Satco Lighting S29811-11 Watt A19 LED Dimmable Frosted Light Bulbs - User Manual
Model: S29811
1. Introduction
This manual provides essential information for the safe and efficient use of your Satco Lighting S29811-11 Watt A19 LED Dimmable Frosted Light Bulbs. Please read this manual thoroughly before installation and retain it for future reference.
2. Safety Information
Always follow basic safety precautions when installing or replacing light bulbs to reduce the risk of fire, electric shock, or injury to persons.
- WARNING: Risk of Electric Shock. Disconnect power before installation.
- Do not use with standard dimmers unless specifically designed for LED dimming. Use only with compatible LED dimmers.
- Not suitable for use in totally enclosed luminaires unless the luminaire is designed for LED bulbs.
- Do not use where directly exposed to water. Suitable for damp locations.
- Do not disassemble the bulb. There are no user-serviceable parts inside.
- Ensure the bulb is cool before handling or replacing.
- This device is not intended for use with emergency exits.
- Not compatible with photo sensors, motion sensors, or timers unless specified.
3. Product Overview
The Satco S29811-11 Watt A19 LED Dimmable Frosted Light Bulb is an energy-efficient lighting solution designed to replace traditional 75-watt incandescent bulbs. It provides a soft warm white light (3000K) and is fully dimmable, allowing for adjustable ambiance.
Key Features:
- Energy Efficient: Consumes up to 80% less energy than traditional incandescent bulbs, reducing your energy costs.
- Dimmable: Adjust the brightness to your desired level for personalized ambiance.
- Soft Warm White Light (3000K): Creates a warm and inviting atmosphere, ideal for living spaces and bedrooms.
- High Lumen Output (1100 Lumens): Provides ample brightness for everyday tasks and activities.
- Long Lifespan: Lasts up to 25,000 hours, minimizing the need for frequent replacements.
Product Components:
4. Setup and Installation
Follow these steps to safely install your Satco LED A19 bulb:
- Turn off power: Before replacing any light bulb, ensure the power to the fixture is turned off at the circuit breaker or fuse box.
- Allow old bulb to cool: If replacing an incandescent bulb, allow it to cool completely before touching.
- Remove old bulb: Carefully unscrew the old bulb counter-clockwise from the light fixture.
- Inspect fixture: Check the light fixture for any damage or loose wiring.
- Install new bulb: Gently screw the Satco LED A19 bulb clockwise into the light fixture until it is snug. Do not overtighten.
- Restore power: Turn the power back on at the circuit breaker or fuse box.
Note: This bulb is designed for standard medium base sockets (E26/E27).
5. Operating Instructions
Your Satco S29811-11 Watt A19 LED bulb operates like a standard light bulb but offers dimming capabilities.
- Turning On/Off: Use the standard wall switch connected to the light fixture.
- Dimming: If connected to a compatible LED dimmer switch, adjust the dimmer control to achieve your desired brightness level. Ensure your dimmer is specifically designed for LED lighting to prevent flickering or damage.
6. Maintenance
The Satco LED A19 bulb requires minimal maintenance due to its long lifespan.
- Cleaning: Ensure the power is off and the bulb is cool before cleaning. Wipe the bulb with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
- Replacement: With a lifespan of up to 25,000 hours, frequent replacement is not necessary. When replacement is needed, follow the installation steps in Section 4.
7. Troubleshooting
If you encounter issues with your Satco LED A19 bulb, refer to the following common troubleshooting steps:
| Problem | Possible Cause | Solution |
|---|---|---|
| Bulb does not light up. | No power to the fixture, loose connection, or faulty bulb. | Check circuit breaker. Ensure bulb is screwed in tightly. Test bulb in another working fixture. |
| Bulb flickers or hums when dimmed. | Incompatible dimmer switch. | Ensure you are using an LED-compatible dimmer. Consult Satco's website for a list of compatible dimmers. |
| Light output is too low or too high. | Dimmer setting or incorrect bulb for application. | Adjust dimmer. Verify bulb specifications meet your lighting needs. |
| Bulb turns off unexpectedly. | Overheating in an enclosed fixture not rated for LED, or power fluctuations. | Ensure fixture is suitable for LED bulbs, especially if enclosed. Check power supply. |
8. Specifications
Detailed technical specifications for the Satco S29811-11 Watt A19 LED Dimmable Frosted Light Bulb:
| Attribute | Value |
|---|---|
| Brand | Satco |
| Model Number | S29811 |
| Light Type | LED |
| Special Feature | Dimmable |
| Wattage | 11 Watts (75W Equivalent) |
| Bulb Shape Size | A19 |
| Light Color | Warm White |
| Color Temperature | 3000 Kelvin |
| Voltage | 120 Volts |
| Lumen Output | 1100 Lumens |
| Lifespan | Up to 25,000 hours |
| Beam Angle | 220 Degree |
| Base Type | Medium Base (E26) |
| Item Package Quantity | 6 |
| Product Dimensions | 8 x 5 x 5 inches (package) |
| Item Weight | 16 ounces (package) |
| Color Rendering Index (CRI) | 80 |
| First Available | August 19, 2019 |
9. Warranty and Support
Satco Lighting S29811-11 Watt A19 LED Dimmable Frosted Light Bulbs come with a 5-year warranty. For complete warranty terms and conditions, please consult the official Satco website or contact their customer support.
For technical support, troubleshooting assistance, or warranty claims, please visit the official Satco website or contact their customer service department. Always provide your product model number (S29811) when seeking support.
Official Website: www.satco.com
