Introduction
Thank you for choosing the Majority Saxon Compact Soundbar. This manual provides essential information for setting up, operating, and maintaining your device. Please read these instructions carefully before use to ensure optimal performance and longevity of your soundbar.
The Majority Saxon is designed to enhance your home audio experience, offering versatile connectivity options and immersive sound modes in a compact form factor.
A front view of the Majority Saxon soundbar, showcasing its compact design and metallic grille.
What's in the Box
Please check the contents of your package. If any items are missing or damaged, contact your retailer.
- 1 x Majority Saxon Soundbar
- 1 x Remote Control (with 2 AAA batteries)
- 1 x 3.5mm to 3.5mm AUX Cable
- 1 x Mains Power Adapter
A visual representation of the contents of the Majority Saxon soundbar package, including the soundbar, remote, AUX cable, and power cable.
Controls and Connections
Familiarize yourself with the soundbar's controls and connection ports.
Soundbar Controls (Top Panel)
- Power Button: Press to turn on/off.
- Mode Button: Press to cycle through input sources (Bluetooth, HDMI ARC, Optical, AUX, USB).
- Volume Up/Down: Adjust the volume level.
- Play/Pause: Control media playback (Bluetooth/USB modes).
Rear Connection Ports
A clear diagram of the rear panel of the Majority Saxon soundbar, with labels for USB, OPTICAL, HDMI (ARC), AUX, and DC IN ports.
- USB Port: For playing audio files from a USB drive.
- OPTICAL Input: Connect to devices with an optical audio output.
- HDMI (ARC) Input: Connect to a TV's HDMI ARC port for high-definition audio and TV remote control functionality.
- AUX Input: Connect to devices using a 3.5mm audio cable.
- DC IN: Connect the power adapter.
Setup
Follow these steps to set up your Majority Saxon Soundbar:
- Placement: Place the soundbar on a stable, flat surface directly in front of your TV or monitor. Ensure there are no obstructions blocking the sound. Its compact design allows it to fit perfectly under most TVs or monitors.
- Power Connection: Connect the mains power adapter to the DC IN port on the back of the soundbar, then plug the adapter into a wall socket.
- Initial Power On: Press the Power button on the soundbar or the remote control to turn on the device. The LED indicator will light up.
- Remote Control Batteries: Insert the two AAA batteries into the remote control, ensuring correct polarity.
The Majority Saxon soundbar positioned neatly under a television in a living room setting, demonstrating its ideal placement.
Operating Instructions
The Majority Saxon Soundbar offers multiple connectivity options:
1. Bluetooth Connection
- Press the 'Mode' button on the soundbar or remote until 'BT' appears on the display, indicating Bluetooth mode.
- On your device (smartphone, tablet, etc.), enable Bluetooth and search for available devices.
- Select 'Majority Saxon' from the list. Once paired, the soundbar will emit a confirmation tone.
- You can now play audio from your device through the soundbar. The Bluetooth range is approximately 10 meters.
2. HDMI ARC Connection
- Connect one end of an HDMI cable (not included) to the HDMI (ARC) port on the soundbar.
- Connect the other end to the HDMI ARC port on your TV.
- Select 'HDMI ARC' as the input source on the soundbar using the 'Mode' button.
- Ensure your TV's audio output is set to HDMI ARC or external speakers. This connection allows your TV remote to control the soundbar's volume.
3. Optical Connection
- Connect an optical cable (not included) from your TV or audio device's optical output to the 'OPTICAL' input on the soundbar.
- Select 'OPT' as the input source on the soundbar using the 'Mode' button.
- Ensure your TV's audio output is set to 'Optical' or 'External Speakers'.
4. AUX Connection
- Connect the supplied 3.5mm to 3.5mm AUX cable from your audio device's headphone jack or AUX output to the 'AUX' input on the soundbar.
- Select 'AUX' as the input source on the soundbar using the 'Mode' button.
5. USB Playback
- Insert a USB drive containing MP3 audio files into the 'USB' port on the soundbar.
- Select 'USB' as the input source on the soundbar using the 'Mode' button.
