1. Product Overview
This manual provides essential information for the DL-pro Enameled Baking Pan, designed for use in ovens and on hobs. This baking pan is a replacement part compatible with various appliance brands and models. It features an enameled surface for durability and ease of cleaning.
Image 1.1: Top view of the DL-pro Enameled Baking Pan, showcasing its deep design and enameled finish.
Image 1.2: Side view of the DL-pro Enameled Baking Pan, highlighting the 43mm total height and sturdy construction.
2. Specifications
| Brand | DL-pro |
| Model Number | 481010657928 |
| Dimensions (L x W x H) | 450 mm x 375 mm x 43 mm |
| Inner Edge Height | 40 mm |
| Material | Enameled Steel |
| Color | Black |
| Dishwasher Safe | Yes |
3. Compatibility
This baking pan is designed as a replacement part for various oven and hob models. It replaces original parts with the numbers C00325933 (Hotpoint) and 481010657928 (Bauknecht, Ignis, Whirlpool, Ikea). Please note that this pan replaces older designs that may have featured a rear corner hole; the current version does not include this hole.
It is crucial to verify compatibility with your specific appliance model. Refer to the original part number of your existing baking pan or consult your appliance's manual. A comprehensive list of compatible appliance models is provided in the images below. Please compare your device's model number with the lists to ensure a correct fit.
- Compatible Brands: Ariston, Bauknecht, Cooke&Lewis, Cylinda, Hotpoint, Ignis, Ikea, Indesit, KitchenAid, Charge, Maytag, Philips, Prima, Privileg, Scholtès, Whirlpool.
- Replaces Original Numbers:
- Indesit, Ariston, Hotpoint, Scholtès: C00325792, C00325933 (replaces C00320750, C00322006)
- Bauknecht, Ignis, Philips, Whirlpool, Ikea: 481010657928 (replaces 480121101184, 480121103007, 481010640956)
Image 3.1: Partial list of compatible Bauknecht appliance models. Verify your model number against this list.
Image 3.2: Partial list of compatible Whirlpool appliance models. Verify your model number against this list.
Image 3.3: Further compatibility list for various appliance brands and models. Consult this list for additional compatible devices.
Image 3.4: Extended compatibility list for various appliance brands and models. Consult this list for additional compatible devices.
Image 3.5: Final section of the compatibility list, including brands like Ignis, Ikea, and KitchenAid. Ensure your model is listed.
Image 3.6: Final section of the compatibility list, including brands like Ignis, Ikea, and KitchenAid. Ensure your model is listed.
4. Installation and Placement
- Verify Fit: Before first use, gently slide the baking pan into your oven or hob to ensure it fits correctly within the designated runners or slots.
- Positioning: Place the baking pan on the appropriate rack level for your cooking needs. Ensure it is stable and level to prevent spills.
- Handling: Always use oven mitts or heat-resistant gloves when handling the hot baking pan.
5. Usage Guidelines
- This enameled baking pan is suitable for various cooking and baking applications in conventional ovens and on hobs.
- Avoid using sharp metal utensils directly on the enameled surface to prevent scratches. Silicone, wood, or plastic utensils are recommended.
- Do not expose the pan to extreme thermal shock (e.g., placing a hot pan directly into cold water), as this may damage the enamel.
6. Cleaning and Maintenance
- After Use: Allow the baking pan to cool completely before cleaning.
- Hand Washing: Wash with warm, soapy water and a soft sponge or cloth. For stubborn food residues, soak the pan in warm water before cleaning.
- Dishwasher Safe: The DL-pro Enameled Baking Pan is dishwasher safe. Place it securely in the dishwasher, ensuring it does not obstruct spray arms.
- Drying: Dry thoroughly after washing to prevent water spots.
- Storage: Store in a dry place.
7. Troubleshooting
- Pan Does Not Fit: Double-check the model number of your appliance against the compatibility lists provided in Section 3. Baking pans are specific to manufacturer designs and cannot be ordered by general dimensions alone.
- Damaged Enamel: Avoid using abrasive cleaners or metal scouring pads, which can scratch or chip the enamel.
8. Support Information
If you encounter any issues with your DL-pro Enameled Baking Pan or have questions regarding its compatibility or use, please contact our customer support. We are committed to assisting you.
For support, please refer to the contact information provided by your retailer or visit the official DL-pro website.
