INGCO High-Pressure Washer (Model INGCO-HPWR25008) User Manual

1. Safety Instructions

Read all safety warnings and instructions carefully before operating the appliance. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury.

General Safety

• Always wear appropriate personal protective equipment, including safety glasses, hearing protection, and protective footwear.
• Never direct the water jet at people, animals, electrical equipment, or the appliance itself.
• Ensure the power supply voltage matches the rating plate on the appliance.
• Do not operate the pressure washer if the power cord or other important parts are damaged.
• Keep children and unauthorized persons away from the operating area.
• Always disconnect the power plug from the outlet before performing any cleaning or maintenance.
• Do not use the appliance in the presence of flammable liquids or gases.
• Use only original replacement parts and accessories.

Electrical Safety

• The appliance must be connected to a power supply that includes a residual current device (RCD) with a tripping current of not more than 30 mA.
• Ensure all electrical connections are dry and protected from water spray.
• Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the power tool. Keep cord away from heat, oil, sharp edges, or moving parts.

2. Product Overview

The INGCO High-Pressure Washer (Model INGCO-HPWR25008) is designed for effective cleaning tasks. It features a powerful copper wire induction motor and an Auto Stop System for enhanced efficiency and safety.

Key Features

• Voltage: 220-240V~50Hz
• Input Power: 2500W
• Max Pressure: 160 Bar (2300 PSI)
• Motor: Copper wire induction motor
• Safety: Auto Stop System (TSS)
• Flow Rate: 6.0 L/min
• Hose Length: 5m steel wired pressure hose

Package Contents

Verify that all items are present and undamaged upon unpacking.

• 1 x Pressure Washer Unit
• 1 x Pressure Lance
• 1 x Pressure Gun
• 1 x 5m Steel Wired Pressure Hose
• 1 x Quick Connector
• 1 x Soap Bottle
• 1 x Water Inlet Connector

This image displays the main pressure washer unit, its integrated hose reel, and the various accessories such as the pressure gun, lance, and high-pressure hose. The unit is yellow and black, indicating the brand's typical color scheme.

3. Setup

Follow these steps to assemble and prepare your pressure washer for first use.

3.1 Attaching the Handle and Wheels (if separate)

Some models may require attaching the handle and wheels. Refer to the diagrams in your specific model's packaging for detailed instructions. Ensure all components are securely fastened.

3.2 Connecting the High-Pressure Hose

1. Uncoil the 5m steel wired pressure hose.
2. Connect one end of the high-pressure hose to the high-pressure outlet on the pressure washer unit. Tighten securely by hand.
3. Connect the other end of the high-pressure hose to the inlet of the pressure gun. Tighten securely.

This image provides a side view of the INGCO pressure washer, highlighting the hose reel and the general layout of the unit, which helps in identifying connection points for the high-pressure hose.

3.3 Connecting the Water Supply

1. Attach the water inlet connector to the water inlet on the pressure washer unit.
2. Connect a standard garden hose (not included) to the water inlet connector.
3. Connect the other end of the garden hose to a water tap.
4. Ensure the water tap is fully open before starting the pressure washer. The water supply must be sufficient to meet the flow rate of 6.0 L/min.
5. Important: Do not run the pressure washer without a water supply, as this can damage the pump.

3.4 Attaching the Lance and Nozzle

1. Insert the pressure lance into the pressure gun and twist until it locks into place.
2. Attach the desired nozzle to the end of the lance. Ensure it is securely fitted.

4. Operating Instructions

Follow these steps for safe and effective operation of your INGCO High-Pressure Washer.

4.1 Starting the Pressure Washer

1. Ensure all connections (water supply, high-pressure hose, lance) are secure.
2. Open the water tap fully.
3. Squeeze the trigger on the pressure gun to purge air from the system until a steady stream of water emerges.
4. Plug the power cord into a suitable electrical outlet.
5. Turn the ON/OFF switch on the pressure washer to the "ON" position. The motor will start.
6. The Auto Stop System (TSS) will automatically shut off the motor when the trigger is released and restart it when the trigger is pressed again.

4.2 Using the Soap Bottle (Detergent Application)

1. Fill the soap bottle with appropriate pressure washer detergent.
2. Attach the soap bottle to the pressure gun or designated detergent inlet (refer to your specific model's diagram).
3. Operate the pressure washer at low pressure (if adjustable) or use the detergent nozzle to apply soap.
4. After applying detergent, remove the soap bottle and rinse the system with clean water before continuing with high-pressure rinsing.

4.3 Stopping the Pressure Washer

1. Turn the ON/OFF switch on the pressure washer to the "OFF" position.
2. Unplug the power cord from the electrical outlet.
3. Turn off the water tap.
4. Squeeze the trigger on the pressure gun to release any remaining pressure in the system.
5. Disconnect the high-pressure hose and water supply hose.

5. Maintenance

Regular maintenance ensures the longevity and optimal performance of your pressure washer.

5.1 Cleaning the Nozzle

If the nozzle becomes clogged, use the provided nozzle cleaning tool (if included) or a thin wire to clear any debris. Rinse the nozzle with water.

5.2 Cleaning the Water Inlet Filter

The water inlet filter prevents debris from entering the pump. Regularly check and clean the filter by rinsing it under running water.

5.3 Storage

• Before storing, ensure all water is drained from the pump, hoses, and accessories to prevent freezing damage.
• Store the pressure washer in a dry, frost-free location.
• Coil the high-pressure hose and power cord neatly.
• Store the pressure gun, lance, and nozzles in their designated holders on the unit (if available) or in a safe place.

This image shows a side profile of the INGCO pressure washer, clearly displaying the translucent soap bottle attached to the unit, which is important for maintenance and refilling.

6. Troubleshooting

This section addresses common issues you might encounter with your pressure washer.

7. Specifications

Technical data for the INGCO High-Pressure Washer Model INGCO-HPWR25008.

8. Warranty & Support

INGCO products are manufactured to high-quality standards and are guaranteed against manufacturing defects. Please retain your proof of purchase for warranty claims.

Warranty Information

Specific warranty terms and conditions may vary by region. For detailed warranty information, please refer to the warranty card included with your product or visit the official INGCO website.

Customer Support

For technical assistance, spare parts, or service inquiries, please contact your local INGCO dealer or authorized service center. You can find contact information on the official INGCO website or through your retailer.

When contacting support, please have your product model number (INGCO-HPWR25008) and serial number (if applicable) ready.
