1. Introduction
Thank you for choosing the ZENCAR EV Charger EVSE. This portable charging solution is designed to provide efficient and safe charging for your electric vehicle. It features a Schuko plug for connection to a standard 230V outlet and a Type 2 connector for your vehicle, offering adjustable current settings from 6A to 16A. The integrated LCD display provides real-time charging information, and a timer function allows for scheduled charging.
Image: The ZENCAR EV Charger EVSE, showcasing its main components: the control box with LCD display, the Schuko plug for power input, and the Type 2 connector for vehicle charging. The cable length for this model is 5 meters.
2. Safety Information
Please read all safety instructions carefully before using the charger. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Ensure the power outlet is properly grounded and rated for the charger's specifications (230V, up to 16A).
- Do not use the charger if the cable or connectors are damaged.
- Keep the charger away from flammable materials and extreme temperatures.
- Do not immerse the control box or connectors in water. While the cable is shockproof and waterproof (IP65 rated), the plug and control box should be protected from direct water exposure during charging.
- Always disconnect the charger from the power source before cleaning or maintenance.
- The charger features 12 protection mechanisms, including over-temperature protection. If high temperatures are detected, the current will be automatically reduced or temporarily cut off to prevent damage.
Image: Visual representation of ZENCAR's safety features, including protection against overvoltage, lightning, and a smart core that automatically adjusts or stops charging based on conditions.
3. Setup
Follow these steps for initial setup of your ZENCAR EV Charger:
- Unpack the Charger: Carefully remove all components from the packaging. Inspect the charger for any visible damage.
- Connect to Power: Insert the Schuko plug firmly into a standard 230V AC grounded wall outlet. The LCD display on the control box should illuminate.
- Prepare Vehicle: Ensure your electric vehicle is ready for charging. Open the charging port cover on your vehicle.
- Connect to Vehicle: Insert the Type 2 connector into your vehicle's charging port. Ensure it clicks securely into place.
Image: A visual guide illustrating the four simple steps for using the ZENCAR EV charger: 1. Connect power cable, 2. Double-click for ampere setting, 3. Plug in & charge vehicle, 4. Swipe card for timer start (if applicable).
Image: A person connecting the ZENCAR EV charger's Type 2 connector to an electric vehicle's charging port, demonstrating the ease of connection. The image also shows the included cable storage bag.
4. Operating Instructions
The ZENCAR EV Charger offers an intuitive LCD display and adjustable settings for optimal charging.
4.1 LCD Display and Information
The informative LCD screen allows you to monitor the entire charging process in real-time. It displays:
- Charging Time
- Controller Temperature
- Charging Current (Amperage)
- Voltage
- Energy Charged (kWh)
Image: A detailed view of the ZENCAR EV charger's control box, highlighting the high-end LCD screen and indicating the display of charging data, the timer function, and the selection of amperage levels (6A, 8A, 10A, 12A, 16A).
4.2 Adjusting Charging Current
You can flexibly adjust the charging current of the Type 2 charging cable according to your needs. Choose the current intensity between 6A, 8A, 10A, 12A, and 16A. This can be done automatically or manually via the control box.
Image: A woman sitting in an electric car, with an overlay indicating the ZENCAR charger's flexible current selection from 6A to 16A, emphasizing user control over the charging speed.
4.3 Timer Function
Plan your charging efficiently using the integrated timer function. Refer to the on-screen menu for setting specific charging start or end times.
4.4 Charging Process
Once connected to both the power outlet and the vehicle, the charger will initiate the charging process. The LCD display will show the current status. Charging will stop automatically when the vehicle battery is full or if a safety issue is detected.
Image: An electric car being charged outdoors, demonstrating the ZENCAR charger's suitability for outdoor application due to its shockproof and waterproof design, allowing charging anywhere, anytime.
5. Maintenance
Proper maintenance ensures the longevity and safe operation of your ZENCAR EV Charger.
- Cleaning: Disconnect the charger from power before cleaning. Use a soft, dry cloth to wipe the control box and cables. Do not use abrasive cleaners or solvents.
- Storage: When not in use, store the charger in a dry, cool place, away from direct sunlight and extreme temperatures. Use the provided cable protection bag to keep the cable tidy and protected.
- Inspection: Regularly inspect the cable, plugs, and control box for any signs of wear, damage, or corrosion. If any damage is found, discontinue use and contact customer support.
6. Troubleshooting
If you encounter issues with your ZENCAR EV Charger, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Charger not powering on | No power from outlet; damaged cable/plug | Check outlet with another device; inspect cable/plug for damage. |
| Vehicle not charging | Connector not fully inserted; vehicle charging port issue; charger error | Ensure Type 2 connector is fully seated; check vehicle manual; restart charger by unplugging and re-plugging. |
| Charging stops unexpectedly | Over-temperature protection activated; power fluctuation; vehicle battery full | Allow charger to cool down; check power supply stability; verify vehicle battery status. |
| LCD display error | Internal fault | Unplug and re-plug the charger. If the error persists, contact customer support. |
If the problem persists after attempting these solutions, please contact ZENCAR customer support.
7. Specifications
| Feature | Specification |
|---|---|
| Brand | ZENCAR |
| Model Number | ZEN-T2-P-16A-5m |
| Color | Black |
| Product Type | Portable |
| Input Voltage | 230 Volts |
| Output Voltage | 230 Volts |
| Current Rating | 16 A (Adjustable: 6A, 8A, 10A, 12A, 16A) |
| Power | 3.6 KW |
| Cable Length | 5 meters |
| Connector Type | Type 2 (Vehicle side), Schuko (Wall side) |
| Compatible Devices | Electric vehicles with Type 2 connector |
| Special Features | Fast Charging, LCD Display, Timer Function, Shockproof, Waterproof |
| Item Weight | 3 Kilograms |
| Product Dimensions | 40.2P x 38.4W x 9H centimeters |
| Country of Origin | China |
8. Warranty and Support
ZENCAR provides a 2-year limited warranty for this product, assured by a European company. This warranty covers manufacturing defects and quality issues.
For technical assistance, warranty claims, or any other inquiries, please do not hesitate to contact our customer support team. We are committed to providing the best possible support.
Contact Information:
Please refer to your purchase documentation or the ZENCAR official website for the most up-to-date contact details.
