Ibergrif M22119-1 Kitchen Faucet with Flexible Spout User Manual

1. Introduction

Thank you for choosing the Ibergrif M22119-1 Kitchen Faucet with Flexible Spout. This manual provides essential information for the safe installation, operation, and maintenance of your new faucet. Please read it thoroughly before installation and keep it for future reference.

This kitchen faucet features a durable stainless steel construction, a flexible spout for enhanced maneuverability, and a dual-function sprayer for versatile use. The brushed finish is designed to resist water spots and fingerprints, ensuring a clean appearance with minimal effort.

Figure 1.1: The Ibergrif M22119-1 Kitchen Faucet with its flexible red spout and brushed stainless steel body.

2. Safety Information

Please observe the following safety precautions during installation and use:

• Always turn off the main water supply before beginning any installation or maintenance.
• Wear appropriate personal protective equipment, such as safety glasses and gloves.
• Ensure all connections are secure to prevent leaks. Do not overtighten.
• If you are unsure about any part of the installation, consult a qualified plumber.
• Keep small parts out of reach of children.

3. Package Contents

Verify that all components are present before starting installation:

• 1 x Flexible Kitchen Faucet
• 1 x Installation Kit (mounting hardware, washers)
• 2 x Water Supply Hoses

Figure 3.1: All components included in the Ibergrif M22119-1 faucet package, including the faucet, hoses, and mounting hardware.

4. Specifications

Figure 4.1: Detailed dimensions of the Ibergrif M22119-1 Kitchen Faucet, showing height, reach, and base measurements.

5. Installation

This faucet is designed for single-hole deck mounting. Follow these steps for proper installation:

1. Prepare the Sink: Ensure the mounting hole on your sink or countertop is clean and free of debris. The faucet requires a standard single-hole opening.
2. Mount the Faucet: Insert the faucet body into the mounting hole. From underneath the sink, secure the faucet using the provided rubber washer, metal washer, and mounting nut. Tighten the nut firmly but do not overtighten.


Figure 5.1: Close-up view of the mounting mechanism, showing the threaded rod and securing nut for deck installation.

3. Connect Water Supply Hoses: Attach the hot and cold water supply hoses to the corresponding inlets on the faucet body. Ensure the connections are hand-tight, then use a wrench to tighten them an additional quarter turn.
4. Connect to Water Supply: Connect the other ends of the hot and cold water supply hoses to your home's hot and cold water lines. Use thread sealant tape on the threads for a watertight seal.
5. Test for Leaks: Slowly turn on the main water supply and check all connections for leaks. If any leaks are detected, tighten the connections slightly until the leak stops.
6. Flush the Faucet: Remove the aerator (see Maintenance section) and turn on the faucet to flush out any debris from the water lines. Run both hot and cold water for a few minutes. Reinstall the aerator.

6. Operation

The Ibergrif M22119-1 faucet is designed for ease of use:

• Water Flow and Temperature Control: The single lever handle controls both water flow and temperature. Lift the handle to increase flow, and move it left for hot water or right for cold water.


Figure 6.1: Close-up of the single lever handle, indicating hot (red) and cold (blue) water positions.

• Flexible Spout: The red flexible spout can be easily adjusted and positioned to direct water exactly where needed, offering maximum versatility for various kitchen tasks.


Figure 6.2: Demonstrations of the flexible spout's ability to bend and hold various positions for targeted water delivery.

• Dual-Function Sprayer: The sprayer head offers two distinct water patterns: a regular aerated stream for filling pots and a powerful shower spray for rinsing. Switch between modes by pressing the button on the sprayer head.


Figure 6.3: The faucet in use, demonstrating the spray function for rinsing dishes.

7. Maintenance

Regular maintenance will ensure the longevity and optimal performance of your faucet:

• Cleaning the Finish: The brushed nickel finish is designed to resist water spots and fingerprints. Clean with a soft, damp cloth and mild soap. Avoid abrasive cleaners, harsh chemicals, or scouring pads, as these can damage the finish.
• Aerator Cleaning: Over time, mineral deposits can accumulate in the aerator, reducing water flow. To clean, unscrew the aerator from the spout tip. Rinse it under running water and gently remove any debris or limescale with your finger or a soft brush. Reattach the aerator.


Figure 7.1: Close-up view of the water-saving aerator, showing its internal structure for easy cleaning.



Figure 7.2: A detailed view of the aerator at the end of the spout, ready for removal and cleaning.

8. Troubleshooting

Here are solutions to common issues you might encounter:

9. Warranty and Support

For warranty information or technical support, please contact Ibergrif customer service. Keep your purchase receipt as proof of purchase.

For further assistance, please visit the official Ibergrif website or contact their customer support directly.
