Introduction
This instruction manual provides essential information for the proper use, installation, and maintenance of the Bosch Service Pack, part number 1 617 000 189. This kit contains critical wear and tear components designed to restore optimal performance to compatible hammer drills. Please read this manual thoroughly before attempting any installation or maintenance procedures.
Package Contents
The Bosch Service Pack includes a selection of wear and tear parts necessary for routine maintenance of compatible tools. The exact contents are detailed in the included spare parts plan.
- Various gaskets
- Protective cap
- Motor carbons
- Small spare parts plan
Note: This Service Pack does not include grease tubes. Appropriate 100 ml grease and ball bearings are sold separately and are not part of this kit.
Image: The Bosch Service Pack (part number 1 617 000 189) in its sealed plastic packaging, showing the label with product details and "Made in Germany". The package contains various components for tool maintenance.
Compatibility
This Service Pack is compatible with the following hammer drill models:
- Bosch GSH 10 C
- Bosch GSH 11 E
- Bosch 11311 EVS (US model)
- Berner BCDH-11
- WÜRTH MH 10-SE
Important: This Service Pack is not compatible with Bosch GBH 11 DE and Bosch 10 DC models.
Installation and Setup
Installation of wear and tear parts requires technical knowledge and adherence to the original equipment manufacturer's service guidelines. Refer to the detailed spare parts plan included in this kit and the service manual for your specific tool model for precise instructions.
- Safety First: Always disconnect the tool from the power supply before beginning any maintenance or installation. Wear appropriate personal protective equipment (PPE).
- Disassembly: Carefully disassemble the tool according to its service manual to access the components requiring replacement. Pay close attention to the order of removal and the position of each part.
- Part Identification: Use the included spare parts plan (part number 1 617 000 189) to identify the correct replacement parts from the Service Pack. Match the new gaskets, protective cap, and motor carbons with the worn components.
- Replacement: Install the new wear parts. Ensure all gaskets are seated correctly to prevent dust and moisture ingress. When replacing motor carbons, ensure they are properly aligned and make good contact.
- Lubrication (if applicable): If your tool's service manual specifies lubrication, apply appropriate grease (not included in this kit) to moving parts as directed.
- Reassembly: Reassemble the tool in reverse order of disassembly, ensuring all fasteners are tightened to the manufacturer's specifications.
- Testing: After reassembly, perform a functional test of the tool in a safe environment before putting it back into regular service.
Maintenance
Regular maintenance, including the timely replacement of wear and tear parts, is crucial for extending the lifespan and ensuring the safe operation of your hammer drill. Follow the maintenance schedule recommended by the tool manufacturer.
- Routine Inspection: Periodically inspect your tool for signs of wear, especially on components like gaskets, brushes, and protective caps.
- Part Replacement: Replace worn parts using components from this Service Pack or other genuine Bosch spare parts as soon as wear is detected to prevent further damage to the tool.
- Cleaning: Keep the tool clean and free from dust and debris, especially around ventilation openings.
- Lubrication: Ensure proper lubrication of internal components as specified in your tool's service manual.
Troubleshooting
If your tool exhibits reduced performance or unusual operation after replacing parts, consider the following:
- Incorrect Part Installation: Double-check that all new parts were installed correctly and securely according to the spare parts plan and tool service manual.
- Gasket Sealing: Ensure all gaskets are properly seated to maintain internal pressure and prevent dust ingress. Improper sealing can lead to performance issues.
- Motor Carbon Contact: Verify that the motor carbons are making proper contact with the commutator and are not stuck.
- Other Worn Components: This Service Pack addresses common wear parts. If issues persist, other components not included in this kit (e.g., ball bearings, gears) may require inspection and replacement.
- Professional Assistance: If you are unable to resolve the issue, consult a qualified service technician or an authorized Bosch service center.
Specifications
| Product Type | Wear and Tear Part Set (Service Pack) |
| Bosch Part Number | 1 617 000 189 |
| Compatibility | Bosch GSH 10 C, GSH 11 E, 11311 EVS; Berner BCDH-11; WÜRTH MH 10-SE |
| Contents | Gaskets, protective cap, motor carbons, spare parts plan |
| Material | Various (specific to each component) |
| Origin | Made in Germany |
Warranty and Support
For warranty information regarding this Bosch Service Pack, please refer to the purchase documentation or contact your authorized Bosch dealer. For technical support or further assistance with installation and maintenance, please consult the service manual for your specific tool model or contact Bosch customer service.
