Introduction
This manual provides detailed instructions for the setup, operation, and maintenance of your Geeni Smart Home Pet and Baby Monitor. This 1080p wireless Wi-Fi camera is designed to help you monitor your home, pets, or children with ease, offering features such as two-way audio, motion detection, and night vision. Please read this manual thoroughly before using the device to ensure proper functionality and safety.
The Geeni Smart Home Pet and Baby Monitor shown alongside a smartphone displaying its live feed of a baby.
Product Overview
Key Features
- 1080p HD Video: Provides clear, high-definition live streaming and recording.
- Night Vision: Automatic infrared night vision for monitoring in low-light conditions.
- Two-Way Audio: Communicate with your pet or baby directly through the camera.
- Motion and Sound Alerts: Receive instant notifications on your smartphone for detected activity.
- Crying Alert: Specifically designed to detect and notify you of a baby's crying.
- Temperature Alert: Monitors the room temperature and sends alerts if it goes outside a set range.
- Pan and Tilt Functionality: Remotely adjust the camera's viewing angle (355° horizontal, 100° vertical) via the app.
- Voice Assistant Compatibility: Works with Amazon Alexa and Google Assistant for convenient control.
- Local and Cloud Storage: Options for storing video footage.
An overview of the Geeni camera's smart features, such as HD live video, lullabies, motion alerts, two-way audio, crying alerts, and temperature alerts.
A visual representation of the Geeni camera's comprehensive features, including 360-degree view, app control, lullabies, various alerts, and night vision.
Package Contents
- Geeni Smart Home Pet and Baby Monitor
- Power Adapter
- User Manual
Setup Guide
Follow these steps to set up your Geeni Smart Home Pet and Baby Monitor.
Step 1: Download the Geeni App
Download the Geeni app from the App Store (for iOS devices) or Google Play Store (for Android devices). Register for a new account or log in if you already have one.
Step 2: Power On the Camera
Plug the power adapter into the camera and then into a power outlet. The camera will power on, and an indicator light will begin to flash, indicating it is ready for pairing.
Step 3: Connect to Wi-Fi
- Open the Geeni app and tap the '+' icon to add a new device.
- Select 'Camera' from the device list.
- Follow the on-screen instructions to connect the camera to your 2.4 GHz Wi-Fi network. Ensure your phone is connected to the same 2.4 GHz network during setup.
- The app will guide you through scanning a QR code with the camera or using an alternative pairing method.
- Once connected, the indicator light will turn solid, and you can name your camera and begin monitoring.
Visual guide for setting up the Geeni camera, including app download, power connection, Wi-Fi pairing, and smart home integration.
A simplified three-step setup process for the Geeni camera: download the app, plug in the device, and connect to your network.
Operating Instructions
Live View and Pan/Tilt Control
Once connected, open the Geeni app and select your camera to view the live feed. Use the on-screen controls to pan (rotate horizontally up to 355°) and tilt (rotate vertically up to 100°) the camera to adjust your viewing angle.
The Geeni camera's pan and tilt functionality is controlled directly through the mobile application, allowing for a wide range of view adjustments.
Two-Way Audio
Tap the microphone icon in the live view interface to speak through the camera. This allows you to comfort your baby or communicate with a pet remotely. Tap the speaker icon to listen to audio from the camera's environment.
The two-way audio feature enables users to speak and listen through the camera, facilitating remote interaction.
Alerts and Notifications
Configure motion, sound, crying, and temperature alerts within the Geeni app settings. You will receive push notifications on your smartphone when these events are detected, allowing you to respond promptly.
Voice Assistant Integration
Connect your Geeni camera to Amazon Alexa or Google Assistant through the respective apps. Once linked, you can use voice commands such as "Show me Baby's Crib" or "What's the temperature in Baby's Crib" on compatible devices.
Users can check in on their monitored space using voice commands with integrated smart assistants, viewing the feed on compatible devices.
Recording and Storage
The camera supports local storage via a microSD card (not included) for continuous recording or event-triggered clips. Cloud storage options may also be available through the Geeni app for secure off-site storage of your footage.
The Geeni camera offers multiple ways to monitor, including cloud storage, multi-camera view on a mobile device, and web browser access.
Maintenance
Cleaning the Camera
To clean the camera, gently wipe the exterior with a soft, dry cloth. Do not use harsh chemicals, cleaning solvents, or abrasive cleaners, as these can damage the device. Ensure the camera is unplugged before cleaning.
Software Updates
Periodically check the Geeni app for available firmware updates. Keeping your camera's software up-to-date ensures optimal performance, security, and access to new features.
Troubleshooting
Camera Not Connecting to Wi-Fi
- Ensure your Wi-Fi network is 2.4 GHz. The camera does not support 5 GHz networks.
- Verify your Wi-Fi password is correct.
- Place the camera closer to your Wi-Fi router during setup.
- Restart your router and the camera, then attempt the pairing process again.
- If your router broadcasts both 2.4 GHz and 5 GHz networks with the same name, consider temporarily disabling the 5 GHz band or separating them with different SSIDs during setup.
Camera Offline in App
- Check if the camera's power adapter is securely plugged in and the camera is powered on.
- Verify your home Wi-Fi network is active and functioning correctly.
- Restart the camera by unplugging it for 10 seconds and plugging it back in.
- If the issue persists, you may need to re-pair the camera with the Geeni app.
No Audio or Poor Audio Quality
- Ensure the microphone and speaker permissions are enabled for the Geeni app on your smartphone.
- Check the volume settings within the app and on your smartphone.
- Minimize background noise near the camera for clearer audio.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | GN-CW023-199 |
| Video Resolution | 1080p (Effective: 1080 Pixels) |
| Viewing Angle | 355 Degrees (Horizontal), 100 Degrees (Vertical) |
| Wireless Technology | Wi-Fi (2.4 GHz only) |
| Power Source | Corded Electric (Wattage: 24 watts) |
| Special Features | Night Vision, Motion Alert, Sound Alert, Crying Alert, Temperature Alert, Two-Way Audio |
| Compatible Devices | Smartphone, Tablet (via Geeni App), Amazon Alexa, Google Assistant |
| Dimensions (L x W x H) | 6.86 x 6.86 x 10.92 cm |
| Item Weight | 472 g |
| Material | Plastic |
Warranty Information and Customer Support
For detailed warranty information, product registration, and the most up-to-date customer support resources, please visit the official Geeni website. You can typically find FAQs, troubleshooting guides, and contact information for technical assistance there.
Geeni Official Website: www.mygeeni.com
