approximately 200 uses per fill.
- Durable Material: Constructed from ABS plastic, which is waterproof and easy to clean.
Figure 2: The Deerma XS100 is suitable for use in multiple locations such as hospitals, schools, kitchens, and offices.
Setup and Installation
Follow these steps to set up your Deerma XS100 soap dispenser for first use.
- Install Batteries: Open the battery compartment. Insert two "AA" batteries, ensuring correct polarity (+/-). Close the battery cover securely.
- Fill with Soap Liquid: Open the top lid of the dispenser. Carefully pour your preferred liquid soap into the tank, ensuring not to exceed the "Max" fill line. Close the lid properly.
- Power On: Locate the power switch, typically at the bottom or rear of the unit. Turn the switch to the "I" position to start the product.
- Initial Dispensing: Place your hand under the infrared sensing area. The dispenser will activate and dispense liquid soap. It may take a few seconds for the liquid to prime and dispense on the first use.
Figure 3: Step-by-step guide for convenient operation, including battery installation, soap filling, power activation, and hand sensing.
Placement Options
The Deerma XS100 offers flexible placement options:
- Desktop Use: Simply place the dispenser on any flat surface, such as a kitchen counter or bathroom vanity. No installation required.
- Wall-Mounted: For space-saving, the dispenser can be mounted on a wall. Note: Hanging panel and other setting tools are not included with the product.
Figure 4: The dispenser can be placed on a desk or wall-mounted to suit your needs.
Operating Instructions
The Deerma XS100 is designed for simple and efficient operation.
To dispense soap, simply place your hand directly under the nozzle. The built-in infrared sensor will detect your hand within a sensing area of 0-10 cm and automatically dispense approximately 1.2-1.5g of liquid soap. The dispensing process is quick, typically taking about 1.4 seconds.
Figure 5: Place your hand under the sensor for automatic soap dispensing.
Figure 6: The infrared sensor detects hands within 0-10 cm, dispensing soap in approximately 1.4 seconds.
Maintenance
Proper maintenance ensures the longevity and optimal performance of your Deerma XS100 soap dispenser.
Cleaning
The dispenser is made of ABS material and has an IPX5 waterproof rating, making it easy to clean. Wipe the exterior with a soft, damp cloth. Do not submerge the unit in water or use abrasive cleaners.
Figure 7: The dispenser is waterproof (IPX5) and made of easy-to-clean ABS material.
Refilling Soap
When the soap level is low, simply open the top lid and refill the reservoir with liquid soap. Ensure the lid is securely closed after refilling to prevent spills and maintain hygiene.
Battery Replacement
When the dispensing performance decreases or the unit stops functioning, it may be time to replace the batteries. Open the battery compartment, remove the old AA batteries, and insert new ones, observing correct polarity. Dispose of used batteries responsibly.
Troubleshooting
If you encounter issues with your Deerma XS100 soap dispenser, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Dispenser does not activate or dispense soap. |
|
|
| Soap dispenses randomly or continuously. |
|
|
| Dispensing volume is too high or too low. |
|
|
Specifications
Detailed technical specifications for the Deerma XS100 Touchless Auto-Sensing Soap Dispenser:
| Feature | Detail |
|---|---|
| Model Number | XS100 |
| Brand | Deerma |
| Capacity | 250 ml |
| Dispensing Volume | Approx. 1.2 - 1.5 g per dispense |
| Power Source | 2 x AA Batteries (not included) |
| Sensing Distance | 0 - 10 cm |
| Dispensing Time | Approx. 1.4 seconds |
| Material | ABS Plastic |
| Color | White |
| Product Dimensions (L x W x H) | 12.5 x 9 x 19 cm |
| Item Weight | 420 g |
| Waterproof Rating | IPX5 |
Figure 8: Visual representation of the dispenser's dimensions and key specifications.
Warranty and Support
Warranty Information
This product is covered by a standard warranty policy. For detailed information regarding warranty terms and conditions, please refer to the official Deerma warranty documentation or contact customer support.
Customer Support
For any questions, technical assistance, or support inquiries regarding your Deerma XS100 soap dispenser, please contact the manufacturer or authorized importer:
- Manufacturer: Deerma, Guangdong Deerma Technology Co., Ltd.
- Importer (India): ALLIN IMPEX SERVICES PVT LTD
- Address: C-38, SECTOR-63, NOIDA, UP, 201301, India
- Mobile: 9313132789
- Email: sales@allinexporters.com
Please have your product model number (XS100) and purchase details ready when contacting support.
