1. Introduction
Welcome to the user manual for your Wings Touch True Wireless Bluetooth Earbuds. This guide provides essential information on setting up, operating, maintaining, and troubleshooting your earbuds to ensure optimal performance and longevity. Please read this manual carefully before using the product.
2. What's in the Box
Upon opening your Wings Touch earbuds package, you should find the following items:
- 2 x Earbuds (Left and Right)
- 1 x Charging Case
- 1 x USB Charging Cable
- 3 x Pairs of Ear-tips (various sizes for a custom fit)
- 1 x User Manual
3. Product Overview
The Wings Touch earbuds feature a sleek, minimalist design with touch sensor controls for easy interaction. They are equipped with 6mm micro Neodymium speaker drivers for enhanced audio quality.
Video Overview
This video provides a visual overview of the Wings Touch earbuds, demonstrating their sleek design, touch controls, battery life, HD bass, voice assistant compatibility, stereo calling, and water resistance.
4. Setup and Pairing
The Wings Touch earbuds are designed for easy and automatic pairing.
Automatic Pairing
- Remove both earbuds from the charging case.
- The earbuds will automatically power on and connect with each other.
- On your device (smartphone, tablet, etc.), enable Bluetooth.
- Search for "Wings Touch" in the list of available Bluetooth devices and select it to pair.
- Once paired, the earbuds are ready for use.
The earbuds are compatible with all Bluetooth-enabled devices, including iOS and Android operating systems.
5. Operating Instructions
The Wings Touch earbuds feature intuitive touch sensor controls on both the left and right earbuds.
Touch Controls
- Single Touch (Left or Right Earbud): Play/Pause music, Answer/Reject calls.
- Double Touch (Right Earbud): Volume Up.
- Double Touch (Left Earbud): Volume Down.
- Long Press (Right Earbud): Next Song.
- Long Press (Left Earbud): Previous Song.
- Triple Touch (Left or Right Earbud): Activate Siri / Google Assistant.
Calling
The earbuds support stereo calling with a built-in microphone, allowing you to take calls from both earbuds.
Voice Assistant
Access your device's voice assistant (Google Assistant or Siri) with a simple triple touch on either earbud.
6. Battery and Charging
The Wings Touch earbuds offer extended playtime and convenient charging.
- Each earbud provides up to 6 hours of playtime on a single charge.
- The charging case provides up to 5 full charges for the earbuds, offering a total of approximately 30 hours of playtime.
Charging the Earbuds
Place the earbuds into the charging case. They will automatically begin charging. The indicator lights on the case will show the charging status.
Charging the Case
Connect the provided USB charging cable to the charging port on the case and to a power source. The indicator lights will show the charging status of the case.
7. Maintenance
To ensure the longevity and optimal performance of your Wings Touch earbuds, follow these maintenance guidelines:
- Cleaning: Regularly clean the earbuds and charging case with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials.
- Water Resistance: The earbuds are water-resistant. However, they are not waterproof. Avoid submerging them in water or exposing them to heavy rain for extended periods. Dry them thoroughly if they get wet.
- Storage: When not in use, store the earbuds in their charging case to protect them from dust and damage.
- Temperature: Avoid exposing the earbuds to extreme temperatures (hot or cold) as this can affect battery life and overall performance.
8. Troubleshooting
If you encounter any issues with your Wings Touch earbuds, refer to the following common solutions:
- Earbuds not pairing with each other: Place both earbuds back into the charging case, close the lid, wait a few seconds, then open the lid and remove them again. This should reset the connection.
- Earbuds not connecting to device: Ensure Bluetooth is enabled on your device and the earbuds are in pairing mode. Forget the device from your phone's Bluetooth settings and try pairing again.
- No sound from one earbud: Check if both earbuds are charged. Try resetting the earbuds by placing them in the case and then taking them out.
- Charging issues: Ensure the charging cable is securely connected to both the case and the power source. Check for any debris in the charging ports.
- Low volume or poor sound quality: Ensure the ear-tips are properly seated in your ears for a good seal. Clean any earwax or debris from the earbud speakers.
If the issue persists, please contact customer support for further assistance.
9. Specifications
Below are the technical specifications for the Wings Touch True Wireless Earbuds:
| Feature | Detail |
|---|---|
| Brand | Wings |
| Model Number | WL-TOUCH-BLK |
| Model Name | Touch |
| Color | Black |
| Ear Placement | In Ear |
| Form Factor | In Ear |
| Noise Control | Active Noise Cancellation |
| Audio Driver Type | Dynamic Driver |
| Enclosure Material | Titanium |
| Wireless Technology Type | Bluetooth |
| Network Connectivity Technology | Bluetooth |
| Control Method | Touch |
| Control Type | Volume Control |
| Battery Average Life | 6 Hours (per earbud) |
| Water Resistance Level | Water Resistant |
| Item Weight | 170 Grams |
| Compatible Devices | Smartphones, Tablets |
10. Warranty and Support
Your Wings Touch earbuds come with a manufacturer's warranty and dedicated support.
Warranty Information
A 1-year warranty is provided by the manufacturer from the date of purchase. Mandatory registration is required on www.wingslifestyle.in/registerproduct within 7 days for warranty eligibility.
Customer Support
For any queries, support, or warranty claims, you can reach out to:
- Call Us At: +91 9130256537 (Monday to Saturday, 10:00 AM to 6:00 PM)
- Mail Us At: support@brandscaleindia.com
- Log On To: www.wingslifestyle.in/claimwarrenty
