Ocean Loong AB18G
Ocean Loong AB18G Bladeless Tower Fan User Manual
Model: AB18G | Brand: Ocean Loong
Introduction
Thank you for choosing the Ocean Loong AB18G Bladeless Tower Fan. This manual provides essential information for the safe and efficient operation of your new fan. Please read it thoroughly before use and retain it for future reference.
Figure 1: Ocean Loong AB18G Bladeless Tower Fan and Remote Control.
Safety Instructions
- Always place the fan on a stable, flat surface to prevent tipping.
- Do not insert fingers or foreign objects into the air outlet or inlet.
- Keep the fan away from water or other liquids.
- Unplug the fan from the power outlet before cleaning or maintenance.
- Ensure the power cord is not damaged or pinched.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- The fan features Tip-Over Protection, automatically powering off if tilted beyond 30 degrees.
- It also includes Overheat Protection, automatically shutting off if the ambient temperature reaches 95°F (35°C).
Figure 2: Safety features including tip-over and overheat protection.
Package Contents
Please check the package for the following items:
- Ocean Loong AB18G Bladeless Tower Fan
- Remote Control
- User Manual (this document)
Setup
The Ocean Loong AB18G Bladeless Tower Fan comes pre-assembled and ready for use. Simply place it on a flat, stable surface and plug it into a standard 120V AC power outlet.
Figure 3: The bladeless design ensures safety for children and pets.
Operating Instructions
Control Panel (Touch Screen)
The fan features a touch-sensitive control panel on its base. The buttons are:
- Power On/Off: Turns the fan on or off.
- Speed Control: Adjusts the fan speed from 1 to 9 levels.
- Oscillation: Activates or deactivates the 90° oscillation feature.
- Timer: Sets the fan to automatically turn off after a set period (1-10 hours).
Figure 4: Remote Control Layout. The fan's base has similar touch controls.
Remote Control
The included remote control allows for convenient operation from a distance. It requires a CR2025 battery (not included). The remote features buttons for:
- Power On/Off
- Speed Up/Down
- Timer Up/Down
- Rotation (Oscillation)
- Max Speeds (direct access to highest speed)
Fan Speeds and Noise Levels
The fan offers 9 speed settings. The noise level varies with speed:
- 1st Fan Speed: Approximately 25dB (suitable for sleeping)
- 5th Fan Speed: Approximately 35dB
- 9th Fan Speed: Approximately 48dB
Figure 5: The fan's quiet operation at lower speeds is ideal for bedrooms.
Modes of Operation
This fan is designed for year-round use, offering both cooling and warming functions (if applicable to the specific model, though the product title only mentions "Air Circulator Fan for Home Air Conditioner"). Based on the provided images, it appears to have both cool and warm air modes.
- Warm Air Mode: Provides warm air quickly.
- Natural Wind Mode: Circulates cool air.
Figure 6: The fan offers both cool and warm air modes for comfort in any season.
Figure 7: Bladeless fan suitable for year-round use, featuring multiple functions.
Video 1: Official product video demonstrating the AB18 Tower Fan's features and operation.
Maintenance
To ensure optimal performance and longevity of your fan, regular cleaning is recommended.
- Cleaning the Exterior: Wipe the exterior surfaces with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- Cleaning the Air Inlet/Outlet: Use a soft brush or vacuum cleaner with a brush attachment to gently remove dust from the air inlets and outlet grilles.
- Ensure the fan is unplugged before any cleaning.
Troubleshooting
If you encounter issues with your Ocean Loong AB18G Bladeless Tower Fan, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Fan does not turn on. | No power, power button not pressed, or tip-over protection activated. | Check power connection. Press the power button. Ensure the fan is upright on a stable surface. |
| Fan stops unexpectedly. | Overheat protection or tip-over protection activated. | Unplug the fan, allow it to cool down for 30 minutes, and ensure it is on a stable, upright surface before plugging it back in. |
| "E1" or "E2" error code displayed. | Internal malfunction or sensor error. | Unplug the fan for a few minutes, then plug it back in. If the error persists, contact customer support. |
| Weak airflow. | Low speed setting or blocked air inlets/outlets. | Increase the fan speed. Clean any dust or obstructions from the air inlets and outlets. |
| Unusual noise. | Dust accumulation or internal component issue. | Clean the fan thoroughly. If the noise persists, contact customer support. |
Specifications
| Feature | Detail |
|---|---|
| Brand | Ocean Loong |
| Model Number | AB18G |
| Color | Grey/Silver |
| Electric Fan Design | Floor Fan / Tower Fan |
| Room Type | Bedroom, Living Room |
| Recommended Uses | Indoor, Home |
| Voltage | 120 Volts |
| Control Method | Remote, Touch Screen |
| Blade Material | Plastic (Bladeless Design) |
| UPC | 725786285211 |
| Product Dimensions | 9.4 x 6.3 x 31.5 inches |
| Item Weight | 7.43 pounds |
| Oscillation | 90° |
| Speeds | 1-9 Speeds |
| Timer | 1-10 Hours |
| Noise Level | 28-48 dB |
Figure 8: Key specifications of the Ocean Loong AB18G Bladeless Tower Fan.
Warranty and Support
Ocean Loong products are designed for reliability and performance. For warranty information or technical support, please refer to the contact details provided on the product packaging or visit the official Ocean Loong website. Please retain your proof of purchase for warranty claims.
