Strymon MultiSwitch Plus Footswitch Instruction Manual

1. Product Overview

The Strymon MultiSwitch Plus is an external footswitch designed to expand the control capabilities of compatible Strymon guitar effects pedals. It provides enhanced functionality, allowing users to access presets, control looper functions, tap tempos, and more, depending on the connected pedal and selected mode. This device connects to your Strymon pedal using a standard 1/4" TRS cable and does not require an external power supply.

Image 1.1: The Strymon MultiSwitch Plus footswitch, a black rectangular unit with three silver footswitches labeled A, B, and C, and the Strymon logo.

Key Features:

• Enhanced Control: Provides instant access to three presets for pedals like Compadre, Iridium, Riverside, or Sunset. Unlocks full potential for Nightsky or Volante.
• Multiple Control Modes: Offers versatile configurations for recalling presets, changing banks, operating TimeLine's looper, and remotely tapping tempos.
• Multi-Pedal Control: Features three outputs, allowing connection to up to three compatible Strymon pedals using additional TRS cables (sold separately).
• Simple Setup: Connects via an included 1/4" TRS cable and requires no additional power supply.
• Durable Construction: Features a metal body and aluminum top material for robust performance.

2. Setup and Connection

Setting up your MultiSwitch Plus is a straightforward process. Ensure your Strymon pedal is powered off before making connections.

1. Identify the TRS Jack: Locate the EXP/TRS jack on your compatible Strymon pedal.
2. Connect the Cable: Use the included 1/4" TRS right-angle cable to connect the MultiSwitch Plus to the EXP/TRS jack of your Strymon pedal.
3. Multiple Pedals (Optional): If controlling multiple pedals, connect additional compatible Strymon pedals to the other TRS outputs on the MultiSwitch Plus using separate TRS cables (sold separately).
4. Power On: Once connections are secure, power on your Strymon pedal. The MultiSwitch Plus draws power directly from the connected pedal and does not require an external power supply.

Image 2.1: A visual representation highlighting the included 1/4" right-angle TRS cable, the absence of an external power supply requirement, and the compact size of the MultiSwitch Plus.

Image 2.2: Diagram showing the MultiSwitch Plus connected to three different Strymon pedals (Sunset, Riverside, Volante) for instant preset access across multiple units.

3. Operating Instructions

The MultiSwitch Plus offers various operational modes depending on the Strymon pedal it is connected to. Refer to your specific Strymon pedal's manual for detailed instructions on configuring its external control settings.

General Operation:

• The three footswitches (A, B, C) on the MultiSwitch Plus will correspond to different functions based on the mode selected on the connected Strymon pedal.
• Common functions include:
  • Preset Recall (e.g., for Compadre, Iridium, Riverside, Sunset)
  • Bank Up/Down
  • Looper Control (e.g., TimeLine's looper functions like Reverse, Half Speed, Undo/Redo)
  • Tap Tempo
  • Expression Pedal functions (e.g., SPEED switch for Volante)
  • Favorite Switch
  • Boost/Gain Toggle

Image 3.1: The MultiSwitch Plus with text indicating its capability for multiple control modes, including recalling presets, changing banks, and operating TimeLine's looper.

Specific Pedal Functionality Examples:

• Compadre, Iridium, Riverside, Sunset: Gain instant access to three presets (1, 2, and 3).
• Nightsky, Volante: Unlock advanced features such as remote operation of the SPEED switch, transport control, or additional foot control in Sound on Sound mode for Volante.
• TimeLine: Full control over the looper, including Reverse, Half Speed, and Undo/Redo. Also provides an alternate way to explore presets and set tempos.
• BigSky, Mobius: Provides an alternate way to explore presets and set tempos.

Image 3.2: A graphic illustrating how the MultiSwitch Plus extends functionality for various Strymon pedals, including Volante (remote SPEED switch), TimeLine (looper control), and BigSky/Mobius (remote preset/tempo control).

Image 3.3: An example setup showing the MultiSwitch Plus connected to Strymon Lex, Flint, and DIG pedals, demonstrating its use for external tap, favorite, boost, and other independently assigned footswitch functions.

4. Maintenance

The Strymon MultiSwitch Plus is designed for durability and requires minimal maintenance.

• Cleaning: Use a soft, dry cloth to clean the exterior of the unit. Avoid using abrasive cleaners or solvents, as these may damage the finish.
• Storage: Store the unit in a dry environment, away from extreme temperatures and humidity, when not in use.
• Cable Care: Ensure the TRS cable is not kinked or strained, as this can lead to damage and intermittent connectivity.

5. Troubleshooting

If you encounter issues with your MultiSwitch Plus, consider the following troubleshooting steps:

• No Response:
  • Ensure the 1/4" TRS cable is securely connected to both the MultiSwitch Plus and the compatible Strymon pedal.
  • Verify that the connected Strymon pedal is powered on and functioning correctly.
  • Check the settings on your Strymon pedal to ensure it is configured to accept external control input from a MultiSwitch. Refer to your pedal's specific manual.
• Incorrect Functionality:
  • Confirm that the mode selected on your Strymon pedal matches the intended function for the MultiSwitch Plus.
  • If using multiple pedals, ensure each pedal is correctly configured for its respective MultiSwitch input.
• Intermittent Connection:
  • Try using a different 1/4" TRS cable to rule out a faulty cable.
  • Inspect the TRS jacks on both the MultiSwitch Plus and the Strymon pedal for any debris or damage.

For further assistance, please contact Strymon customer support.

6. Specifications

7. Warranty and Support

Strymon products are known for their quality and reliability. For specific warranty information, please refer to the official Strymon website or the documentation included with your purchase. Extended protection plans may also be available from authorized retailers.

For technical support, product inquiries, or service, please visit the official Strymon support page or contact their customer service department directly.

Online Resources: Strymon Support Website
