Greenworks 48V (2x24V) Cordless Lawn Mower G24X2LM36K2X Instruction Manual

1. Product Overview

This Greenworks 48V (2x24V) cordless lawn mower is designed for efficient lawn care. It operates using two 24V lithium-ion batteries, providing the power of a 48V system. Key features include a 36 cm cutting width, 5-position cutting height adjustment (20-70 mm), and a 40-liter grass collection bag. The mower also offers a 2-in-1 function for collecting or mulching grass clippings. Its foldable handle allows for compact storage. This manual provides essential information for safe assembly, operation, maintenance, and troubleshooting.

Image 1.1: Greenworks 48V cordless lawn mower in operation, illustrating its key features.

2. Setup and Assembly

Follow these steps to assemble your Greenworks lawn mower before first use.

2.1 Unpacking

1. Carefully remove all components from the packaging.
2. Check the contents against the packing list to ensure all parts are present and undamaged.

2.2 Handle Assembly

1. Unfold the lower handle section and secure it in place using the provided knobs or levers.
2. Attach the upper handle section to the lower section, ensuring all cables are routed correctly and not pinched. Tighten any fasteners securely.

2.3 Grass Collection Bag Assembly

Assemble the grass collection bag according to the instructions provided with the bag. Typically, this involves attaching the fabric bag to the frame.

Image 2.1: The lawn mower with the grass collection bag properly installed.

2.4 Battery Installation

1. Ensure the batteries are fully charged before first use. Refer to the battery charger manual for charging instructions.
2. Open the battery compartment cover on the mower.
3. Insert both 24V batteries into their respective slots until they click into place.
4. Close the battery compartment cover securely.

Image 2.2: The lawn mower with its two 24V batteries and dual charger.

3. Operating Instructions

Familiarize yourself with the controls and safety features before operating the lawn mower.

3.1 Starting the Mower

1. Ensure the safety key is inserted into its slot.
2. Press and hold the safety button on the handle.
3. While holding the safety button, pull the bail switch lever towards the handle. The motor will start.
4. Release the safety button, but continue to hold the bail switch lever to keep the mower running.

3.2 Stopping the Mower

Release the bail switch lever. The motor will stop immediately. Always remove the safety key when the mower is not in use or unattended.

3.3 Adjusting Cutting Height

The cutting height can be adjusted to 5 positions, from 20 mm to 70 mm.

1. Ensure the mower is turned off and the safety key is removed.
2. Locate the central height adjustment lever on the side of the mower deck.
3. Pull the lever outwards and move it to the desired cutting height position.
4. Release the lever to lock it into place. Ensure all wheels are at the same height setting.

Image 3.1: Detail of the cutting height adjustment lever.

3.4 Mowing Techniques

• For best results, mow dry grass.
• Overlap cutting swaths slightly to ensure an even cut.
• Avoid cutting more than one-third of the grass height at a time.
• The mower offers 2-in-1 functionality: grass collection or mulching. To mulch, ensure the mulching plug is inserted and the grass bag is removed. To collect, remove the mulching plug and attach the grass bag.

Image 3.2: The mower performing its 2-in-1 function, either mulching or collecting grass.

4. Maintenance

Regular maintenance ensures optimal performance and extends the life of your lawn mower.

4.1 General Cleaning

1. Always remove the safety key and batteries before cleaning or performing any maintenance.
2. Clean the mower deck and blade area after each use to prevent grass buildup. Use a brush or cloth; avoid using water directly on electrical components.
3. Empty and clean the grass collection bag regularly.

4.2 Blade Care

• Inspect the blade regularly for sharpness and damage. A dull or damaged blade can lead to an uneven cut and strain the motor.
• If the blade needs sharpening or replacement, contact a qualified service technician or refer to the detailed service manual.

4.3 Battery Care and Storage

• Store batteries in a cool, dry place, away from direct sunlight and extreme temperatures.
• For long-term storage, charge batteries to approximately 50% capacity.
• Do not store batteries in a discharged state.

4.4 Storage

The mower features a foldable handle for compact storage.

1. Ensure the mower is clean and dry.
2. Remove the safety key and batteries.
3. Fold the handle down as instructed in the assembly section.
4. Store the mower in a dry, secure location, out of reach of children.

Image 4.1: The lawn mower with its handle folded for convenient storage.

5. Troubleshooting

This section addresses common issues you might encounter. For problems not listed here, contact customer support.

6. Technical Specifications

7. Warranty and Support

7.1 Warranty Information

This Greenworks lawn mower comes with a three-year product warranty. The included batteries are covered by a two-year warranty. Please retain your proof of purchase for warranty claims. The warranty covers defects in materials and workmanship under normal use.

7.2 Customer Support

For technical assistance, spare parts, or warranty claims, please contact Greenworks customer support. Refer to the Greenworks official website or your purchase documentation for contact details specific to your region.

• Online Resources: Visit the official Greenworks website for FAQs, product registration, and additional support materials.
• Service Centers: For repairs or professional assistance, locate an authorized Greenworks service center near you.
