Introduction
The Pawaboo 7L Automatic Cat Feeder is a WiFi-enabled smart food dispenser designed to provide scheduled meals for your cats and small dogs. This device ensures your pet receives consistent feeding times and portion sizes, even when you are away. It features app control, a voice recorder, and dual power options for reliable operation.
Product Overview
Components
- Feeder Unit (Main Body)
- Food Hopper (7L capacity, translucent)
- Food Bowl
- Lid with Buckle
- Desiccant Bag Compartment
- USB Cable (3m/9.8ft)
- Battery Compartment (for 3 x D-cell batteries, not included)
Key Features
- APP Control: Manage feeding schedules and portions remotely via a smartphone app (2.4G WiFi only).
- Large Capacity: 7-liter food hopper suitable for dry kibble with a diameter of 2-10mm.
- Scheduled Feeding: Program up to 10 meals per day.
- Portion Control: Dispense 1 to 12 portions per meal, with each portion approximately 10 grams.
- Voice Recorder: Record a 10-second personalized message to call your pet at meal times.
- Dual Power Supply: Operates via 5V/0.5A DC (USB cable included, adapter not included) or 3 x D-cell batteries (not included) for backup.
- Secure Lid: Buckled lid prevents pets from accessing food prematurely.
- Food Freshness: Includes a desiccant bag to keep food dry and fresh.
Setup Guide
- Unpack the Feeder: Carefully remove all components from the packaging.
- Install Power Supply:
- Connect the provided USB cable to the feeder and a 5V/0.5A power adapter (not included).
- For battery backup, open the battery compartment on the bottom of the feeder and insert 3 D-cell batteries (not included). This ensures operation during power outages.
Image: The bottom of the feeder showing the battery compartment and USB power input. This illustrates the dual power options.
- Download and Install App: Search for the "Tuya Smart" app on your smartphone's app store and install it.
- Connect to WiFi:
- Ensure your smartphone is connected to a 2.4GHz WiFi network. The feeder does not support 5GHz networks.
- Open the Tuya Smart app and follow the on-screen instructions to add the Pawaboo feeder. You may need to press and hold the WiFi pairing button on the feeder until the indicator light flashes.
Image: A cat eating from the feeder while a smartphone displays the app interface for remote feeding control.
- Prepare and Fill Food Hopper:
- Ensure the food hopper is clean and dry.
- Place a desiccant bag (included) into its designated compartment under the lid to maintain food freshness.
- Fill the hopper with dry kibble. The feeder is designed for kibble sizes between 2mm and 10mm in diameter. Do not use wet food.
- Securely close the lid using the buckle mechanism to prevent pets from opening it.
Image: Detailed view of the feeder's lid with a buckle, the desiccant bag placement, and the translucent food hopper for easy monitoring.
- Place the Feeder: Position the feeder on a flat, stable surface in an area accessible to your pet.
Operating Instructions
Scheduling Meals via App
- Open the Tuya Smart app and select your Pawaboo feeder.
- Navigate to the "Meal Plan" or "Schedule" section.
- Set desired feeding times (up to 10 meals per day).
- Adjust the number of portions for each meal (1 to 12 portions, approximately 10g each).
- Save your settings. The feeder will now dispense food according to your schedule.
Video: An instructional video demonstrating how to set up a feeding schedule using the smartphone application for the Pawaboo Automatic Cat Feeder.
Recording a Voice Message
- Locate the record button on the feeder's control panel.
- Press and hold the record button. Speak your 10-second message (e.g., "[Pet's Name], time to eat!").
- Release the button to save the recording. This message will play before each scheduled meal.
Image: The feeder with a dog, illustrating the 10-second voice recording feature to call pets for meals.
Manual Feeding
To dispense food manually, press the "Feed" button on the feeder's control panel or use the manual feed option within the Tuya Smart app. Each press or tap will dispense one portion.
Maintenance
- Cleaning: The food tray and hopper should be hand washed regularly with mild soap and water. Ensure all parts are completely dry before reassembling and refilling with food. Do not immerse the main feeder unit in water.
- Desiccant Bag: Replace the desiccant bag every 1-2 months, or as needed, to maintain food freshness.
- Food Level Check: Periodically check the translucent food hopper to monitor food levels and refill as necessary.
Troubleshooting
| Issue | Possible Cause | Solution |
|---|---|---|
| Feeder not connecting to WiFi | Incorrect WiFi band (5GHz), special characters in password, weak signal. | Ensure your router is broadcasting a 2.4GHz network. Avoid special characters in your WiFi password. Move the feeder closer to the router. Re-attempt pairing in the app. |
| Food not dispensing or jamming | Kibble size too large/small, wet food used, food blockage. | Ensure kibble is between 2mm and 10mm in diameter. Only use dry food. Check for any obstructions in the dispenser mechanism and clear them. |
| Feeder loses power/stops working | Power outage, loose USB connection, depleted batteries. | Check USB cable connection. If using battery backup, ensure batteries are fresh and correctly installed. |
| App not tracking feeding history | Intermittent WiFi connection, app synchronization issue. | Verify stable 2.4GHz WiFi connection. Restart the app. Ensure feeder firmware is up to date if an update is available. |
| Portions seem too small | Default portion size is small (approx. 10g). | Increase the number of portions per meal in the app settings to meet your pet's dietary needs. |
Specifications
- Model: P723314175331
- Dimensions (L x W x H): 9.1" x 8.3" x 13.8"
- Weight: 4.41 pounds
- Capacity: 7 liters
- Material: Polyethylene Terephthalate
- Connectivity: WiFi (2.4GHz only)
- Power Input: 5V/0.5A DC (USB)
- Battery Backup: 3 x D-cell batteries (not included)
- Kibble Size Compatibility: 2-10mm diameter
- Max Meals per Day: 10
- Portions per Meal: 1-12 (approx. 10g per portion)
- Voice Recording: 10 seconds
Image: The feeder with its physical dimensions and compatible kibble size clearly indicated.
Warranty and Support
For warranty information and customer support, please refer to the documentation included with your product or contact the retailer where the product was purchased. You may also visit the official Pawaboo store for additional resources and contact options:
