APS iBoard Third Generation 6-inch Black Aluminum Running Boards

1. Introduction

This manual provides detailed instructions for the proper installation, operation, and maintenance of your APS iBoard Third Generation 6-inch Black Aluminum Running Boards, Model IBNZ3730. These running boards are designed to provide a convenient and secure step for accessing your vehicle.

Compatibility: This product is compatible with 2014-2020 Nissan Rogue models (excluding 2014 Select & Sport models).

Please read all instructions thoroughly before beginning installation to ensure a safe and correct setup.

2. Safety Information

Always prioritize safety during installation and use. Failure to follow safety guidelines may result in injury or damage to the product or vehicle.

• Wear appropriate personal protective equipment, including safety glasses and gloves, during installation.
• Ensure the vehicle is parked on a level surface and the parking brake is engaged before starting work.
• If lifting the vehicle, use appropriate jack stands to secure it. Never work under a vehicle supported only by a jack.
• Confirm all fasteners are securely tightened to the specified torque (if applicable) to prevent loosening during vehicle operation.
• Do not exceed the maximum weight limit of 300 pounds per running board.
• Keep children and pets away from the work area.

3. What's in the Box

Carefully unpack all components and verify that all items listed below are present and undamaged. If any parts are missing or damaged, contact customer support immediately.

• Set of Running Boards (2 pieces)
• Mounting Brackets (Vehicle-specific)
• Hardware Kit (Bolts, washers, nuts, etc.)
• Instruction Manual (This document)

Figure 3.1: Exploded view showing the running boards, mounting brackets, and associated hardware components included in the package.

4. Tools Required

The following tools are typically required for installation. Specific sizes may vary based on your vehicle and the provided hardware.

• Socket Wrench Set
• Open-End Wrench Set
• Measuring Tape
• Marker or Pen
• Drill and Drill Bits (Specific sizes as needed for rocker panel mounting)
• Center Punch
• Safety Glasses
• Gloves

5. Installation Instructions

The APS iBoard running boards utilize a rocker panel mount system, which requires drilling into the vehicle's rocker panel. Follow these steps carefully.

1. Prepare the Vehicle: Park the vehicle on a flat, level surface. Engage the parking brake. For easier access, you may lift the vehicle using a jack and secure it with jack stands.
2. Identify Mounting Locations: Locate the pre-drilled holes or designated mounting points on the vehicle's rocker panel. These are typically found along the underside of the vehicle, beneath the doors. Refer to your vehicle's specific service manual if unsure.
3. Position Brackets: Hold the mounting brackets up to the identified locations. Ensure they align correctly with the rocker panel and the running board attachment points. Mark the drilling locations precisely using a marker or center punch.
4. Drill Holes: Using the appropriate drill bit size (refer to hardware instructions for exact size), carefully drill pilot holes at the marked locations. Gradually increase drill bit size if necessary. Apply rust-preventative paint to all drilled holes to prevent corrosion.
5. Attach Brackets: Secure the mounting brackets to the vehicle's rocker panel using the provided hardware. Hand-tighten all bolts initially to allow for adjustment.
6. Mount Running Boards: Carefully position one running board onto the installed brackets. Align the slots on the running board with the attachment points on the brackets.
7. Secure Running Boards: Attach the running board to the brackets using the remaining hardware. Again, hand-tighten all fasteners.
8. Adjust and Tighten: Adjust the running board's position to ensure it is level and properly spaced from the vehicle body. Once satisfied with the alignment, fully tighten all bolts on both the brackets and the running boards. Refer to the hardware specifications for recommended torque values.
9. Repeat for Other Side: Follow the same steps for installing the running board on the opposite side of the vehicle.
10. Final Inspection: Double-check all fasteners for tightness. Ensure the running boards are secure and do not wobble.

Figure 5.1: Side view of the APS iBoard running board installed on a Nissan Rogue, demonstrating proper fitment.

Figure 5.2: Front-side view of the APS iBoard running board installed on a white Nissan Rogue, showing the integrated appearance.

6. Operating Your Running Boards

The APS iBoard running boards are designed for straightforward use. Simply step onto the board when entering or exiting your vehicle. The 6-inch wide surface provides a comfortable and secure stepping area.

• Always step onto the center of the running board for optimal stability.
• Avoid placing excessive weight on the edges of the board.
• Be mindful of wet or icy conditions, as the non-slip step pad, while effective, may have reduced grip in extreme weather.

7. Maintenance

Regular maintenance will ensure the longevity and continued performance of your running boards.

• Cleaning: Clean the running boards regularly with mild soap and water. Avoid abrasive cleaners or harsh chemicals that could damage the matte black powder coating or the non-slip step pad. Rinse thoroughly and dry.
• Inspection: Periodically inspect all mounting hardware (bolts, nuts, brackets) for tightness. Re-tighten any loose fasteners to prevent rattling or instability.
• Damage Check: Check the running boards for any signs of damage, such as bends, cracks, or excessive wear on the step pad. Replace damaged components if necessary.

Figure 7.1: The running boards feature a triple-layer rust protection system, including stainless steel, pre-treatment, anti-corrosion primer, and a black powder-coated finish for enhanced durability.

8. Troubleshooting

If you encounter issues with your running boards, refer to the following common problems and solutions.

• Running Board is Loose/Wobbly:
  Solution: Inspect all mounting bolts and nuts. Re-tighten any loose fasteners. Ensure brackets are securely attached to the vehicle's rocker panel.
• Unusual Noise (Rattling/Squeaking):
  Solution: Check all contact points between the running board, brackets, and vehicle. Ensure no components are rubbing. Re-tighten all hardware. Apply a small amount of silicone grease to contact points if squeaking persists.
• Difficulty Stepping On/Off:
  Solution: Verify the running board is installed at the correct height and distance from the vehicle. While adjustments are limited by the mounting points, ensure no obstructions are present.
• Corrosion/Rust Spots:
  Solution: Although made from aluminum with a powder coating, minor surface imperfections can occur. Clean affected areas thoroughly and apply a touch-up paint designed for powder-coated aluminum if necessary.

9. Specifications

Figure 9.1: Detailed dimensions of the iBoard, highlighting its 6-inch width and low profile.

Figure 9.2: Illustration of the solid aluminum build of the running boards, emphasizing the absence of plastic caps for enhanced durability.

10. Warranty Information

APS provides a 5-year spare part availability duration for this product within the EU. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact APS customer support.

11. Customer Support

If you have any questions, require assistance with installation, or need to report a missing/damaged part, please contact APS customer support. You can find more information and contact details by visiting the official APS store:
