Product Overview
This document provides instructions for the Generisch maintenance kit designed for Buderus G115 oil burners, specifically the Logatop BE-A series. Regular maintenance is crucial for optimal performance, efficiency, and longevity of your heating system.
Compatibility
This maintenance kit is compatible with the following Buderus Logatop BE-A oil burner models:
- BE-A 1.0/1.1 - 2.0/2.1 (17-68 kW)
Kit Contents
The maintenance kit includes the following components:
- 1 x Double Ignition Electrode L34 / L50: Suitable for 17-34 kW (L34) and 43-55 kW (L50) burners. This component is essential for reliable ignition of the oil burner.
- 1 x Gasket for Ceramic Burner Tube D 81: Ensures a proper seal for the burner tube, preventing air leaks.
- 1 x Danfoss/OEG Oil Nozzle: A critical component for atomizing fuel into a fine spray for efficient combustion. The specific nozzle size is 0.55-60°HFD for BE-A 1.1-28 kW models.
- 1 x Siku Star Fuel Filter (35 m²): Compatible with common oil filters such as Afriso, Oventrop, and GOK. This filter removes impurities from the fuel, protecting the burner components.
- 1 x O-ring for Fuel Filter (3/8" - 1/2"): For common oil filters such as Afriso, Oventrop, and GOK. Provides a seal for the fuel filter housing.
Image Description: An overhead view of all components included in the maintenance kit. From top left, clockwise: a double ignition electrode, a white cylindrical ceramic filter, a green braided gasket, a black O-ring, and at the bottom left, a brass oil nozzle next to a small orange-capped fuel filter.
Maintenance Guidelines
Regular maintenance of your oil burner is vital for safety, efficiency, and preventing breakdowns. This kit provides key components for routine servicing.
Ignition Electrode Replacement
The double ignition electrode should be inspected and replaced periodically to ensure consistent and reliable ignition. Worn or fouled electrodes can lead to ignition failures and inefficient operation.
Burner Tube Gasket Replacement
The gasket for the ceramic burner tube helps maintain a sealed combustion chamber. Replace this gasket if it shows signs of wear, cracking, or damage to prevent air leaks that can affect combustion efficiency.
Oil Nozzle Replacement
The oil nozzle is a precision component that atomizes the fuel. Over time, nozzles can wear or become clogged, affecting combustion efficiency and leading to increased fuel consumption or soot production. Replace the oil nozzle annually or as recommended by the burner manufacturer.
Fuel Filter and O-ring Replacement
The fuel filter prevents contaminants from reaching the burner. Replace the Siku star fuel filter and its O-ring during each service interval to ensure clean fuel delivery and prevent blockages in the fuel line or nozzle.
It is highly recommended that maintenance procedures be performed by a qualified heating technician. Refer to your specific Buderus Logatop BE-A oil burner manual for detailed replacement instructions and safety precautions.
Specifications
| Feature | Detail |
|---|---|
| Brand | Generisch |
| Compatible Burner Models | Buderus Logatop BE-A 1.0/1.1 - 2.0/2.1 |
| Power Range | 17-68 kW |
| Specific Nozzle | 0.55-60°HFD (for BE-A 1.1-28 kW) |
| Product Dimensions | 10 x 10 x 4 cm |
| Product Weight | 200 grams |
Support and Assistance
For technical support, detailed installation guides, or professional assistance with your Buderus Logatop BE-A oil burner, please consult your original burner manual or contact a certified HVAC technician.
For inquiries regarding the Generisch maintenance kit components, please contact the seller or manufacturer.
Image Description: The iTecFix brand logo, featuring the name "iTecFix" with two orange squares preceding "iTec" and an orange "Fix". Below the logo, the German slogan "Passende Teile, Starke Lösungen!" is visible, which translates to "Matching Parts, Strong Solutions!".
Image Description: A white cardboard box with the iTecFix logo and slogan printed on a label affixed to the top. The box appears to be packaging for the product.
