Morpilot 4-in-1 Electric Milk Frother User Manual

Introduction

Thank you for choosing the Morpilot 4-in-1 Electric Milk Frother. This appliance is designed to create various milk textures, including cold foam, light hot foam, thick hot foam, and heated milk without frothing, enhancing your coffee and beverage experience. Please read this manual carefully before use to ensure safe and optimal operation.

Important Safety Instructions

• Read all instructions before using the appliance.
• Do not immerse the base unit or power cord in water or other liquids.
• Ensure the voltage rating on the appliance matches your local power supply.
• Keep the appliance out of reach of children.
• Always unplug the frother from the power outlet when not in use and before cleaning.
• Do not operate the appliance with a damaged cord or plug, or if it malfunctions or has been damaged in any manner.
• Use only attachments recommended by the manufacturer.
• Avoid contact with moving parts.
• Do not use outdoors.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Do not use the appliance for anything other than its intended use.
• Exercise extreme caution when disposing of hot steam.
• The appliance features an automatic temperature control system (Strix) that stops operation when the milk reaches approximately 65 ± 5 °C to prevent overheating.

Package Contents

Please check the box for the following items:

• 1 x Morpilot Electric Milk Frother
• 2 x Whisks (one for frothing, one for heating)
• 1 x Power Base
• 1 x Cleaning Brush
• 1 x User Manual

Image: The Morpilot Electric Milk Frother, showing the main unit, power base, two whisks, and cleaning brush, alongside its packaging.

Product Features

• 4-in-1 Programs: Capable of producing cold foam, light hot foam, thick hot foam, and heating milk without frothing.
• One-Touch Control: Simple single-button operation for selecting desired functions.
• Easy to Clean: Features a non-stick interior coating for quick wiping and dishwasher-safe lid and whisks.
• Safe and Quiet Operation: Equipped with a Strix automatic temperature control system to prevent overheating (stops at 65 ± 5 °C) and magnetic induction heating technology for quiet operation (approx. 55 decibels).
• Thoughtful Design: Double-walled stainless steel construction, non-slip feet, and an ergonomic touch surface ensure stability and safe handling. BPA/PFOA/PTFE-free materials comply with food safety standards.
• Capacity: Maximum milk capacity of 115ml for frothing and 240ml for heating.

Setup

1. Unpack all components and ensure they are clean.
2. Place the power base on a stable, flat, and dry surface.
3. Select the appropriate whisk for your desired function (spring whisk for frothing, flat whisk for heating milk). Insert it firmly onto the shaft at the bottom of the frother's interior.
4. Place the frother jug onto the power base.
5. Connect the power cord to a suitable electrical outlet.

Image: Close-up of the two whisks provided: the spring whisk for creating milk foam and the flat whisk for heating milk.

Image: The Morpilot milk frother unit placed securely on its detachable power base.

Operating Instructions

The Morpilot Electric Milk Frother offers four distinct modes for preparing your favorite milk-based beverages. Ensure the correct whisk is installed before adding milk.

1. Add Milk: Pour the desired amount of milk into the frother. Observe the internal markings for maximum fill levels: 115ml for frothing and 240ml for heating. Do not overfill.
2. Select Mode: Press the power button repeatedly to cycle through the four available modes. The indicator light will change to reflect the selected mode.
• Cold Milk Foam: Ideal for iced coffees or cold beverages. (Uses frothing whisk)
• Hot Light Foam: For cappuccinos or lattes with a lighter foam texture. (Uses frothing whisk)
• Hot Thick Foam: For macchiatos or richer, denser foam. (Uses frothing whisk)
• Hot Milk (No Foam): For hot chocolate or simply warming milk. (Uses heating whisk)
3. Start Operation: Once the desired mode is selected, the frother will begin operation automatically. The process typically takes between 55-170 seconds depending on the mode and milk volume.
4. Completion: The frother will automatically shut off when the cycle is complete. Carefully remove the frother jug from the base and pour the frothed or heated milk.

Image: The Morpilot milk frother displaying the four operational modes: Froth Cold Milk, Hot Airy Foam, Heat Milk, and Cold Milk Foam, each with an illustrative icon.

Image: Visual representations of the different milk preparations: Warm Dense Milk, Warm Airy Dense Milk, Hot Milk, and Cold Milk Foam, with approximate processing times.

Image: A four-step visual guide demonstrating how to use the frother: 1. Install the whisk, 2. Pour milk, 3. Select function, 4. Enjoy the finished beverage.

Cleaning and Maintenance

Regular cleaning ensures the longevity and hygiene of your milk frother.

• Unplug: Always unplug the appliance from the power outlet before cleaning.
• Interior Cleaning: The frother features a non-stick interior coating. After each use, wipe the interior with a soft, damp cloth or sponge. For stubborn residue, use a small amount of mild dish soap and rinse thoroughly.
• Whisks and Lid: The whisks and lid are dishwasher safe for convenient cleaning. Alternatively, wash them by hand with warm, soapy water.
• Exterior Cleaning: Wipe the exterior of the frother and the power base with a soft, damp cloth. Do not use abrasive cleaners or scouring pads.
• Important Note: Do not immerse the main frother unit (especially the electrical switch area) or the power base in water or any other liquid. Avoid washing the switch directly with water to prevent damage.
• Storage: Ensure all parts are completely dry before storing the appliance.

Image: Demonstrates the easy cleaning process, highlighting the non-stick interior coating and scratch-resistant material, with a visual reminder not to wash the switch with water.

Troubleshooting

If you encounter any issues with your Morpilot Electric Milk Frother, please refer to the following common problems and solutions:

Specifications

Warranty and Support

Morpilot is committed to providing high-quality products. For any warranty claims, technical support, or product-related inquiries, please contact Morpilot customer service through the retailer where you purchased the product or visit the official Morpilot website for contact information. Please retain your proof of purchase for warranty purposes.
