Keramag Renova Nr.1 WC Seat Plan 500.692.01.1 Instruction Manual

1. Product Overview

This manual provides instructions for the installation, operation, and maintenance of the Keramag Renova Nr.1 WC Seat Plan, model 500.692.01.1. This WC seat features an angular design, a soft-close mechanism for quiet operation, and quick-release hinges for easy cleaning. It is designed for top-fix installation and includes chrome-plated brass hinges for durability.

2. Safety Information

• Read all instructions carefully before installation and use.
• Ensure all components are present and undamaged before beginning installation.
• Do not use abrasive cleaners or harsh chemicals, as these can damage the seat surface and hinge mechanisms.
• Avoid excessive force when opening or closing the seat, despite the soft-close feature.
• Keep small parts out of reach of children to prevent choking hazards.

3. Package Contents

Verify that all the following items are included in your package:

• One (1) Keramag Renova Nr.1 WC Seat Plan
• One (1) Set of Top-Fix Quick-Release Hinges (chrome-plated brass)
• One (1) Set of Mounting Hardware (screws, washers, nuts)

4. Setup and Installation

The Keramag Renova Nr.1 WC Seat Plan is designed for easy top-fix installation. Please refer to the dimension diagrams below to ensure compatibility with your toilet bowl before proceeding.

4.1. Dimensional Overview

Figure 1: Top-down view showing overall width (445mm), inner width (285mm), and front-to-back dimensions (19mm and 22mm).

Figure 2: Front-on side view showing overall length (355mm) and seat thickness (45mm).

Figure 3: Side view showing seat projection (43mm) and front edge thickness (4mm).

4.2. Installation Steps

1. Prepare the Toilet Bowl: Ensure the toilet bowl surface where the seat will be mounted is clean and dry. Remove any old seat and hardware.
2. Position the Hinges: Place the hinge bases into the mounting holes on the toilet bowl. The top-fix design allows you to secure them from above.
3. Secure the Hinges: Insert the provided screws and washers through the hinge bases and into the mounting holes. Tighten them securely using a screwdriver, ensuring the hinges are firmly in place and aligned correctly.
4. Attach the Seat: Align the quick-release pins on the underside of the WC seat with the hinge bases. Press down firmly until you hear a click, indicating the seat is securely locked onto the hinges.
5. Test the Seat: Gently lower the seat and lid to verify the soft-close mechanism functions correctly. Check for any wobbling or misalignment. Adjust hinge position if necessary by loosening and re-tightening the screws.

5. Operating Instructions

5.1. Soft-Close Mechanism

The WC seat is equipped with an integrated soft-close mechanism. To close the seat or lid, simply push it gently downwards. The mechanism will engage, allowing the seat and lid to lower slowly and quietly without slamming, preventing damage and reducing noise.

5.2. Quick-Release Hinges

For thorough cleaning of the toilet bowl and seat, the quick-release hinges allow for easy removal of the seat. Locate the release buttons or levers on the hinge mechanisms (typically at the back of the seat where it connects to the hinges). Press or lift these mechanisms to disengage the seat from the hinges. To reattach, align the seat with the hinges and press down until it clicks into place.

6. Maintenance and Cleaning

Proper maintenance ensures the longevity and hygiene of your WC seat.

• Regular Cleaning: Clean the WC seat regularly with a mild soap solution and a soft cloth.
• Avoid Harsh Cleaners: Do not use abrasive cleaners, scouring pads, strong acids, alkalis, or chlorine-based products, as these can damage the surface finish and hinge components.
• Drying: After cleaning, wipe the seat and hinges dry with a soft, clean cloth to prevent water spots and mineral buildup.
• Hinge Care: Periodically check the hinge screws for tightness and re-tighten if necessary to prevent wobbling.

7. Troubleshooting

• Seat is Loose/Wobbles: Check the hinge mounting screws. Loosen them slightly, adjust the seat for proper alignment, and then re-tighten firmly.
• Soft-Close Not Working Properly: Ensure the hinges are clean and free from debris. If the mechanism slows down significantly or stops working, it may indicate wear. Contact customer support if the issue persists.
• Difficulty Removing/Attaching Seat: Ensure the quick-release buttons/levers are fully engaged or disengaged. Check for any obstructions around the hinge pins.

8. Specifications

9. Warranty and Support

This product is covered by the manufacturer's standard warranty. For specific warranty terms and conditions, please refer to the documentation provided with your purchase or visit the official Keramag website. For technical support, replacement parts, or any other inquiries, please contact Keramag customer service through their official channels.
