HOFTRONIC 120cm IP65 Waterproof LED TL Fixture

1. Introduction

Thank you for choosing the HOFTRONIC 120cm IP65 Waterproof LED TL Fixture. This manual provides essential information for the safe installation, operation, and maintenance of your new lighting product. Please read it thoroughly before use and retain it for future reference.

This fixture is designed for demanding environments, offering high efficiency and durability. It is ideal for use in humid areas such as garages, industrial halls, warehouses, and outdoor spaces.

2. Safety Information

WARNING: Electrical installation should only be performed by a qualified electrician in accordance with all local and national electrical codes.

• Always disconnect power at the circuit breaker before installation, maintenance, or cleaning.
• Ensure the supply voltage matches the fixture's requirements (230 Volts).
• Do not modify the fixture or its components. Unauthorized modifications may void the warranty and create safety hazards.
• Avoid direct eye exposure to the light source when the fixture is operating.
• The fixture is IP65 rated, meaning it is protected against dust ingress and low-pressure water jets from any direction. However, it is not designed for submersion.
• The fixture is IK06 rated, indicating protection against mechanical impacts.

3. Product Features

• Durable Construction: Constructed from robust ABS and Polycarbonate, this LED fixture offers high shock resistance and is suitable for environments with chemical vapors, such as factory halls and automotive garages.
• IP65 Waterproof & Dust-tight: With an IP65 rating, this fixture is fully waterproof and dust-tight, ensuring reliable operation in humid and dusty conditions. It functions across a wide temperature range (-25°C to 50°C), making it suitable for various indoor and outdoor applications, including cold storage.
• High Efficiency: The included LED tubes are highly efficient, delivering 175 lumens per watt. Each 36-watt tube produces 6300 lumens, offering an energy-efficient replacement for traditional 160-watt fluorescent lamps. The tubes feature a T8 fitting.
• Flicker-Free Lighting: Designed with a flicker-free LED driver, this ceiling light minimizes eye strain and headaches, making it ideal for prolonged use in workshops, offices, and similar environments.
• Long Lifespan: The LED tubes have an estimated lifespan of 50,000 hours.
• Included LED Starter: Easily retrofit your traditional tube light fixture with the included LED starter.

4. Package Contents

Please check the package for the following items:

• 1 x HOFTRONIC 120cm IP65 Waterproof LED TL Fixture
• 2 x HOFTRONIC T8 LED Tubes (36W, 4000K, 6300lm each)
• Mounting brackets and screws
• LED Starter (for each tube)

5. Setup and Installation

This fixture is designed for ceiling mounting. Professional installation is recommended.

5.1 Pre-Installation Checks

• Ensure the power supply is turned off at the main circuit breaker.
• Verify that the installation location is suitable for the fixture's dimensions and weight (5 kg).
• Confirm that the electrical wiring meets local standards and the fixture's requirements (230V AC/DC).

5.2 Mounting the Fixture

1. Mark the desired mounting points on the ceiling using the fixture's mounting brackets as a template.
2. Drill appropriate holes and insert wall plugs if necessary.
3. Secure the mounting brackets to the ceiling using the provided screws.
4. Attach the fixture body to the secured mounting brackets.

Image: Rear view of the HOFTRONIC LED TL fixture, illustrating the mounting brackets and the sealed cable entry point for secure installation.

5.3 Electrical Connection

1. Open the wiring compartment of the fixture.
2. Connect the main power supply cables (Live, Neutral, Earth) to the corresponding terminals inside the fixture. Ensure all connections are secure.
3. Close the wiring compartment, ensuring the seal is properly seated to maintain the IP65 rating.

5.4 Tube Installation and Compatibility

This fixture is designed for T8 LED tubes with a G13 fitting. The included LED tubes are compatible with 230V main power and magnetic ballasts (KVG). They are NOT compatible with electronic ballasts (EVG) or high-frequency ballasts (EVG).

1. Insert the provided LED tubes into the G13 sockets within the fixture.
2. Ensure the tubes are securely twisted into place.
3. If replacing existing fluorescent tubes, use the included LED starter.

Image: A detailed view of the G13 fitting within the HOFTRONIC LED TL fixture, showing the connection points for the LED tubes and indicating its capability for series linking.

Image: An illustration of the included LED starter, featuring a fuse, designed to facilitate the replacement of traditional fluorescent tubes with LED tubes.

Image: A clear compatibility chart indicating that the HOFTRONIC LED TL fixture works with 230V main power and magnetic ballasts, but is not compatible with electronic or high-frequency ballasts.

6. Operating Instructions

Once installed and connected to the power supply, the HOFTRONIC LED TL fixture operates simply:

• Turn on the power switch connected to the fixture. The LED tubes will illuminate instantly.
• Turn off the power switch to extinguish the light.
• The fixture provides a consistent, flicker-free light output at 4000K neutral white color temperature.

Image: An explanatory graphic detailing the flicker-free LED driver technology integrated into the HOFTRONIC LED TL fixture, highlighting its stable light output and high efficiency of 175 lumens per watt.

7. Maintenance

The HOFTRONIC LED TL fixture requires minimal maintenance due to its durable construction and long-lasting LED technology.

• Cleaning: Before cleaning, ensure the power supply is disconnected. Wipe the fixture with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the ABS and Polycarbonate materials.
• Inspection: Periodically inspect the fixture for any signs of damage, loose connections, or wear. If any issues are found, disconnect power and consult a qualified electrician.
• Tube Replacement: While the LED tubes have a long lifespan, if replacement is needed, ensure you use compatible T8 LED tubes with a G13 fitting.

Image: A visual representation of the HOFTRONIC LED TL fixture being subjected to water spray, demonstrating its IP65 rating for water and dust resistance.

Image: An informative graphic emphasizing the IK06 impact resistance and the use of high-impact polycarbonate in the construction of the HOFTRONIC LED TL fixture, ensuring durability.

8. Troubleshooting

If you encounter issues with your HOFTRONIC LED TL fixture, please refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact HOFTRONIC customer support or a qualified electrician.

9. Specifications

For detailed product information and energy efficiency data, please refer to the EPREL database: https://eprel.ec.europa.eu/qr/1066612

Image: The EU Energy Label for the HOFTRONIC LED TL fixture, indicating an energy efficiency class of B and an energy consumption of 18 kWh per 1000 hours.

10. Warranty and Support

HOFTRONIC provides a 3-year warranty on this LED TL luminaire. This warranty covers defects in materials and workmanship under normal use. Any defects occurring within this 3-year period will result in a free replacement.

For warranty claims, technical support, or any questions regarding your HOFTRONIC product, please contact your retailer or visit the official HOFTRONIC website for contact information.
