1. Introduction
This manual provides essential information for the safe operation, maintenance, and troubleshooting of your Coredy R580 Robot Vacuum Cleaner. Please read this manual thoroughly before using the product and retain it for future reference.
The Coredy R580 is a versatile robotic vacuum cleaner designed to simplify your cleaning routine. It features powerful 2000Pa suction, Wi-Fi connectivity for app control, and compatibility with voice assistants like Amazon Alexa and Google Assistant. It supports both sweeping and mopping functions (water tank and mop cloth sold separately) and can transition seamlessly from hard floors to carpets, automatically boosting suction when needed. Its slim design allows it to clean under furniture, and it supports virtual boundaries (strips sold separately) to define cleaning areas.
2. Safety Instructions
- Read all instructions before operating the appliance.
- Do not allow children to play with the robot. Supervise children and pets when the robot is operating.
- Only use the original power adapter provided by the manufacturer.
- Do not use the robot in environments with open flames or fragile objects.
- Ensure the robot is turned off and unplugged before cleaning or performing maintenance.
- Do not immerse the robot or its charging dock in water.
- Avoid using the robot on wet surfaces or in areas with standing water.
- Remove power cords, small objects, and loose rugs from the floor before operation to prevent entanglement.
3. Package Contents
Upon opening the package, please verify that all items listed below are included and in good condition:
- Coredy R580 Robot Vacuum Cleaner
- Charging Dock
- Power Adapter
- Side Brushes (4x)
- High Efficiency Filter (1x extra)
- Remote Control
- Cleaning Brush
Note: The 300ML water tank, cleaning mop cloth, and boundary strips are sold separately and are not included in the standard package.
4. Product Overview
Figure 4.1: Top view of the Coredy R580 Robot Vacuum Cleaner with an accompanying smartphone displaying the control application. The robot is black with bronze accents and features a central power button and home button.
Robot Components
- Top Panel: Power/Clean button, Home/Recharge button, Wi-Fi indicator.
- Front Bumper: Collision sensors.
- Side Brushes: Two rotating brushes for edge and corner cleaning.
- Dustbin: Collects debris.
- Main Brush: Central brush for deep cleaning.
- Driving Wheels: For movement across various surfaces.
- Charging Contacts: For automatic charging with the dock.
- Cliff Sensors: Detects drops to prevent falling down stairs.
5. Setup
5.1 Charging the Robot
Before first use, fully charge the robot. Place the charging dock against a wall in an open, uncluttered area. Ensure there is at least 1 meter (3 feet) of clear space to the front and 0.5 meters (1.5 feet) to each side of the charging dock. Connect the power adapter to the charging dock and plug it into a wall outlet. Place the robot on the charging dock, ensuring the charging contacts align. The indicator light on the robot will show charging status.
5.2 Installing Side Brushes
Attach the side brushes by pressing them onto the square posts at the bottom of the robot until they click into place. Ensure the brushes are securely fastened.
5.3 Connecting to Wi-Fi and App Setup
To utilize smart features, download the Coredy app from your smartphone's app store. Follow the in-app instructions to connect your R580 to your home Wi-Fi network. Note that the robot supports 2.4 GHz Wi-Fi networks only.
Figure 5.1: The Coredy smartphone application allows users to control cleaning, monitor status, schedule cleaning, and access support.
6. Operating the Robot Vacuum
6.1 Starting/Stopping Cleaning
- Manual Start: Press the Power/Clean button on the robot or the remote control.
- App Start: Use the Coredy app to initiate cleaning.
- Voice Command: If connected to Alexa or Google Assistant, use voice commands like "Alexa, ask Coredy to start cleaning."
- To pause cleaning, press the Power/Clean button again. To send the robot back to the charging dock, press the Home/Recharge button.
6.2 Cleaning Modes
- Auto Cleaning: The robot automatically cleans in a systematic pattern.
- Spot Cleaning: The robot cleans a specific area in a spiral pattern.
- Edge Cleaning: The robot cleans along walls and furniture edges.
6.3 Using Voice Control
The Coredy R580 is compatible with Amazon Alexa and Google Assistant. Once connected through the Coredy app, you can use simple voice commands to start or stop cleaning.
Figure 6.1: The Coredy R580 can be controlled via voice commands through Amazon Alexa or Google Assistant for hands-free operation.
