KHOI1971 Wall Charger AC Adapter Instruction Manual

Introduction

This instruction manual provides essential information for the safe and effective use of your KHOI1971 Wall Charger AC Adapter. This charger is specifically designed for use with the Frozen 2 Sing & Ride Quad Ride-on models KT1515TG and KT1515, which utilize a 6V-Volt battery. Please read this manual thoroughly before first use to ensure proper operation and to prevent damage to the charger or your device.

Image: The KHOI1971 Wall Charger AC Adapter, showing the main unit with specifications, the power cord, and the distinctive grey battery connector.

Important Safety Information

Always observe the following safety precautions to reduce the risk of fire, electric shock, or injury:

• Use this charger only with the specified Frozen 2 Sing & Ride Quad Ride-on models (KT1515TG, KT1515) that have a GREY BATTERY PLUG. Using it with incompatible devices or battery plugs (e.g., black battery plugs) may cause damage or fire.
• Do not expose the charger to rain or moisture.
• Do not operate the charger if it has been damaged in any way.
• Unplug the charger from the wall outlet when not in use.
• Keep out of reach of children.
• This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov.

Compatibility and Identification

It is critical to verify the compatibility of your ride-on toy's battery plug before using this charger. This charger is ONLY compatible with the Frozen 2 Sing & Ride Quad Ride-on models KT1515TG and KT1515 that feature a GREY BATTERY PLUG. There are versions of this ride-on toy with different battery plug types (e.g., black plugs) that are NOT compatible with this charger.

Image: A visual warning emphasizing that this charger is exclusively for models with a GREY battery plug, and explicitly states it is NOT for black battery plug models.

Image: A close-up view of the grey battery plug connector, showing its distinct color and shape for identification.

If you are unsure about your ride-on's battery plug type, please consult the ride-on's original manual or contact the manufacturer with a picture of your battery plug for verification.

Setup

1. Unpack: Carefully remove the charger from its packaging. Inspect it for any visible damage.
2. Locate Battery Port: On your Frozen 2 Sing & Ride Quad, locate the battery charging port. Ensure it matches the grey plug of the charger.
3. Connect Charger to Battery: Firmly insert the grey battery plug of the charger into the ride-on's battery charging port. Ensure a secure connection.
4. Connect to Power Outlet: Plug the charger's AC adapter into a standard wall outlet (100-240V).

Image: The Frozen 2 Sing & Ride Quad Ride-on toy, illustrating the device this charger is designed for.

Operating Instructions

Once the charger is connected to both the ride-on's battery and a power outlet, the charging process will begin automatically. The charger does not feature an indicator light to show charging status. Therefore, it is important to follow the recommended charging times provided in your ride-on toy's original manual.

• Initial Charge: For first-time use or after extended storage, a full initial charge is recommended. Refer to your ride-on's manual for specific initial charging duration.
• Recharge Time: Typical recharge times for a depleted 6V battery can range from 8 to 12 hours. Avoid overcharging.
• Disconnecting: Once charging is complete, first unplug the charger from the wall outlet, then disconnect the grey plug from the ride-on's battery port.

Note: This charger is designed to provide a consistent charge. The absence of an indicator light means you must rely on the ride-on's battery life or the manufacturer's recommended charging schedule.

Maintenance

• Cleaning: Disconnect the charger from all power sources before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use liquid cleaners or solvents.
• Storage: Store the charger in a cool, dry place away from direct sunlight and extreme temperatures. Keep the cord neatly coiled.
• Inspection: Periodically inspect the charger's cord and plug for any signs of damage, such as fraying, cuts, or bent prongs. Do not use if damaged.

Troubleshooting

Specifications

• Model Number: KHOI1971 CUSTOM MADE
• Input Voltage: 100-240 Volts
• Amperage: 1 Amps
• Wattage: 240 watts
• Connectivity Technology: Plug
• Connector Type: Barrel Connector (Grey Plug)
• Compatible Devices: KT1515TG, KT1515 Kidtrax Frozen 2 Sing & Ride Quad Ride-on 6V-Volt Battery (with Grey Plug)
• Item Weight: 8 ounces
• Included Components: Wall Charger

Warranty and Support

For information regarding warranty, returns, or technical support, please contact the seller directly through the platform where the product was purchased. The manufacturer is KHOI1971 ® CUSTOM MADE.

Seller: KHOI1971
