1. Product Overview
The Phomemo M110 is a versatile thermal label printer designed for both smartphone and PC use. It supports various label types for applications such as mailing addresses, price tags, food labeling, package shipping, DIY projects, and organization. This compact and portable device offers efficient printing for both personal and business needs.
1.1 Package Contents
Please verify that all items are present in your package:
- Phomemo M110 Printer Unit
- 40*30mm Sample Label Roll
- Type-C Charging Cable
- User Manual (this document)
Image: Phomemo M110 printer, sample label roll, and charging cable.
1.2 Product Components
Familiarize yourself with the different parts of your Phomemo M110 printer:
- Top Cover: Protects the label compartment.
- Display: Shows printer status and information.
- Power/Menu Button: Turns the printer on/off and navigates menus.
- Paper Feed/Select Button: Feeds labels or confirms selections.
- Label Output Slot: Where printed labels exit.
- Type-C Cable Connection Port: For charging and PC connection.
- Reset Hole: For factory reset (use a pin).
Image: Detailed view of the Phomemo M110 printer with labels indicating its various parts.
2. Setup
2.1 Initial Preparation
- Remove any protective films from the printer.
- Press and hold the Power button for 3 seconds until the display lights up.
- The printer is now ready for use.
2.2 Loading Labels
The M110 printer supports die-cut labels with widths ranging from 20mm to 50mm. Ensure the labels are thermal-sensitive and have a protective coating for water, oil, and durability.
- Open the top cover of the printer.
- Place the label roll into the paper cassette, ensuring the printing side faces upwards.
- Close the top cover.
- Press the paper feed button to automatically position the label.
Image: The Phomemo M110 printer with the top cover open, showing how to insert a label roll.
2.3 Mobile App Installation (Print Master)
The 'Print Master' app is required for smartphone and tablet operation. It offers various frames, fonts, templates, and icons for label customization.
- Search for 'Print Master' on the App Store (iOS) or Google Play (Android).
- Download and install the application.
- Open the 'Print Master' app.
- Tap 'Auto Connect' and allow necessary permissions. The app will automatically search for and connect to your M110 printer.
Video: Phomemo M110 Quick Start Guide, demonstrating initial setup and mobile app connection.
2.4 PC Software Installation (Labelife)
For PC connectivity, the M110 supports Mac OS and Windows 10 via USB. (Note: Linux and Chromebook systems are not supported).
- Visit the official Phomemo website, navigate to 'Support' -> 'Download Center', and select M110 to download the driver. Alternatively, visit labelife.net.
- Download the appropriate 'Labelife' software for your operating system (Windows or Mac).
- Install the software by following the on-screen instructions.
Video: Guide on downloading and installing the PC application for the Phomemo M110 printer.
3. Operating Instructions
3.1 Connecting to a Smartphone/Tablet (Bluetooth)
- Ensure Bluetooth is enabled on your smartphone or tablet.
- Open the 'Print Master' app.
- The app will automatically detect and connect to your M110 printer. If not, tap 'Auto Connect' or manually select your printer from the device list.
Image: Visual guide for connecting the M110 printer to a smartphone or tablet via Bluetooth.
3.2 Connecting to a PC (USB)
- Connect the M110 printer to your PC using the provided Type-C USB cable.
- Open the 'Labelife' software on your PC.
- The software should automatically detect and connect to the printer. If not, follow the software's prompts to add a printer.
Image: Visual guide for connecting the M110 printer to a PC via USB cable.
3.3 Creating and Printing Labels
Both the 'Print Master' app and 'Labelife' software offer extensive customization options for your labels, including text, QR codes, barcodes, images, and various templates.
- Select your desired label size within the app/software.
- Design your label using the available tools (text, icons, barcodes, etc.).
- Preview your label to ensure accuracy.
- Click the 'Print' button to send the label to the printer.
Image: A smartphone displaying the 'Print Master' app interface for designing labels.
Image: Overview of additional app functions including voice-to-text, barcode/QR code recognition, OCR, and PDF/Excel printing.
4. Maintenance
To ensure optimal performance and longevity of your Phomemo M110 printer, regular maintenance is recommended.
- Cleaning the Print Head: Use a soft, lint-free cloth lightly dampened with isopropyl alcohol to gently wipe the print head. Ensure the printer is off and cool before cleaning.
- Cleaning the Exterior: Wipe the exterior of the printer with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials.
- Storage: Store the printer in a cool, dry place away from direct sunlight and extreme temperatures. Remove the label roll if storing for an extended period.
- Battery Care: For optimal battery life, avoid fully discharging the battery frequently. Charge the printer regularly, even if not in use, to maintain battery health.
5. Troubleshooting
If you encounter issues with your Phomemo M110 printer, refer to the following common troubleshooting steps:
| Problem | Possible Cause | Solution |
|---|---|---|
| Printer does not turn on | Low battery; Power button not pressed long enough | Charge the printer; Press and hold the Power button for 3 seconds. |
| Cannot connect via Bluetooth | Bluetooth off on device; Printer not discoverable; App permissions denied | Ensure Bluetooth is on; Restart printer; Grant app location/Bluetooth permissions. |
| Poor print quality | Dirty print head; Incorrect label type; Low battery | Clean print head; Use genuine Phomemo thermal labels; Charge printer. |
| Labels not feeding correctly | Label roll incorrectly inserted; Labels jammed | Re-insert label roll correctly; Clear any jammed labels. |
If the issue persists after trying these steps, please contact Phomemo customer support.
6. Specifications
| Feature | Specification |
|---|---|
| Product Dimensions | 11.4 x 6.3 x 8.7 cm (Depth x Width x Height) |
| Max Media (Paper) Size | 50mm |
| Included Components | 40*30mm Sample Label Roll, Type-C Charging Cable, M110 Printer Unit, User Manual |
| Print Media | Labels |
| Scanner Type | Portable |
| Max Sheet Capacity | 100 |
| Max Copy Speed (B&W) | 45 pages/minute |
| Compatible Devices | Smartphones, Tablets, Desktop PCs, Laptops |
| Sheet Size | 20~50mm |
| Max Print Resolution (Monochrome) | 300 dpi |
| Duplex Printing | No |
| Batteries | 1 Lithium Ion battery (included) |
| Color | White |
| Form Factor | Printer |
| Connectivity Technology | Bluetooth, USB |
| OS | Android, iOS |
| Lithium Battery Energy Content | 8.88 Watt Hours |
| Lithium Battery Packaging | Batteries contained in equipment |
| Lithium Ion Cell Count | 2 |
| Item Weight | 228 g |
7. Warranty and Support
Phomemo products are designed for reliability and performance. For warranty information and customer support, please refer to the following:
- Warranty: Please consult the warranty card included in your product packaging for specific terms and conditions.
- Customer Support: For technical assistance, troubleshooting, or any product-related inquiries, please visit the official Phomemo website at www.phomemo.com or contact their customer service team directly.
