Introduction
Thank you for choosing the MAIDeSITe T1 Basic Electric Height-Adjustable Desk. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new desk. Please read these instructions carefully before use and retain them for future reference.
The MAIDeSITe T1 Basic desk frame offers stable and quiet height adjustment, allowing you to easily switch between sitting and standing positions. Its robust design and intelligent features are intended to enhance your workspace ergonomics.
Safety Information
- Weight Limit: Do not exceed the maximum load capacity of 80 kg (176 lbs). Overloading can cause instability and damage.
- Assembly: Follow the assembly instructions precisely to ensure proper stability and safe operation. Incorrect assembly can lead to hazards.
- Clearance: Ensure there are no obstructions above or below the desk during height adjustment to prevent damage or injury.
- Children and Pets: Keep children and pets away from the desk during operation. The control panel includes a child safety lock feature to prevent accidental adjustments.
- Power Supply: Use only the provided power adapter. Do not operate the desk with a damaged power cord or plug.
- Environment: Do not expose the desk to excessive moisture or extreme temperatures.
- Maintenance: Regularly check all screws and bolts to ensure they are tight. Do not attempt to repair the motor or control system yourself. Contact customer support for assistance.
Package Contents
The package typically includes the following components:
- Desk frame components (legs, crossbar, feet)
- Control panel with LCD display
- Power adapter and cable
- Assembly hardware (screws, bolts, Allen wrench)
- Instruction manual
Note: A tabletop is typically sold separately and is not included with the frame.
Setup and Assembly
Assembly of the MAIDeSITe T1 Basic desk frame is designed to be straightforward. Please refer to the detailed assembly manual included in your package for step-by-step instructions and diagrams. The following is a general overview:
- Unpack Components: Carefully remove all parts from the packaging and verify against the parts list in the included manual.
- Assemble Legs and Feet: Attach the feet to the bottom of the desk legs using the provided hardware.
- Connect Crossbar: Secure the adjustable crossbar between the two leg columns. Ensure the crossbar is extended to the desired width for your tabletop. The frame is adjustable from 96 cm to 160 cm in width.
- Attach Tabletop: Place your chosen tabletop (recommended dimensions: 100-180 cm wide, 50-80 cm deep) onto the assembled frame. Secure it using appropriate screws (not always included with the frame).
- Install Control Panel: Mount the control panel to the underside of the tabletop in an accessible location.
- Connect Cables: Connect the motor cables from the legs to the control box, and then connect the control panel cable and power adapter to the control box.
- Initial Power-Up: Plug the power adapter into a wall outlet. The desk may require an initial reset or calibration as per the specific manual instructions.
Figure 1: Easy Assembly Overview. The desk frame is designed for straightforward assembly, typically taking around 30 minutes with basic tools.
Operating Instructions
Control Panel Functions
Figure 2: Premium Touch Control Panel. The panel features an LCD screen, child safety lock, four memory presets, and a USB charging port.
- Up/Down Buttons (▲ / ▼): Press and hold to adjust the desk height upwards or downwards. The desk height range is 72 cm to 120 cm.
- Memory Presets (1, 2, 3, 4): These buttons allow you to save and recall preferred desk heights.
- Memory 'M' Button: Used to save a height setting. To save a height: adjust the desk to the desired height, press 'M', then press one of the number buttons (1, 2, 3, or 4) until you hear a beep or see a confirmation on the LCD.
- Child Safety Lock: The control panel includes a child safety lock feature. Refer to your specific manual for activation and deactivation instructions to prevent accidental adjustments.
- USB Port: A convenient USB port is integrated into the control panel for charging devices.
Height Adjustment
The desk features a powerful and quiet motor, operating at less than 45 dB, with an adjustment speed of 30 mm/s.
Figure 3: Height Adjustment Range. The desk offers a height range from 72 cm to 120 cm, accommodating various user preferences.
Figure 4: Retractable Frame Range. The desk frame's width is adjustable from 96 cm to 160 cm, fitting a wide range of tabletops.
Maintenance
- Cleaning: Wipe the desk frame with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners.
- Fasteners: Periodically check all screws and bolts to ensure they are securely tightened. Loose fasteners can affect stability and operation.
- Cable Management: Ensure all cables are neatly routed and not pinched or tangled, which could cause damage.
- Lubrication: The lifting columns are designed to be maintenance-free and do not require lubrication.
Troubleshooting
If you encounter issues with your MAIDeSITe T1 Basic desk, please refer to the following common troubleshooting steps:
- Desk Not Moving:
- Check if the power cable is securely plugged into both the wall outlet and the control box.
- Ensure the child safety lock is not activated.
- Perform a reset (refer to your specific manual for reset procedures, often involving holding down certain buttons).
- Uneven Movement:
- Ensure the desk is not overloaded and weight is evenly distributed.
- Check for any obstructions preventing smooth movement.
- Perform a calibration or reset procedure.
- Error Codes on Display:
- Consult your detailed manual for a list of error codes and their corresponding solutions.
- Often, unplugging the desk for 10-15 minutes and plugging it back in can resolve temporary errors.
- Unusual Noises:
- Ensure all assembly screws are tight.
- Check for any objects caught in the lifting mechanism.
If these steps do not resolve the issue, please contact MAIDeSITe customer support.
Specifications
| Feature | Specification |
|---|---|
| Brand | MAIDeSITe |
| Model Name | T1 Basic (also referred to as T1 Pro, Model No. HU-XI-201) |
| Color | Black |
| Material | Carbon Steel |
| Height Adjustment Range | 72 cm - 120 cm (28.3 in - 47.2 in) |
| Width Adjustment Range | 96 cm - 160 cm (37.8 in - 63 in) |
| Recommended Tabletop Width | 100 cm - 180 cm (39.4 in - 70.9 in) |
| Recommended Tabletop Depth | 50 cm - 80 cm (19.7 in - 31.5 in) |
| Maximum Load Capacity | 80 kg (176 lbs) |
| Motor Noise Level | < 45 dB |
| Adjustment Speed | 30 mm/s |
| Memory Presets | 4 |
| Special Features | Child Safety Lock, USB Charging Port |
Figure 5: Superior Load Capacity. The desk is designed to support up to 80 kg (176 lbs) for stable operation.
Figure 6: Powerful and Quiet Motor. The desk features a motor designed for efficient, quiet, and durable performance.
Warranty and Support
MAIDeSITe offers a 5-year warranty on the T1 Basic desk frame, ensuring reliability and durability. For any questions, issues, or warranty claims, please contact our customer service team.
Our customer support is available to provide assistance and ensure you have the best possible experience with your product.
Contact Information: Please refer to the contact details provided in your purchase documentation or on the official MAIDeSITe website for customer service.
