LAXIHUB P2 2K/3MP Indoor Wi-Fi Security Camera User Manual

1. Introduction

Thank you for choosing the LAXIHUB P2 2K/3MP Indoor Wi-Fi Security Camera. This manual provides essential information for setting up, operating, and maintaining your device. The P2 camera offers advanced features such as 2K/3MP video resolution, 360-degree pan and tilt functionality, enhanced night vision, two-way audio communication, and intelligent motion and sound detection. It is designed to help you monitor your home, pets, or children with ease and peace of mind.

LAXIHUB P2 Indoor Security Camera showing a golden retriever and a baby, with a smartphone displaying the live feed.

2. Features Overview

The LAXIHUB P2 camera is equipped with a range of features to enhance your home monitoring experience:

• 2K/3MP Video Resolution: Provides clear and detailed video footage.
• 360° Pan & Tilt: Offers a wide viewing angle with 355° horizontal and 93° vertical rotation.
• Enhanced Night Vision: Clear visibility up to 33 feet (10 meters) in complete darkness.
• Two-Way Audio: Built-in microphone and speaker for real-time communication.
• Motion & Sound Detection: Sends instant alerts to your smartphone upon detecting activity.
• Customizable Activity Zones: Define specific areas for motion detection.
• Flexible Storage Options: Supports local SD card storage (up to 256GB, not included) and cloud storage.
• Privacy Mode: Turn off the camera with one click via the app.
• Voice Control: Compatible with Amazon Alexa and Google Assistant.

Infographic detailing LAXIHUB P2 camera features: 2K 3MP view, customizable privacy mode, flexible 256GB storage, sharing, night vision, real-time alerts, and Alexa compatibility.

3. Package Contents

Please check the package for the following items:

• LAXIHUB P2 Camera (1)
• Power Supply (1)
• Mounting Accessories (Screws, Wall Plugs, Mounting Plate)
• User Manual (This document)

4. Setup Guide

4.1 App Download and Account Creation

1. Download the Arenti App from the App Store (iOS) or Google Play Store (Android).
2. Open the app and create a new account, or log in if you already have one.

4.2 Powering On the Camera

1. Connect the power supply to the camera's power port.
2. Plug the power adapter into a wall outlet.
3. The camera will power on, and the indicator light will flash, indicating it's ready for pairing.

4.3 Device Pairing (Wi-Fi Connection)

1. In the Arenti App, tap the "+" icon to add a new device.
2. Select your LAXIHUB P2 camera model from the list.
3. Follow the on-screen instructions to connect the camera to your 2.4GHz Wi-Fi network. Ensure your phone is connected to the same Wi-Fi network.
4. Scan the QR code displayed on your phone screen with the camera lens. Hold the phone approximately 15-20 cm (6-8 inches) from the camera.
5. Once connected, the camera's indicator light will turn solid blue, and you will hear a confirmation sound.

4.4 Placement and Mounting

The LAXIHUB P2 camera can be placed on a flat surface or mounted on a wall or ceiling.

• Tabletop Placement: Simply place the camera on a stable surface with a clear view of the area you wish to monitor.
• Wall/Ceiling Mounting:
  1. Attach the mounting plate to the desired location using the provided screws and wall plugs.
  2. Securely attach the camera to the mounting plate by twisting it into place.
  3. Adjust the camera angle in the app if necessary to ensure proper orientation.

5. Operating Instructions

5.1 Live View and Pan/Tilt Control

Access the live video feed from your camera through the Arenti App. Use the on-screen controls to remotely adjust the camera's viewing angle.

• Pan: Rotate the camera horizontally up to 355 degrees.
• Tilt: Adjust the camera vertically up to 93 degrees.

LAXIHUB P2 camera demonstrating 355-degree horizontal and 93-degree vertical rotation, controlled via a smartphone app.

5.2 Two-Way Audio

The camera features a built-in microphone and speaker, allowing you to listen to your environment and speak through the camera.

• Tap the microphone icon in the app to speak. Your voice will be transmitted through the camera's speaker.
• Ensure the speaker icon is enabled to hear audio from the camera's location.

A child and a dog interacting in a living room, with the LAXIHUB P2 camera in the foreground, depicting two-way audio communication.

5.3 Motion and Sound Detection

The camera can detect motion and sound, sending instant alerts to your smartphone.

• Motion Tracking: When motion is detected, the camera can automatically track the subject to keep it in view.
• Adjustable Sensitivity: Customize the sensitivity levels for both motion and sound detection in the app to minimize false alarms.
• Activity Zones: Set specific areas within the camera's view for motion detection, ignoring irrelevant areas.

LAXIHUB P2 camera tracking multiple cats in a living room, illustrating its smart motion tracking feature.

A cat on a sofa with a phone displaying a 'P2T Sound detected...' alert message, illustrating the camera's noise detection feature.

5.4 Night Vision

The camera automatically switches to enhanced infrared night vision in low-light conditions, providing clear black and white video up to 33 feet (10 meters).

A sleeping baby in a crib, viewed through the LAXIHUB P2 camera's enhanced night vision, showing the LED IR sensor and automatic activation up to 33ft in darkness.

5.5 Video Storage

Your video recordings can be stored in two ways:

• Micro SD Card: Insert a Micro SD card (up to 256GB, not included) into the camera's slot for local storage. Recordings can be exported from the SD card.
• Cloud Storage: LAXIHUB offers a free 3-month cloud storage trial. Your data is securely stored on AWS servers.

LAXIHUB P2 camera with an inset showing an SD card being inserted, and icons for SD card and cloud storage options.

5.6 Privacy Mode

Activate Privacy Mode via the Arenti App to temporarily turn off the camera and stop recording, ensuring your privacy when needed.

5.7 Voice Assistant Integration

The LAXIHUB P2 camera is compatible with Amazon Alexa and Google Assistant. You can use voice commands to view the live feed on compatible smart displays.

• Follow the instructions in your Alexa or Google Home app to link your Arenti account.
• Example command: "Alexa, show me the living room camera."

6. Maintenance

6.1 Cleaning

To ensure optimal performance, keep the camera lens clean.

• Gently wipe the lens with a soft, dry, lint-free cloth.
• Avoid using harsh chemicals or abrasive cleaners.

6.2 Firmware Updates

Periodically check the Arenti App for available firmware updates. Keeping your camera's firmware up-to-date ensures you have the latest features and security enhancements.

• Navigate to the camera settings in the app.
• Select "Firmware Update" and follow the prompts.

7. Troubleshooting

8. Specifications

Comparison image showing the difference between 1080P and LAXIHUB P2's 2K/3MP video resolution.

9. Warranty and Support

9.1 Warranty Information

LAXIHUB products typically come with a limited warranty. Please refer to the warranty card included in your product packaging or visit the official LAXIHUB website for detailed warranty terms and conditions specific to your region.

9.2 Customer Support

If you encounter any issues or have questions regarding your LAXIHUB P2 camera, please contact our customer support team:

• Email: Check the LAXIHUB official website for the most current support email address.
• Online Resources: Visit the LAXIHUB support page for FAQs, video tutorials, and additional resources.
