YESKAMO Wireless Security Camera System User Manual

1. Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your YESKAMO Wireless Security Camera System. This system includes 3MP wireless cameras and an 8-channel NVR with a pre-installed 1TB HDD, designed for reliable outdoor and indoor surveillance.

Image: Overview of the YESKAMO Wireless Security Camera System, showing two cameras, the NVR, and a 1TB hard drive.

2. Package Contents

Please verify that all items listed below are included in your package:

• 2 x Wireless Security Cameras (3MP)
• 1 x Wireless NVR (8-channel, 5MP compatible) with 1TB HDD pre-installed
• 2 x 12V1A Power Adapters for Cameras
• 1 x 12V2A Power Adapter for NVR
• 1 x USB Mouse
• 1 x 1m LAN Cable
• 2 x Security Stickers
• 1 x Quick Start Guide (Japanese)
• 1 x Detailed User Manual (Japanese)

Image: Illustration of the complete package contents, including NVR, cameras, power adapters, mouse, LAN cable, and manuals.

3. Product Overview

3.1 Camera Features

• 3MP High-Resolution Sensor with HISILICON chip
• 100° Wide-Angle Lens
• IP66 Waterproof and Dustproof Metal Casing
• Built-in Microphone and Speaker for Two-Way Audio
• AI Human Detection with Sensor Light and Siren Alarm
• Infrared LEDs for Night Vision
• Adjustable 3DB Antennas

3.2 NVR Features

• 8-Channel Recorder, compatible with up to 5MP cameras
• Pre-installed 1TB HDD for continuous recording
• H.265 Video Compression for efficient storage
• VGA and HDMI outputs for monitor connection
• LAN port for network connection and remote access
• USB ports for mouse and backup

Image: Detailed view of the camera's high-sensitivity chip and lens, alongside a comparison demonstrating the superior clarity of 3MP resolution over 1MP.

4. Setup Guide

Follow these steps for initial system setup:

1. Connect Cameras: Plug the 12V1A power adapters into each camera and then into a power outlet. The cameras will power on.
2. Connect NVR:
   • Connect the NVR to a monitor (VGA or HDMI) with a resolution of 1024x1280 or higher.
   • Connect the USB mouse to the NVR's USB port.
   • Plug the 12V2A power adapter into the NVR and then into a power outlet. The NVR will power on and automatically detect the cameras within seconds.
3. Local Viewing: Once powered on, the system will automatically begin recording. You can view live footage and playback recordings directly on the connected monitor without an internet connection.
4. Remote Viewing (Optional): For remote viewing via mobile app or PC, connect the NVR to your home router using the provided LAN cable. Ensure your router has an active internet connection.

Image: Visual guide for connecting the camera power, NVR power, and NVR to a monitor.

5. Operating Instructions

5.1 Recording Modes

The system supports various recording modes:

• Continuous Recording: Records 24/7. The 1TB HDD allows for extended recording periods. Older files are automatically overwritten when the disk is full.
• Scheduled Recording: Set specific times for recording, such as during weekdays, nights, or holidays.
• Motion Detection Recording: Records only when motion is detected. This conserves storage space and makes reviewing events easier.

Image: Visual representation of different recording options including continuous, scheduled, and motion detection, along with various alarm methods.

5.2 AI Human Detection and Alarms

The system features advanced AI human detection to minimize false alarms caused by light changes or heat. When a human is detected:

• Siren Alarm: The camera can emit a siren sound to deter intruders.
• Sensor Light: In dark conditions, the camera's sensor lights will illuminate, providing a color image and acting as a deterrent. This feature can be enabled/disabled.
• Mobile Notifications: Receive instant alerts on your smartphone.
• Email Notifications: Get email alerts with snapshots of the event.
• NVR Buzzer: The NVR can emit an audible alarm.

Image: Illustration of AI human detection triggering a siren and sensor light, showing color night vision capabilities and different night vision modes.

5.3 Two-Way Audio

Equipped with a high-sensitivity microphone and speaker, the cameras support two-way audio communication. You can:

• Listen to audio from the camera's location (up to 8m range).
• Speak through the camera to communicate with visitors or deter intruders.

Image: Depiction of two-way audio functionality, showing a user speaking through a smartphone to someone at the camera's location, and audio recording examples.

5.4 Remote Access

Access your camera system remotely using the YESKAMO app on your smartphone or client software on your PC. Ensure the NVR is connected to your router via LAN cable for this functionality.

Image: Steps for connecting the NVR to a router and accessing the system via the YESKAMO app on a smartphone or PC, illustrating live view and playback.

6. Maintenance

• Cleaning: Regularly wipe the camera lenses with a soft, dry cloth to ensure clear image quality. Do not use harsh chemicals.
• Weather Protection: The cameras are IP66 rated for outdoor use, providing protection against dust and strong jets of water. However, avoid submerging them in water.
• Cable Management: Ensure all cables are securely connected and protected from environmental damage. Use waterproof plugs for exposed connections.
• Firmware Updates: Check the official YESKAMO website periodically for firmware updates to ensure optimal performance and security.

7. Troubleshooting

7.1 No Image Display

• Check if the NVR and cameras are properly powered on.
• Ensure the monitor is correctly connected to the NVR via VGA or HDMI.
• Verify that the monitor input source is set correctly.

7.2 Unstable Wi-Fi Signal

If the wireless signal between the cameras and NVR is unstable, consider the following solutions:

• Repeater Function: Utilize the NVR's repeater function to extend the Wi-Fi range.
• Wired Connection: Connect cameras to the NVR directly via an Ethernet cable for a more stable connection.
• External Repeater: Use a separate Wi-Fi repeater or range extender (sold separately).
• Extended Antenna: Connect an external Wi-Fi extension antenna (sold separately) to the cameras.

7.3 Recording Issues

• Ensure the 1TB HDD is properly installed and recognized by the NVR.
• Check recording settings (continuous, scheduled, motion detection) to ensure they are configured as desired.
• If the HDD is full, the system will automatically overwrite the oldest files. To retain more footage, consider upgrading the HDD to a maximum of 6TB.

8. Specifications

9. Warranty and Support

YESKAMO provides comprehensive support for its products:

• Warranty: This product comes with a 3-year warranty.
• Return Policy: 60-day money-back guarantee.
• Exchange Policy: Free exchange within 1 year.
• Technical Support:
  • Telephone support available during business hours.
  • Email inquiries are responded to promptly, typically within 24 hours.
• For any questions or assistance, please contact YESKAMO customer support.