- The soundbar will automatically begin playing audio files from the USB drive. Use the remote control for playback functions (Play/Pause, Skip).
Remote Control Functions
- Power: Turn the soundbar on or off.
- Mode: Switch between input sources (BT, HDMI ARC, OPT, AUX, USB).
- Mute: Mute or unmute the sound.
- Volume +/-: Adjust the volume level.
- EQ: Cycle through equalizer presets (Music, Movie, Voice).
- 3D: Activate or deactivate 3D sound mode.
- Playback Controls (Play/Pause, Skip): Control media playback in Bluetooth and USB modes.
Sound Modes
The Majority Saxon Soundbar features various sound modes to optimize your listening experience:
- Equalizer (EQ) Presets: Use the 'EQ' button on the remote control to switch between different audio profiles:
- Music: Optimized for music playback, providing balanced audio.
- Movie: Enhances cinematic sound effects and dialogue for an immersive movie experience.
- Voice: Boosts vocal clarity, ideal for news, podcasts, or dialogue-heavy content.
- 3D Sound Mode: Activate the 3D sound mode using the '3D' button on the remote control. This mode creates a virtual surround sound effect, expanding the soundstage and immersing you further into the audio.
Maintenance
To ensure the longevity and optimal performance of your soundbar, follow these maintenance guidelines:
- Cleaning: Use a soft, dry cloth to clean the surface of the soundbar. Do not use abrasive cleaners, waxes, or solvents.
- Ventilation: Ensure the soundbar has adequate ventilation. Do not block any ventilation openings.
- Environment: Avoid exposing the soundbar to extreme temperatures, humidity, direct sunlight, or dusty environments.
- Power Off: Always turn off and unplug the soundbar from the power outlet when not in use for extended periods or during electrical storms.
Troubleshooting
If you encounter issues with your soundbar, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| No power | Power cable not connected; Power outlet not active. | Ensure the power cable is securely connected to the soundbar and a working power outlet. |
| No sound | Incorrect input source; Volume too low; Cables not connected properly; TV audio output settings incorrect. | Select the correct input source. Increase volume. Check all audio cables are securely connected. Adjust TV audio output settings to external speakers or the specific input (e.g., HDMI ARC, Optical). |
| Bluetooth pairing fails | Soundbar not in pairing mode; Device too far; Bluetooth disabled on device. | Ensure the soundbar is in Bluetooth mode ('BT' displayed). Move your device closer to the soundbar. Enable Bluetooth on your device and try searching again. |
| Remote control not working | Batteries depleted; Obstruction between remote and soundbar; Incorrect remote angle. | Replace batteries. Ensure a clear line of sight to the soundbar's IR receiver. Point the remote directly at the soundbar. |
| Distorted sound | Volume too high; Poor audio source quality; Loose cable connection. | Reduce volume. Try a different audio source. Check cable connections. |
Specifications
| Brand | MAJORITY |
| Model Name | Saxon |
| Speaker Type | Soundbar |
| Connectivity Technology | Bluetooth, HDMI ARC, Optical, Auxiliary, USB |
| Maximum Speaker Output Power | 80 Watts |
| Audio Output Mode | 3D, Stereo, Voice |
| Special Features | Bluetooth, 3D sound |
| Mounting Type | Tabletop Mount |
| Material | Metal, Plastic |
| Color | Black |
| Control Method | Remote Control |
| Speaker Size | 2 Inches |
| Bluetooth Range | 10 Meters |
| Item Dimensions (D x W x H) | 9.5 x 50 x 6.5 cm |
| Item Weight | 1100 Grams |
| Power Source | Corded Electric |
| Included Components | Remote control (with 2 AAA batteries), 3.5mm AUX cable, Power adapter |
Warranty and Support
The Majority Saxon Soundbar comes with a 3-year limited warranty, providing peace of mind regarding your purchase. This warranty covers manufacturing defects and ensures reliable performance.
The Majority Saxon soundbar with a prominent "3 Year Extended Warranty" badge, highlighting its durability and manufacturer support.
For technical support, warranty claims, or further assistance, please visit the official Majority website or contact their customer service department. Keep your proof of purchase for warranty validation.
