FEELWORLD FT6 FR6 5.5 Inch Wireless Video Transmission Monitor

1. Introduction

Thank you for choosing the FEELWORLD FT6 FR6 5.5 Inch Wireless Video Transmission Monitor. This device integrates a high-quality HD monitor with a wireless video transmission system, offering enhanced mobility and flexibility for professional video production. The FT6 acts as the transmitter, and the FR6 functions as the receiver, providing a reliable solution for monitoring on set. This manual will guide you through the setup, operation, and maintenance of your new monitor system.

2. Safety Information

• Do not expose the device to rain or moisture to prevent fire or shock hazards.
• Avoid disassembling the unit. Refer servicing to qualified personnel only.
• Use only the specified power adapter (12V 1.5A) or compatible F970 batteries.
• Keep the device away from strong magnetic fields.
• Ensure proper ventilation to prevent overheating.

3. Package Contents

Verify that all items listed below are included in your package:

• 1x FEELWORLD FT6 Wireless Monitor (Transmitter)
• 1x FEELWORLD FR6 Wireless Monitor (Receiver)
• 1x Micro HDMI Cable
• 2x Sunshade
• 1x Hot Shoe Mount
• 4x Transmission Antenna
• 1x Type-C to USB Cable
• 1x Handle
• 2x Screws
• 1x Lanyard
• 1x 1/4 C-ring Screw
• 1x Small Carrying Case
• 1x User Manual

4. Product Overview

The FEELWORLD FT6 FR6 system consists of two 5.5-inch monitors, one configured as a transmitter (FT6) and the other as a receiver (FR6). Both units feature a 1920x1080 Full HD IPS touchscreen display, offering a 1000:1 contrast ratio and Rec.709 color gamut for accurate image representation. The system supports 4K HDMI input and loop-out, making it compatible with a wide range of DSLR and mirrorless cameras.

Key features include:

• Wireless Transmission: Up to 800ft (250m) range with ultra-low latency of 0.07s.
• High-Resolution Display: 5.5-inch 1920x1080 IPS screen with 500nit brightness.
• Touchscreen Control: Intuitive menu navigation and function adjustments.
• 3D LUT Support: Load up to 50 custom 3D LUTs via Type-C to USB.
• HDR Monitoring: Supports HDR signals for enhanced clarity and detail.
• Dual Battery Plates: Accommodates two F970 batteries for extended operation and hot-swapping.
• Professional Monitoring Tools: Includes Waveform, Vectorscope, Histogram, Focus Assist, False Color, Nine Grid, Exposure, Zoom, Image Flip, Embedded Audio, and Anamorphic Mode.

5. Setup

5.1. Attaching Antennas

Screw the four provided transmission antennas onto the designated ports on both the FT6 (transmitter) and FR6 (receiver) units. Ensure they are securely fastened for optimal signal transmission.

5.2. Powering the Device

The FT6 FR6 monitors can be powered by either a DC 12V power adapter (not included) or two F970 series batteries (not included). The monitors feature dual battery plates, allowing for continuous power by hot-swapping batteries.

To switch between batteries during operation, double-tap the battery icon displayed on the upper right corner of the monitor screen. The system will switch to the other battery after approximately 3 seconds.

5.3. Connecting to Your Camera

Use the provided Micro HDMI cable to connect your camera's HDMI output to the HDMI IN port on the FT6 (transmitter). If you need to loop out the signal to another monitor, connect an HDMI cable from the HDMI OUT port on the FR6 (receiver) to your external monitor.

5.4. Sunshade Installation

Attach the sunshade to the monitor to improve screen visibility in bright outdoor conditions. The sunshade clips onto the monitor's frame.

6. Operating Instructions

6.1. Power On/Off

Press and hold the power button located on the side of the monitor to turn the device on or off.

6.2. Touchscreen Controls

The FT6 FR6 monitors feature an intuitive touchscreen interface. Double-tap the screen to open the main menu. Swipe gestures allow for quick adjustments:

• Swipe up/down on the right side: Adjust volume.
• Swipe up/down on the left side: Adjust backlight.
• Swipe left/right: Access shortcut menus or switch between functions.

6.3. Wireless Pairing and Channel Selection

The FT6 and FR6 units are designed for automatic pairing. If manual pairing is required, use the WPS pairing function. There are 11 signal channels available for selection to ensure stable transmission.

For optimal performance, select a channel with minimal interference. The system provides real and stable pictures, crucial for professional monitoring.

6.4. Advanced Monitoring Features

The monitor includes a suite of professional tools to assist with exposure, focus, and framing:

• 3D LUT: Load custom Look-Up Tables to preview your footage with specific color grades.
• Waveform/Vectorscope/Histogram: Analyze video signals for accurate exposure and color balance.
• Focus Assist: Highlights in-focus areas for precise focusing.
• False Color: Displays exposure levels using a color overlay.
• Nine Grid: Assists with composition using a rule-of-thirds grid.

6.5. Video Playback and Monitoring

The system supports various video formats including 1080P60, 1080P50, 1080i60, 1080i50, and 4K HDMI formats (4096x2160p 24Hz, 3840x2160p 30/29.97/25/24/23.98Hz). The low latency of 0.07s ensures real-time monitoring.

7. Maintenance

• Cleaning: Use a soft, dry cloth to clean the monitor screen and body. For stubborn smudges, a slightly damp cloth with a mild cleaning solution can be used, ensuring no liquid enters the device.
• Storage: When not in use, store the monitor in its carrying case in a cool, dry place away from direct sunlight and extreme temperatures.
• Battery Care: If using F970 batteries, ensure they are charged regularly and stored properly to prolong their lifespan.

8. Troubleshooting

• Cannot turn on the monitor:
  Ensure you are using the standard 12V 1.5A power adapter or fully charged F970 batteries.
• Noise during recording:
  Long press the "<" button to decrease the volume to near zero. This can help avoid noise during recording. Long pressing ">" increases the volume.
• Monitor displays "no signal":

  1. Try using a different HDMI cable.
  2. Connect the monitor's HDMI input to a computer to verify if the monitor receives a signal.
  3. Check your camera's output signal settings and confirm that the monitor supports the camera's output signal format.
• Focus peak displays information on the monitor:
  Turn off the "HDMI Information Display" option under the "HDMI Settings" tab in the menu system. This will prevent additional information from being shown when focus peak is active.

9. Specifications

10. Warranty and Support

FEELWORLD provides a 1-year warranty for the FT6 FR6 Wireless Video Transmission Monitor. For any technical assistance or support inquiries, please contact FEELWORLD's official customer service. US local after-sales support is available to address your needs.
