FLEXISPOT S01 Under Desk Drawer Instruction Manual

1. Product Overview

The FLEXISPOT S01 Under Desk Drawer is designed to optimize your workspace by providing convenient and secure storage directly beneath your desk. This lockable drawer helps keep your desktop clear and organized, offering a discreet solution for office supplies and personal items. Its robust construction and smooth-gliding mechanism ensure reliable daily use.

Image 1.1: Front view of the FLEXISPOT S01 Under Desk Drawer.

Image 1.2: Illustration of how the drawer helps save space and organize your desk.

Key Features:

• Space-Saving Design: Integrates seamlessly under your desk to free up desktop space.
• Smooth Operation: Equipped with rolling glides for effortless opening and closing.
• Secure Storage: Features a lock with two keys to protect confidential documents and valuables.
• Durable Construction: Made from steel with a PVC front panel for longevity.
• Generous Capacity: Can hold up to 10 kg of items.

2. Specifications

3. Package Contents

Please ensure all the following items are included in your package:

• FLEXISPOT S01 Under Desk Drawer
• Mounting hardware (bolts, screws)
• Installation template
• Screwdriver
• 2 Keys for the lock

4. Installation Instructions

Follow these steps for quick and easy installation of your FLEXISPOT S01 drawer:

1. Prepare Workspace: Clear the area under your desk where the drawer will be installed. Ensure the desk surface is clean, stable, and thick enough to support the drawer's weight and mounting screws.
2. Position Template: Use the provided installation template to accurately mark the drilling points on the underside of your desk. Ensure the drawer will be positioned correctly and will not interfere with desk legs or other components.
3. Drill Pilot Holes: Carefully drill pilot holes at the marked points. Use a drill bit appropriate for your desk material and the provided screws.
4. Attach Mounting Brackets: Secure the mounting brackets to the underside of the desk using the provided bolts and screws. Ensure they are firmly attached and level.


Image 4.1: Underside view illustrating the mounting brackets and sliding mechanism.

5. Mount the Drawer: Slide the drawer assembly onto the mounted brackets. Ensure the sliding mechanism engages correctly and the drawer moves freely.
6. Test Functionality: Gently pull the drawer open and push it closed to ensure smooth operation. Test the locking mechanism with the provided keys.

Note: For optimal installation and stability, it is recommended to have assistance from another person, especially when aligning and securing the drawer.

5. Operation

Operating your FLEXISPOT S01 drawer is straightforward:

• Opening the Drawer: Gently pull the drawer handle to slide it open. The smooth-gliding tracks allow for easy access to your stored items.
• Closing the Drawer: Push the drawer firmly until it is fully closed and flush with the desk.
• Locking the Drawer: Insert one of the provided keys into the lock on the front panel. Turn the key clockwise to engage the locking mechanism. Remove the key to secure the contents.
• Unlocking the Drawer: Insert the key and turn it counter-clockwise to disengage the lock. The drawer can then be opened.
• Storage: Place items within the drawer, ensuring not to exceed the maximum weight capacity of 10 kg. The interior felt lining helps protect contents and reduce noise.

Image 5.1: The drawer fully open, revealing its interior storage capacity.

6. Maintenance

Regular maintenance will ensure the longevity and smooth operation of your drawer:

• Cleaning: Wipe the exterior and interior surfaces of the drawer with a soft, damp cloth. Avoid abrasive cleaners, harsh chemicals, or solvents that may damage the finish.
• Sliding Mechanism: Periodically check the sliding tracks for any debris, dust, or obstructions. Clean the tracks as necessary to ensure smooth operation. A dry cloth or soft brush can be used.
• Hardware Check: Occasionally inspect all mounting bolts and screws to ensure they remain tight. Tighten any loose hardware to maintain stability and prevent wobbling.

7. Troubleshooting

If you encounter any issues with your FLEXISPOT S01 drawer, refer to the following common problems and solutions:

• Problem: Drawer does not slide smoothly.
  Solution:

  • Check the sliding tracks for any obstructions or dirt. Clean the tracks if necessary.
  • Ensure the drawer is not overloaded beyond its 10 kg capacity. Remove some items if it feels too heavy.
  • Verify that the mounting hardware is securely fastened and the drawer is installed level. Loose screws or an uneven installation can affect sliding.
• Problem: Drawer does not lock or unlock.
  Solution:

  • Ensure the drawer is fully closed and flush with the desk before attempting to lock it.
  • Check if the key is fully inserted and turned correctly in the lock mechanism.
  • If the lock mechanism appears damaged or jammed, do not force it. Contact customer support for assistance.

8. Warranty and Support

For warranty information, technical assistance, or replacement parts, please contact FLEXISPOT customer service. Refer to your purchase documentation or the official FLEXISPOT website for specific warranty terms, contact details, and support resources.

FLEXISPOT is committed to providing high-quality products and customer satisfaction. Do not attempt to repair the product yourself if it is under warranty, as this may void the warranty.