6.4 Virtual Boundary (Sold Separately)
The R580 supports virtual boundary strips to restrict the robot from entering certain areas. Place the boundary strips on the floor to create invisible barriers. The robot's specialized sensors will detect these strips and avoid crossing them.
Figure 6.2: Virtual boundary strips (sold separately) allow you to define specific areas where the robot vacuum should not clean.
6.5 Sweep and Mop Function (Accessories Sold Separately)
The R580 can perform wet-dry mopping when equipped with the optional 300ML water tank and cleaning mop cloth. Attach the water tank with the mop cloth to the robot for comprehensive cleaning on hard surface floors.
Figure 6.3: The Coredy R580 can be converted for mopping by attaching the optional water tank and mop cloth.
6.6 Boost-Intellect Technology
The robot is equipped with Boost-Intellect Technology, which automatically increases suction power when it detects carpeted surfaces, ensuring a deeper clean across different floor types.
Figure 6.4: Boost-Intellect Technology automatically adjusts suction power when the robot moves from hard floors to carpets.
Figure 6.5: The Coredy R580 provides strong suction power to effectively clean various types of debris from hard floors.
7. Maintenance
Regular maintenance is crucial for optimal performance and longevity of your robot vacuum. Perform the following cleaning procedures regularly:
7.1 Emptying the Dustbin
Press the dustbin release button and pull out the dustbin. Open the dustbin cover and empty its contents into a trash can. It is recommended to empty the dustbin after each cleaning cycle.
7.2 Cleaning the Main Brush
Remove the main brush cover and lift out the main brush. Use the provided cleaning tool or a pair of scissors to remove any hair or debris tangled around the brush. Reinstall the main brush and cover.
7.3 Cleaning Side Brushes
Periodically check the side brushes for tangled hair or debris. Gently pull them off their posts to clean. If they are worn or damaged, replace them with new ones. Push them back onto the posts until they click.
7.4 Cleaning the Filter
Remove the filter from the dustbin. Tap the filter against a trash can to remove dust. Do not wash the filter with water, as this can damage it. Replace the filter every 2-3 months, or more frequently depending on usage.
7.5 Cleaning Sensors and Charging Contacts
Wipe the cliff sensors (located on the bottom of the robot) and the charging contacts (on the robot and charging dock) with a clean, dry cloth. Keeping these clean ensures proper navigation and charging.
8. Troubleshooting
If your Coredy R580 encounters issues, refer to the following table for common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Robot does not turn on | Low battery; Power switch off | Charge the robot; Turn on the main power switch. |
| Robot does not charge | Charging contacts dirty; Charging dock not powered | Clean charging contacts on robot and dock; Ensure charging dock is plugged in. |
| Robot gets stuck frequently | Obstacles (cables, rugs); Cliff sensors dirty | Clear obstacles from cleaning path; Clean cliff sensors. |
| Poor cleaning performance | Dustbin full; Brushes tangled; Filter clogged | Empty dustbin; Clean main and side brushes; Clean or replace filter. |
| Wi-Fi connection issues | Incorrect Wi-Fi password; Router too far; 5GHz network | Re-enter password; Move robot closer to router; Ensure 2.4GHz network is used. |
If the problem persists after trying the above solutions, please contact Coredy customer support for further assistance.
9. Specifications
| Feature | Detail |
|---|---|
| Brand | Coredy |
| Model | R580 |
| Special Feature | HEPA Filtration, Pet Tools, Vacuums |
| Color | Black |
| Filter Type | Cartridge |
| Dustbin Capacity | 0.3 Liters |
| Power Source | Battery Powered (1 Lithium Ion battery included) |
| Control Method | Remote, Voice (Alexa, Google Home), App |
| Form Factor | Robotic |
| Dimensions (L x W x H) | 16.89 x 13.66 x 4.57 inches |
| Item Weight | 8.91 pounds |
| Suction Power | Up to 2000Pa |
| Noise Level | Under 65dB |
10. Warranty and Support
10.1 Warranty Information
Coredy products are manufactured to the highest quality standards. For specific warranty details regarding your R580 Robot Vacuum Cleaner, please refer to the warranty card included in your product packaging or visit the official Coredy website. The warranty typically covers defects in materials and workmanship under normal use.
10.2 Customer Support
If you have any questions, require technical assistance, or need to report an issue with your Coredy R580, please contact Coredy customer support. Contact information can usually be found on the official Coredy website or on the product packaging. Please have your model number (R580) and purchase information ready when contacting support.
