Introduction
Thank you for choosing the VOUNOT Day and Night Roller Blind. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new roller blind. Please read these instructions carefully before installation and keep them for future reference.
This roller blind features a unique dual-layer fabric design with alternating opaque and translucent bands, allowing you to easily adjust light levels and privacy in your home. Made from high-quality polyester, it is designed for durability and ease of use.
Setup and Installation
Parts List
Before you begin, ensure all parts are present:
Image: All components included in the VOUNOT roller blind package, such as brackets, clips, screws, and the chain holder.
- Roller Blind Unit
- Mounting Brackets / Clips
- Screws and Wall Plugs (for drill-in installation)
- Chain Holder (for child safety)
Important Note on Dimensions
The window or door frame must be at least 4 cm wider than the blind itself to ensure proper fit and function.
Image: A diagram illustrating the roller blind's width (55cm) and the recommended minimum frame width for installation.
Two Installation Methods
Method 1: Clip-on Installation (No Drilling)
This method is suitable for windows or doors that open. The clips allow for direct attachment to the window sash without drilling.
- Attach the provided clips to the top edge of your window or door sash. Ensure they are securely fastened.
- Carefully place the roller blind unit onto the clips, ensuring it clicks into place.
- Verify that the blind is stable and level.
Image: A detailed view of the clip-on bracket, designed for easy, drill-free installation on window sashes.
Image: An illustration demonstrating the simple clip-on installation process for the roller blind.
Method 2: Drill-in Installation (Screws)
This method is suitable for walls, ceilings, or window frames that do not open. Screws and wall plugs are provided for a secure attachment.
- Mark the desired positions for the mounting brackets on the wall, ceiling, or window frame. Ensure the marks are level and spaced correctly for the blind's width.
- Drill pilot holes at the marked positions. Insert wall plugs if installing into masonry or plasterboard.
- Secure the mounting brackets using the provided screws.
- Attach the roller blind unit to the secured brackets.
Operating Instructions
Adjusting Light and Privacy
The VOUNOT Day and Night Roller Blind features two layers of fabric with alternating opaque and translucent horizontal bands. To adjust the light and privacy:
- Day Mode (Partial Transparency): Align the translucent bands of both fabric layers to allow natural light to filter through while maintaining a degree of privacy.
- Night Mode (Full Privacy/Blackout): Overlap the opaque bands of both fabric layers to block light and ensure maximum privacy.
Image: The roller blind demonstrating its dual functionality, with one side showing translucent bands for daylight and the other showing opaque bands for privacy.
Using the Chain Mechanism
The blind is operated manually using the continuous chain mechanism located on one side. Gently pull the chain to raise or lower the blind and adjust the fabric layers.
Image: A close-up view of the beaded chain and roller system used to operate the blind.
Child Safety Feature: Chain Holder
For safety, especially in homes with children, secure the chain using the provided chain holder. This prevents the chain from hanging loosely and reduces the risk of entanglement.
Image: A close-up of the transparent chain holder, designed to keep the operating chain taut and out of reach.
Maintenance
The VOUNOT roller blind is made from durable polyester fabric, designed to resist humidity, mold, and sun exposure, ensuring a long lifespan. Regular cleaning will help maintain its appearance and functionality.
Cleaning Instructions
- To clean the fabric, simply wipe it with a damp cloth.
- Avoid using harsh chemicals or abrasive cleaners, as these may damage the fabric or color.
- For stubborn spots, a mild soap solution can be used, followed by wiping with a clean damp cloth.
- Allow the blind to air dry completely before rolling it up.
Image: A magnified view of the polyester fabric, highlighting its weave and texture.
Troubleshooting
If you encounter any issues with your VOUNOT Day and Night Roller Blind, please refer to the following common solutions:
- Blind not rolling smoothly: Check for any obstructions in the roller mechanism or along the fabric path. Ensure the chain is not tangled.
- Blind not staying in position: Verify that the mounting brackets are securely installed and that the chain mechanism is functioning correctly.
- Uneven rolling: Ensure the blind is installed perfectly level. Minor adjustments to the brackets might be necessary.
- Difficulty with installation: Re-read the installation instructions carefully. Ensure you are using the correct method (clip-on or drill-in) for your window type.
If the problem persists, please contact customer support for further assistance.
Specifications
| Feature | Detail |
|---|---|
| Brand | VOUNOT |
| Model Number | 4860598812695 |
| Color | Grey |
| Product Dimensions (L x W) | 150 cm x 55 cm |
| Material | Polyester |
| Special Feature | Blackout / Dual Transparency |
| Item Weight | 560 grams |
| Operation Mode | Manual |
| Opacity | Semi-transparent |
Warranty and Support
VOUNOT products are manufactured to high-quality standards. While specific warranty details are not provided in this manual, please retain your proof of purchase. For any questions, technical support, or warranty claims, please contact your retailer or the VOUNOT customer service directly.
Manufacturer: VOUNOT
Country of Origin: China
