Lepro 32.8ft Smart LED Strip Lights Instruction Manual

Introduction

Welcome to your new Lepro 32.8ft Smart LED Strip Lights. This manual provides detailed instructions for installation, operation, and maintenance to ensure optimal performance and longevity of your product. Please read this guide thoroughly before use.

The Lepro 32.8ft Smart LED Strip Lights product packaging, showcasing the strip, remote, and app control features.

Safety Information

To prevent injury or product damage, please observe the following safety precautions:

• This product is designed for indoor use only. Do not expose to water or moisture.
• Ensure the power supply voltage matches the product's requirements (12V DC).
• Do not cut the LED strip while it is connected to power.
• Avoid bending the LED strip sharply, as this can damage the circuit and LEDs.
• Keep out of reach of children.
• Do not cover the LED strip with flammable materials.
• If any damage occurs, discontinue use immediately and contact customer support.

Package Contents

Verify that all items are present in your package:

• 32.8ft (2 x 16.4ft rolls) LED Strip Lights
• Smart Controller
• IR Remote Control
• Power Adapter
• User Manual

Setup Guide

1. Preparation

Before installation, ensure the desired surface is clean, dry, and smooth. Unroll the LED strip completely before powering it on to prevent overheating.

2. Physical Installation

The LED strip features a strong 3M adhesive backing. Carefully peel off the protective layer and press the strip firmly onto the desired surface. For corners or intricate designs, avoid sharp bends. If necessary, use appropriate connectors (not included) to maintain the strip's integrity.

An image showing the LED strip lights installed along a wall, demonstrating flexible placement options.

3. Power Connection

Connect the LED strip to the smart controller, ensuring the arrows on both components align. Then, connect the smart controller to the power adapter. Finally, plug the power adapter into a standard electrical outlet.

4. App Download and Setup

Download the "Lepro LampUX" app from the App Store (for iOS devices) or Google Play Store (for Android devices). Register a new account or log in if you already have one.

5. Device Pairing

Ensure your phone's Bluetooth is enabled and connected to a 2.4GHz Wi-Fi network. Note: 5GHz Wi-Fi networks are not supported. Power on the LED strip lights. If the lights are not blinking rapidly, long-press the controller button until they begin to blink rapidly. In the app, tap "Add Device" or the "+" icon, then select "Strip Lights (Wi-Fi)". Follow the on-screen prompts to complete the pairing process.

A smartphone screen displaying the 'Lepro LampUX' app interface with a color wheel and brightness controls, alongside the LED strip lights.

Operating Instructions

1. App Control

The "Lepro LampUX" app provides comprehensive control over your LED strip lights:

• Color Selection: Choose from 16 million colors using the intuitive color wheel.
• Brightness Adjustment: Easily adjust the light intensity to suit your mood or environment.
• Scene Modes: Select from various pre-set scenes or create custom lighting effects.
• Timer Function: Schedule your lights to automatically turn on or off at specific times.

An image showing a person controlling the LED strip lights in a house from a smartphone app, highlighting the remote control feature.

2. Remote Control

Use the included IR remote control for convenient basic functions:

• Power On/Off
• Direct Color Selection (pre-set buttons)
• Brightness Up/Down

The included remote control for the LED strip lights, showing buttons for power, color selection, and brightness adjustment.

3. Voice Control

Your Lepro Smart LED Strip Lights are compatible with Amazon Alexa and Google Assistant. To enable voice control:

1. Open the "Lepro LampUX" app.
2. Navigate to the "Me" tab, then select "Third-Party Services".
3. Choose "Alexa" or "Google Assistant" and follow the on-screen instructions to link your account.

Example voice commands:

• "Alexa, turn on the strip lights."
• "Hey Google, set the strip lights to blue."
• "Alexa, dim the strip lights to 50%."

A woman in a kitchen interacting with a smart speaker to control the LED strip lights, demonstrating voice control functionality.

4. Music Sync Function

The built-in microphone allows the lights to synchronize with music or ambient sounds in the room. Activate this feature through the "Lepro LampUX" app to create dynamic lighting effects that respond to audio, enhancing your entertainment experience.

A couple enjoying music in a room illuminated by LED strip lights that are syncing with the audio, creating a vibrant atmosphere.

5. Timer Setting

Utilize the app's timer function to set schedules for your lights to automatically turn on or off, promoting energy efficiency and convenience.

An image illustrating the timer function of the LED strip lights, showing lights turning off at bedtime and on in the morning.

Maintenance

Proper maintenance ensures the longevity and performance of your LED strip lights:

• Cleaning: Gently wipe the LED strip with a dry, soft cloth to remove dust. Do not use harsh chemicals, abrasive cleaners, or excessive moisture.
• Connection Check: Periodically inspect all connections (strip to controller, controller to power adapter) to ensure they are secure.
• Storage: If storing the lights for an extended period, ensure they are clean, dry, and stored in a cool, dark place.

Troubleshooting

Lights not turning on:

• Check all power connections to ensure they are secure.
• Verify that the power adapter is plugged into a functional electrical outlet.
• Ensure the remote control has working batteries and is pointed directly at the controller.

Lights not connecting to Wi-Fi:

• Confirm your Wi-Fi network is 2.4GHz. 5GHz networks are not compatible.
• Ensure the LED strip lights are blinking rapidly, indicating they are in pairing mode.
• Double-check your Wi-Fi password for accuracy.
• Move the LED strip lights closer to your Wi-Fi router to improve signal strength.

Adhesive not sticking:

• Ensure the installation surface was thoroughly cleaned, dry, and smooth before applying the strip.
• For rough, textured, or uneven surfaces, the adhesive may not hold effectively. Consider using additional mounting clips or a stronger adhesive solution (not included) for better adherence.

Inconsistent colors or sections not lighting up:

• This may indicate physical damage to the LED strip. Avoid excessive bending, twisting, or pulling.
• If the issue persists after checking connections and power, contact customer support for further assistance.

Specifications

Warranty and Support

For detailed warranty information, product registration, or technical support, please visit the official Lepro website or contact their customer service team. Keep your purchase receipt for warranty claims.

Online Support: www.lepro.com/support

Email: support@lepro.com
