BEBANG Dog Training Collar User Manual

Introduction

Thank you for choosing the BEBANG Dog Training Collar. This device is designed to assist in training your dog effectively and humanely, offering various modes to suit different training needs. Please read this manual thoroughly before using the product to ensure proper operation and safety for both you and your pet.

Safety Information

• This training collar is intended for dogs only. Do not use on aggressive dogs or dogs under 6 months old.
• Avoid leaving the collar on the dog for more than 12 hours per day.
• Regularly check the contact points on the collar for signs of irritation or pressure sores on your dog's skin. If irritation occurs, discontinue use until the skin heals.
• The static shock mode should be used as a last resort and only after other modes (beep, vibration) have been attempted. Always start with the lowest effective level.
• Keep the device out of reach of children.
• Do not attempt to disassemble or modify the device. This will void the warranty and may cause damage or injury.

Package Contents

• Remote Transmitter
• Receiver Collar
• Adjustable Nylon Strap
• USB Charging Cable (2-in-1)
• Test Light
• Silicone Contact Points (short and long)
• User Manual

Product Overview

Image: The BEBANG dog training collar system, showing the remote transmitter and the receiver collar with its green and black strap.

Remote Transmitter

• LCD Display: Shows battery level, channel, and intensity level.
• Beep Button: Activates an audible tone.
• Vibration Button: Activates vibration mode.
• Shock Button: Activates static shock mode (use with caution).
• +/- Buttons: Adjust intensity levels for vibration and shock.
• CH Button: Selects training channel (for multiple collars).
• Light Button: Turns on/off the LED light on the receiver collar.
• Charging Port: For USB charging.

Receiver Collar

• Contact Points: Deliver static correction (can be replaced with silicone covers).
• LED Indicator Light: Shows power status, charging status, and indicates activation.
• Charging Port: For USB charging.
• Power Button: Turns the receiver on/off.
• IPX7 Waterproof: Designed to withstand immersion in water.

Setup

1. Charging the Devices

Before first use, fully charge both the remote transmitter and the receiver collar. Use the provided 2-in-1 USB charging cable.

• Connect the charging cable to the charging ports on both the remote and the receiver.
• Plug the USB end into a standard USB charger (not included).
• The indicator light on the receiver will be red during charging and turn green when fully charged. The remote's battery icon will show full.
• Charging typically takes about 3 hours for a full charge, providing up to 15 days of working time.

Image: Illustration of the 2-in-1 charging cable connected to both the remote transmitter and the receiver collar, highlighting the simultaneous charging capability.

2. Pairing the Remote and Receiver

1. Turn on the remote transmitter by pressing any button.
2. Turn on the receiver collar by pressing and holding the power button until the LED indicator flashes.
3. Within 10 seconds of turning on the receiver, press and hold the Beep and Vibration buttons on the remote simultaneously until the receiver's LED indicator stops flashing and stays solid. This indicates successful pairing.
4. If pairing fails, turn off both devices and repeat the steps.

3. Fitting the Collar

Proper fit is crucial for effective and safe operation.

• Ensure the contact points are making direct contact with your dog's skin. You may need to trim long fur around the contact area.
• The collar should be snug, but not too tight. You should be able to fit two fingers comfortably between the collar strap and your dog's neck.
• Periodically reposition the collar on your dog's neck to prevent pressure sores.
• Use the appropriate length of contact points (short for short-haired dogs, long for long-haired dogs).

Operating the Training Collar

Training Modes

The BEBANG training collar offers three distinct training modes:

Image: Visual representation of the three training modes: Beep, Vibration, and Shock (0-99 level), along with the remote and collar.

• Beep Mode: Delivers an audible tone. Ideal for recall training or as a warning before other corrections. Press the Beep button.
• Vibration Mode: Delivers a non-harmful vibration. Effective for getting your dog's attention or interrupting unwanted behaviors. Press the Vibration button. The intensity can be adjusted from 1-99 using the +/- buttons.
• Shock Mode: Delivers a static correction. Use with extreme caution and only when necessary. Always start at the lowest level and increase gradually if needed. Press the Shock button. The intensity can be adjusted from 1-99 using the +/- buttons.

Adjusting Intensity Levels

For Vibration and Shock modes, you can adjust the intensity from 1 to 99. Use the + and - buttons on the remote to select the desired level. Always start with the lowest level and observe your dog's reaction. The goal is to get their attention, not to cause pain.

LED Light Function

The receiver collar features a built-in LED light. Press the Light button on the remote to turn it on or off. This is useful for locating your dog in low-light conditions or at night.

Image: A golden retriever wearing the BEBANG collar with its LED light illuminated, useful for visibility in dark environments.

Control Range

The remote transmitter offers a control range of up to 2600 feet (approximately 800 yards) in open spaces. This allows for effective training both indoors and outdoors.

Image: A dog running in an open field, illustrating the 2600ft control range of the BEBANG training collar system.

Maintenance

Cleaning

• Wipe the receiver collar and remote with a damp cloth. Do not use harsh chemicals or abrasive cleaners.
• Regularly clean the contact points on the receiver to ensure proper function and prevent skin irritation.

Battery Care

• Charge the devices fully before long periods of inactivity.
• Store in a cool, dry place.
• Avoid extreme temperatures, which can affect battery life.

Waterproofing

The receiver collar is IPX7 waterproof, meaning it can withstand immersion in up to 1 meter of water for 30 minutes. This makes it suitable for use in rain, bathing, or swimming.

Image: A golden retriever standing in water, demonstrating the IPX7 waterproof capability of the receiver collar. A note emphasizes ensuring the charging port is sealed.

Important: Ensure the charging port on the receiver is securely sealed before exposing it to water.

Troubleshooting

Specifications

• Brand: BEBANG
• Model: Dog Training Collar
• Control Range: Up to 2600 feet (open space)
• Training Modes: Beep, Vibration (1-99 levels), Shock (1-99 levels)
• Waterproof Rating: IPX7 (Receiver Collar)
• Battery Type: Rechargeable Lithium-ion
• Charging Time: Approximately 3 hours
• Battery Life: Up to 15 days (depending on usage)
• Suitable for: Small, Medium, Large Dogs
• Material: Silicone, Metal (contact points), Nylon (strap)
• Item Weight: 3.52 ounces (approx. 0.1 Kilograms)
• Dimensions: 5.91 x 4.72 x 1.18 inches (product package dimensions are 6.57 x 5.91 x 2.17 inches)

Warranty and Support

BEBANG products are designed for durability and performance. For warranty information, technical support, or any questions regarding your product, please refer to the contact information provided with your purchase or visit the official BEBANG website. Please retain your proof of purchase for warranty claims.

Manufacturer: BEBANG

Date First Available: May 29, 2020
