Horevo 24W/36W Smart LED Ceiling Light with Bluetooth Speaker User Manual

1. Introduction

Thank you for purchasing the Horevo 24W/36W Smart LED Ceiling Light with Bluetooth Speaker. This innovative lighting solution combines energy-efficient LED illumination with a high-quality Bluetooth speaker, offering a versatile and immersive experience for your living space. It features adjustable brightness, color temperature, RGB mood lighting, and convenient control via a remote or a dedicated mobile application. Please read this manual thoroughly before installation and use to ensure proper operation and safety.

Image 1: Horevo Smart LED Ceiling Light with integrated Bluetooth speaker.

2. Safety Instructions

Always follow basic safety precautions when installing and operating electrical appliances to reduce the risk of fire, electric shock, and personal injury.

• Professional Installation Recommended: Installation should be performed by a qualified electrician to ensure compliance with local electrical codes.
• Power Disconnection: Always disconnect power at the circuit breaker before installation, maintenance, or cleaning.
• Voltage Compatibility: Ensure the supply voltage (100-240V/50-60Hz) is compatible with the light fixture.
• Avoid Water: Do not install in damp locations or expose to water.
• Proper Mounting: Ensure the mounting surface can support the weight of the fixture.
• No High Temperature Exposure: The lampshade material is durable but can be damaged if exposed to high temperatures in a closed environment.

3. Package Contents

Verify that all components are present and undamaged upon unboxing:

• 1 x Horevo Ceiling Lamp
• 1 x Remote Control
• 1 x Set of Screws for Installation
• 1 x User Manual (This document)

4. Product Features

• High-Quality Bluetooth Speaker: Integrated speaker for playing music, with a rhythm pattern mode that synchronizes light effects with music beats for a romantic ambiance.
• Dual Control Options: Control the light functions via the included remote control or a dedicated mobile application.
• Dimmable Lighting: Adjust light brightness from 10% to 100% to suit your needs.
• Adjustable Color Temperature: Seamlessly switch between warm white (2800K), neutral white (4500K), and cool white (6000K) light.
• RGB Mood Lighting: Offers multiple RGB color options to create various atmospheres.
• Timer Function: Program the light to automatically turn on or off according to your set schedule.
• Night Light Mode: Provides a soft, low-brightness warm light for nighttime comfort.

Image 2: Illustration of dimmable color temperature (3000K-6500K) and brightness (10-100%).

Image 3: Example of RGB mood lighting for multiple atmospheres.

Image 4: Depiction of different light modes including daylight, night light, and RGB light.

Image 5: Visual representation of the light's versatility, offering different lighting moods for various needs.

5. Setup and Installation

This ceiling light is designed for ceiling mount installation. Please follow these general steps:

1. Prepare for Installation:
   • Turn off the main power supply at the circuit breaker to avoid electric shock.
   • Ensure the ceiling surface is clean, dry, and capable of supporting the fixture's weight (approx. 3 lbs / 1.36 kg).
2. Mount the Bracket:
   • Attach the mounting bracket (usually included with the light) to the ceiling junction box using the provided screws.
3. Connect Wiring:
   • Carefully connect the light fixture's wires to your household electrical wires (Live to Live, Neutral to Neutral, Ground to Ground) using wire nuts. Ensure all connections are secure.
4. Attach the Fixture:
   • Align the light fixture with the mounting bracket and secure it in place using the provided screws or twist-lock mechanism.
5. Restore Power:
   • Once the light is securely installed, turn the main power supply back on at the circuit breaker.

Image 8: Product dimensions (50cm/19.7inch diameter, 5.8cm/2.3inch height) and illustration of using a wall switch to change light modes by toggling ON/OFF within 5 seconds.

6. Operating Instructions

6.1 Remote Control Operation

The included remote control allows for convenient adjustment of various light functions.

Image 6: Horevo Ceiling Light with its remote control, symbolizing music playback capability.

• Power ON/OFF: Press the ON/OFF button.
• Brightness Adjustment: Use the Brightness +/- buttons to increase or decrease light intensity.
• Color Temperature Adjustment: Use the CCT +/- buttons to cycle through warm, neutral, and cool white light.
• RGB Color Selection: Press the RGB button to activate RGB mode, then use directional buttons or dedicated color buttons (if available) to select colors.
• Music Mode: Press the Music Note button to activate the music rhythm mode.
• Timer Function: Press the Timer button to set an automatic turn-off time. Refer to the remote's specific markings for duration options.
• Night Light Mode: Press the Moon icon button to activate the minimum brightness warm light.

Image 7: The light operating in Night Light mode, providing minimal brightness warm light.

6.2 Bluetooth Pairing

To play music through the integrated speaker, pair your device via Bluetooth:

1. Ensure the ceiling light is powered on.
2. On your smartphone or Bluetooth-enabled device, go to Bluetooth settings.
3. Search for available devices. The light will typically appear as "Horevo Light" or a similar name.
4. Select the light to pair. Once connected, you can play audio from your device through the light's speaker.
5. The Bluetooth distance is approximately 10 meters (33 feet).

6.3 App Control

For advanced control and features, download the dedicated mobile application (details usually found in a QR code on the packaging or a separate leaflet). The app allows for more precise control over colors, brightness, and potentially custom scenes.

7. Maintenance

To ensure the longevity and optimal performance of your Horevo ceiling light, follow these maintenance guidelines:

• Cleaning: Disconnect power before cleaning. Use a soft, dry cloth to wipe the surface of the light. Do not use abrasive cleaners, solvents, or harsh chemicals, as they may damage the finish or electronic components.
• Bulb Replacement: This fixture uses integrated LED lights, which are not user-replaceable. If the LEDs fail, the entire fixture may need replacement.
• Regular Checks: Periodically check for any loose connections or signs of damage. If any issues are found, consult a qualified electrician.

8. Troubleshooting

If you encounter issues with your Horevo ceiling light, refer to the following common problems and solutions:

9. Specifications

10. Warranty and Support

Specific warranty information for this product is not detailed in the provided data. Please refer to the product packaging or contact Horevo customer support directly for warranty terms and conditions. For technical assistance or further inquiries, please reach out to the retailer or manufacturer's support channels.

Manufacturer: Horevo
