1. Product Overview
The LEDLUX Mini Round Slim LED Downlight is a versatile lighting solution designed for various indoor applications. This package includes four 3W LED downlights operating on a low voltage DC 12V or 24V power supply. With a slim profile and a 50mm installation hole requirement, these lights are ideal for kitchens, bathrooms, RVs, caravans, boats, and cabinet lighting.
Key features include a 120° beam angle, 250 lumens output, and PWM dimmability. The lights have a high Color Rendering Index (CRI) of RA > 80, ensuring accurate color representation, and a long lifespan of over 30,000 hours.
Image 1.1: Four LEDLUX Mini Round Slim LED Downlights. These are white, circular lights with a low profile, designed for recessed installation.
2. Safety Information
Please read all safety instructions carefully before installation and use. Failure to follow these instructions may result in electric shock, fire, or other injuries.
- Electrical Safety: Ensure the power supply is disconnected before installation or maintenance. This product operates on low voltage DC (10-30V); do not connect directly to AC mains voltage.
- Qualified Electrician: Installation should be performed by a qualified electrician or a knowledgeable individual familiar with low-voltage DC electrical systems.
- Ventilation: Ensure adequate ventilation around the installed lights to prevent overheating. The operating temperature should remain below 50°C.
- IP Rating: This product has an IP20 rating, meaning it is protected against solid objects larger than 12.5mm but has no protection against water. Do not install in areas where it may be exposed to water or high humidity unless additional protection is provided.
- Compatibility: Use only with compatible 10-30V DC power supplies and PWM dimmers if dimming functionality is desired. Power supply is not included.
3. Package Contents
Your package should contain the following items:
- 4 x LEDLUX Mini Round Slim LED Downlights
If any items are missing or damaged, please contact your retailer.
4. Setup and Installation
These downlights are designed for flush mounting in ceilings or cabinets. Follow these steps for proper installation:
- Prepare the Installation Area: Ensure the power supply to the installation area is turned off at the main circuit breaker.
- Cut the Mounting Hole: Using an appropriate hole saw, cut a circular hole in the desired mounting surface. The recommended cut-out diameter is between 50mm and 60mm. The light itself has a diameter of 68mm and a height of 17mm.
- Connect Wiring: The downlight comes with two wires (positive and negative). Connect these wires to your 10-30V DC power supply. Ensure correct polarity (red wire typically positive, black wire negative). If using a PWM dimmer, connect it between the power supply and the lights according to the dimmer's instructions.
- Insert the Downlight: Gently push the spring-loaded clips on the sides of the downlight upwards and insert the light into the prepared hole. The clips will spring back down, securing the light in place.
- Restore Power: Once all lights are securely installed and wired, restore power to the circuit.
Image 4.1: Angled view of a single LEDLUX downlight, showing its slim profile. The overall diameter is 68mm.
Image 4.2: Rear view of the downlight, illustrating the spring-loaded mounting clips and the two-wire (red and black) electrical connection. The clips are designed to secure the light within the cut-out hole.
Image 4.3: Front view of a single LEDLUX downlight, showing the illuminated surface. This is how the light appears once installed.
Note: An external 12V or 24V DC power supply is required and is not included with this product.
5. Operating Instructions
Once installed and connected to a compatible DC power supply, the LEDLUX downlights will illuminate when power is supplied to the circuit.
- On/Off: Control the lights using the switch connected to your DC power supply circuit.
- Dimming: If a compatible PWM dimmer (Pulse Width Modulation) is installed in your circuit, you can adjust the brightness of the lights using the dimmer control.
6. Maintenance and Care
The LEDLUX downlights require minimal maintenance. Follow these guidelines to ensure longevity and optimal performance:
- Cleaning: Disconnect power before cleaning. Use a soft, dry, or slightly damp cloth to wipe the surface of the light. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish or internal components.
- No User-Serviceable Parts: These are sealed units. Do not attempt to open or disassemble the downlight. There are no user-serviceable parts inside, and doing so will void any warranty.
- Temperature: Ensure the operating environment temperature does not exceed 50°C.
7. Troubleshooting
If you encounter issues with your LEDLUX downlights, refer to the following common problems and solutions:
- Lights do not turn on:
- Check if the power supply is connected and active.
- Verify that the wiring connections are secure and correct (positive to positive, negative to negative).
- Ensure the power supply voltage is within the 10-30V DC range.
- Check for any tripped circuit breakers or blown fuses in your electrical system.
- Lights flicker or are dim:
- Ensure the power supply is providing stable voltage within the specified range.
- If using a dimmer, ensure it is a compatible PWM dimmer and is functioning correctly.
- Check for loose wiring connections.
- Lights are too hot:
- Ensure there is adequate air circulation around the installed lights.
- Verify that the ambient temperature is not excessively high.
If the problem persists after trying these solutions, please contact customer support.
8. Specifications
| Feature | Specification |
|---|---|
| Brand | LEDLUX |
| Model Number | FP2014FX4 |
| Product Dimensions (L x W x H) | 6.8 x 6.8 x 1.7 cm |
| Weight | 200 grams (per 4 pieces) |
| IP Rating | IP20 |
| Number of Items | 4 |
| Style | Minimalist |
| Color | White |
| Shape | Round |
| Material | Aluminum |
| Finish Type | Mirrors |
| Number of Bulbs | 4 (integrated LEDs) |
| Voltage | 10-30V DC (12V/24V compatible) |
| Specific Uses | Cabinet, Bathroom, Kitchen, RV, Caravan, Boat |
| Special Features | Dimmable (PWM) |
| Shade Material | Glass |
| Beam Angle | 120° |
| Plug Type | Electric Cable (2-wire positive/negative) |
| Switch Style | Dimmer (external) |
| Installation Type | Flush Mount / Ceiling Mount |
| Batteries Required/Included | No |
| Bulb Type | LED |
| Luminous Flux | 250 lumens |
| Power | 3 Watts |
| Color Rendering Index (CRI) | RA > 80 |
| Average Lifespan | > 30,000 hours |
| Startup Time | Instant Full Light |
| Warm-up Time | <1s |
Image 8.1: Energy efficiency label for the LEDLUX FP2014F model, indicating an energy rating of F and consumption of 3 kWh/1000h.
For more details, scan the QR code or visit: https://eprel.ec.europa.eu/qr/956947
9. Warranty and Support
Specific warranty information for this product is not provided in the available data. Please refer to your purchase receipt or contact the retailer for details regarding warranty coverage.
For technical support or inquiries, please contact LEDLUX customer service through their official website or the contact information provided by your retailer.
