Maxax Modern Square Chandelier Instruction Manual

Model: 19078-4 | Brand: Maxax

Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your Maxax Modern Square Chandelier. Please read all instructions carefully before beginning installation to ensure safe and proper use of the product.

The Maxax Modern Square Chandelier features an eye-catching open square frame with 4 candle-shaped bulb bases, designed to create a charming contrast effect suitable for various rooms including kitchens, dining rooms, bedrooms, and living rooms.

Product Features

Modern Style: Features an antique black finish with an open square frame and 4 candle-shaped bulb bases.
Adjustable Height: Includes an adjustable 39.4-inch chain, allowing suspension from sloped or flat ceilings.
Bulb Compatibility: Requires 4 E26 light bulbs (40-60W, bulbs not included). Compatible with incandescent, LED, or CFL light bulbs.
Versatile Design: Suitable for dining rooms, living rooms, kitchens, foyers, and hallways.
Dimmable Functionality: Can be used with dimmable bulbs and a dimmer switch (not included).

What's in the Box

The package includes the following components:

Maxax Modern Square Chandelier Fixture
Mounting Hardware
Adjustable Chain
Canopy

Components of the Maxax Modern Square Chandelier including the antique black metal canopy, E26 base sockets, antique black metal frame, and 39.4-inch adjustable chain.

Image: Detailed view of chandelier components including canopy, E26 base, metal frame, and adjustable chain.

Specifications

Brand	Maxax
Model Number	19078-4
Color	Antique black
Material	Metal
Style	Modern
Light Fixture Form	Chandelier
Product Dimensions	23"L x 18"W x 63.5"H (including chain)
Chain Length	39.4 inches (adjustable)
Number of Light Sources	4
Bulb Base	E26
Max Wattage	60 watts per bulb
Voltage	110 Volts
Power Source	Corded Electric
Installation Type	Flush Mount
Item Weight	12 Pounds
Indoor/Outdoor Usage	Indoor use only

Diagram showing the dimensions of the Maxax Modern Square Chandelier, including length, width, height, and chain length, along with illustrations for flat, vaulted, and sloped ceiling compatibility.

Image: Chandelier dimensions and ceiling compatibility.

Safety Information

Always ensure the power supply is disconnected before installation, maintenance, or bulb replacement. Installation should be performed by a qualified electrician if you are unsure. Do not exceed the maximum wattage specified for the bulbs. This fixture is designed for indoor use only.

Turn off power at the circuit breaker before installation.
Use only E26 base bulbs with a maximum of 60 watts.
Ensure all connections are secure and properly insulated.
Do not modify the fixture in any way.
Keep away from water and moisture.

Setup and Installation

The Maxax Modern Square Chandelier is designed for flush mount installation and comes with all necessary mounting hardware. The adjustable chain allows for customization of hanging height to suit your space.

Installation Steps:

Prepare for Installation: Turn off the power at the main circuit breaker. Clear the work area and gather necessary tools (screwdriver, wire strippers, ladder).
Mount the Crossbar: Attach the mounting crossbar to the junction box in your ceiling using the provided screws.
Adjust the Chain: Determine the desired hanging height for your chandelier. Adjust the chain length by removing links as needed.
Wire the Fixture: Connect the fixture's wires to the corresponding house wires (black to black, white to white, ground to ground) using wire nuts. Ensure all connections are secure.
Secure the Canopy: Tuck the wires into the junction box and secure the canopy to the mounting crossbar.
Install Bulbs: Screw in four E26 base bulbs (not included) into the lamp holders.
Restore Power: Turn the power back on at the circuit breaker and test the chandelier.

Maxax Modern Square Chandelier hanging in a room, showcasing its design and size.

Image: The Maxax Modern Square Chandelier installed.

Operating Instructions

Once installed, operate the chandelier using your standard wall switch. For dimmable functionality, ensure you use dimmable E26 bulbs and have a compatible dimmer switch installed (sold separately).

Side-by-side comparison of the Maxax Modern Square Chandelier with lights off and lights on, demonstrating its illumination.

Image: Chandelier with lights off (left) and on (right).

Image showing various E26 bulb types compatible with the Maxax Modern Square Chandelier, including incandescent, LED, and CFL options.

Image: Compatible E26 bulb types.

Maintenance

To maintain the appearance and longevity of your chandelier, follow these simple maintenance guidelines:

Cleaning: Dust regularly with a soft, dry cloth. For more thorough cleaning, wipe with a damp cloth using mild soap and water, then dry immediately. Avoid abrasive cleaners or solvents.
Bulb Replacement: Always turn off the power before replacing bulbs. Allow bulbs to cool completely before handling.
Inspection: Periodically check all connections and mounting hardware to ensure they remain secure.

Troubleshooting

If you encounter any issues with your Maxax Modern Square Chandelier, please refer to the following common troubleshooting steps:

Problem	Possible Cause	Solution
Light does not turn on	No power, loose wiring, faulty bulb, tripped circuit breaker.	Check power supply, ensure wires are securely connected, replace bulb, reset circuit breaker.
Flickering lights	Loose bulb, incompatible dimmer switch, faulty wiring.	Tighten bulbs, ensure dimmer switch is compatible with LED/CFL bulbs if used, check wiring connections.
Chandelier is crooked	Improper mounting, uneven ceiling.	Re-adjust mounting hardware, ensure canopy is flush with the ceiling.

Official Product Videos

View these official videos from the seller for additional product insights and demonstrations.

Video: "Maxax 4 Lights Square Chandelier for Your Room" - A brief overview showing the chandelier installed in a room setting.

Video: "Maxax Modern Square Chandelier" - A detailed look at the chandelier's design and features.

Video: "Customer photos of Maxax's 4-Light Farmhouse Chandelier" - A compilation of customer installations showcasing the chandelier in various home environments.

Warranty and Support

Maxax is committed to providing quality products and excellent customer service. If you have any questions, concerns, or require assistance with your Maxax Modern Square Chandelier, please do not hesitate to contact us.

For support, please refer to the contact information provided with your purchase or visit the official Maxax store on Amazon: Maxax Store.
