Blade RC Helicopter 120 S2 BNF Instruction Manual

1. Safety Information

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

2. What's in the Box

• (1) Fully Assembled 120 S2 Helicopter
• (1) USB LiPo Battery Charger
• (1) E-flite 500mAh 1S 3.7V 25C Li-Po Flight Battery
• (1) Tools and Extras
• Product Manual

Image: The Blade 120 S2 RC Helicopter, fully assembled and ready for use.

3. Setup

The Blade 120 S2 RC Helicopter comes fully assembled, requiring no complex building. However, as a Bind-N-Fly (BNF) product, a compatible transmitter is required and not included in the box. You will need to bind your chosen Spektrum 6-Channel Receiver compatible transmitter to the helicopter.

3.1. Transmitter Requirement

This model requires a separate transmitter to operate. Ensure you have a compatible Spektrum 6-Channel Receiver transmitter. Refer to your transmitter's manual for specific binding instructions.

Image: An icon indicating that a transmitter is needed to complete the setup of the helicopter.

3.2. Battery Charging

Before first flight, fully charge the included E-flite 500mAh 1S 3.7V 25C Li-Po Flight Battery using the provided USB LiPo Battery Charger. Connect the battery to the charger and plug the charger into a suitable USB power source. The charging indicator light on the charger will show the charging status. Disconnect the battery once fully charged.

3.3. Binding Procedure

To bind your transmitter to the Blade 120 S2, follow these general steps:

1. Ensure the helicopter's battery is disconnected.
2. Put your Spektrum transmitter into bind mode (refer to your transmitter's manual).
3. Connect the flight battery to the helicopter. The receiver's LED will flash rapidly, indicating it's in bind mode.
4. Once bound, the receiver's LED will turn solid. Disconnect the battery from the helicopter, then power off your transmitter.
5. Reconnect the battery to the helicopter and then power on your transmitter. The system should now be linked.

4. Operating Instructions

The Blade 120 S2 is designed for ease of flight, making it suitable for beginner RC pilots while offering agility for seasoned enthusiasts. It features SAFE Select flight envelope protection for enhanced stability.

4.1. Pre-Flight Checks

• Ensure the flight battery is fully charged and securely installed.
• Verify that your transmitter batteries are fully charged.
• Check all rotor blades and tail rotor for any damage or cracks.
• Confirm all control surfaces move freely and correctly in response to transmitter inputs.
• Perform a range check of your radio system before the first flight of the day.

4.2. Take-off and Flight

Place the helicopter on a flat, level surface. Slowly increase the throttle. The helicopter will lift off smoothly. Utilize the SAFE Select technology for stable flight, especially if you are a beginner. This fixed-pitch, flybarless design offers both speed and agility.

4.3. Landing

To land, slowly reduce the throttle while maintaining control. Aim for a gentle descent. Once on the ground, fully reduce the throttle to stop the rotors. Disconnect the flight battery immediately after landing to prevent accidental startup.

5. Maintenance

Regular maintenance ensures the longevity and optimal performance of your Blade 120 S2 helicopter.

• After Each Flight: Inspect the main rotor blades, tail rotor, landing gear, and canopy for any signs of damage. Check for loose screws or connections.
• Cleaning: Use a soft, dry cloth to clean the helicopter. Avoid using solvents or harsh chemicals.
• Motor and Gearbox: Periodically check the main motor and tail motor for debris. Ensure the main gear meshes correctly with the motor pinion.
• Battery Care: Store LiPo batteries at a storage voltage (around 3.8V per cell) if not used for extended periods. Never fully discharge or overcharge batteries.
• Replacement Parts: If any part is damaged, replace it with genuine Blade spare parts to maintain performance and safety.

6. Troubleshooting

This section provides solutions to common issues you might encounter with your Blade 120 S2 helicopter.

7. Specifications

8. Warranty and Support

For warranty information and technical support, please refer to the official Blade product website or contact Horizon Hobby, LLC customer service. Keep your proof of purchase for any warranty claims.

For the most up-to-date information, product registration, and additional resources, visit the manufacturer's website.
